Frigidaire FGF379WJCA Manual de usuario

FACTORY PARTS CATALOG

GAS RANGE

P.O. Box 212378

Augusta, Georgia 30917

PRODUCT NO. BASE MODEL NO. COLOR MARKET

FGF379WJCA FGF379WJ stainless/black USA

FGF379WJCB FGF379WJ stainless/black USA

Publication No.

5995344289

0001004

-EN/SERVICE /CML

369

WIRING DIAGRAM # - 316002166

OWNER’S GUIDE # - 316135903

INSTALLATION GUIDE # - 316105837 GAS - RANGE

FGF379WJCA

FGF379WJCB

10/00 2

Publication number

5995344289 FGF379WJCA, FGF379WJCB

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

# - Fast Moving Parts

* - Non Illustrated Parts 3 10/00

Publication number

FGF379WJCA, FGF379WJCB 5995344289

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

A = FGF379WJ (FGF379WJCA)

B = FGF379WJ (FGF379WJCB)

POS. NO PART NO DESCRIPTION

* 218490900 A B Cleaner,stainless steel

* 316001435 A B Wiring Harness,backguard

* 316021105 A B Screw,hex head cup pt ,8-18 x 0.375 ,

black,back/bodyside

* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome ,

hinge,ind light,manifold panel

* 316021110 A B Screw,semi gimlet ,8-18 x 0.500 ,black

1 316028700 A B Shield-backguard,galv ,rear wall

13A 316095500 A B Switch-warmer, infinite,drawer/zone

14A 3131963 A B Light-indicator,warmer dwr/zone

15 316023108 A B Support-backguard,RH

15A 316023109 A B Support-backguard,LH

18 316021800 A B End Cap,black ,RH

18A 316021801 A B End Cap,black ,LH

16 316042612 A B Plate-instr. mtg.

19 316028381 A B Panel-control,assy ,glass ,stainless ,black

19* 5303272836 A B Clip-backguard

20 # 316080102 A B Clock/Timer,EOC

21 316039201 A B Trim-canopy/shield

24 # 316083101 A B Switch-rocker,oven light ,black ,RH

28 316015102 A B Push Button,clock/timer/EOC ,black

28A 316080600 A B Shaft-push button,clock/timer/EOC ,black

31A 316095700 A B Knob-warmer,black ,(2)

36 316085000 A B Knob-top valve,(4)

40 316086824 A B Panel-manifold

42 5303272839 A B Trim-vent

44 5303272831 A B Bracket-backguard,(2)

51 316082300 A B Nameplate,black

56 316074907 A B Deflector-flue, black

69 5303292005 A B Screw-switch

10/00 4

Publication number

5995344289 FGF379WJCA, FGF379WJCB

CAUTION: Use the part number on all orders, not the position number.

BURNER

# - Fast Moving Parts

* - Non Illustrated Parts 5 10/00

Publication number

FGF379WJCA, FGF379WJCB 5995344289

CAUTION: Use the part number on all orders, not the position number.

A = FGF379WJ (FGF379WJCA)

B = FGF379WJ (FGF379WJCB)

POS. NO PART NO DESCRIPTION

* 5303271648 A B Screw,wafer hd sq dr ,8-18AB x 1/2 ,burner box

1 # 316113801 A - Manifold Pipe

1 316134501 - B Manifold Pipe

2 B 316127507 A - Valve-top burner 5K

2 B 316134107 - B Valve-top burner 5K

2 # 316127500 A - Valve-top burner 9K

2 # 316134100 - B Valve-top burner 9K

2* 316048200 A - Screw-,hex washer head ,1/4-20 x 0.31,w/gasket

2* 316134300 - B Screw-10-24,valve mtg

2A# 316127502 A - Valve-top burner, 11K

2A# 316134102 - B Valve-top burner, 11K

3 316001826 A B Harness ignitor assy

4 # 316059612 A B Tube-burner,red ,RF

5 # 316059613 A B Tube-burner,green ,LF

6 # 316059614 A B Tube-burner,natural ,RR

7 # 316059615 A B Tube-burner,black ,LR

8 # 316135701 A B Spark Module

8* 5303289034 A B Wiring Harness, module/igniter

10 # 5303935025 A B Burner Assy-top,sealed ,small ,9000 BTU

10A 5303935075 A B Burner Assy-top,sealed ,large ,

11,100 BTU,(2), includes ,11,37,44,45

10B 316010605 A B Burner Assy-top,sealed 5,000 BTU

11 316011200 A B Ignitor-top burner,(4) ,w/mtg bracket

13 # 316065005 A B Tube,aluminum ,rgltr to manf ,with fittings

14 # 316091706 A B Regulator-pressure

14* 316021104 A B Screw-regulator/brkt, hex , 8-18 x 3/8 ,nick,3

15 316091600 A B Bracket-regulator

16 # 316065003 A B Tube-valve to regulator,3/8

17 # 5303208499 A B Valve-safety,dual

18 # 3131290 A B Burner-oven

19 316119301 A B Ignitor-oven

20 3131284 A B Baffle-oven burner

21 5303013272 A B Nut, hex head sems

22 # 316065002 A B Tube-valve to mixer

23 # 08067935 A B Burner-broiler

24 # 316070400 A B Mixer Elbow

25 5303210379 A B Baffle-broiler

26 # 316119302 A B Ignitor-broiler

37 316069301 A B Screw-burner mtg

44 5303210090 A B Orifice-top burner,small

45 316011100 A B Screw-ignitor mtg,self-tapping ,M3x5.8

46 316074700 A B Plate-burner tube

47 # 316039616 A B LP Conversion Kit

BURNER

10/00 6

Publication number

5995344289 FGF379WJCA, FGF379WJCB

CAUTION: Use the part number on all orders, not the position number.

BODY

# - Fast Moving Parts

* - Non Illustrated Parts 7 10/00

Publication number

FGF379WJCA,FGF379WJCB 5995344289

CAUTION: Use the part number on all orders, not the position number.

BODY

A = FGF379WJ (FGF379WJCA)

B = FGF379WJ (FGF379WJCB)

POS. NO PART NO DESCRIPTION

* 316021105 A B Screw,hex head cup pt ,8-18 x 0.375 ,

black,back/bodyside

* 316021108 A B Screw,cup pt ,8-18 x 0.375 ,chrome ,

hinge,ind light,manifold panel

1 316029416 A B Back-main

2 3131314 A B Shield-oven top

3 316081038 A B Panel-bodyside, black, RH, textured

3 316081039 A B Panel-bodyside, black, LH, textured

4 316011918 A B Burner Box,4 ,solid

5 316129200 A B Screw-leveling,plastic ,with stop

6 316083800 A B Rack-oven

7 316007005 A B Hinge-oven door, (2)

8 5303212540 A B Panel-oven bottom

8* 316064600 A B Support-oven bottom

9 316081900 A B Pan-broiler

10 316082000 A B Insert-broiler pan

12 # 316027701 A B Switch-oven light

13 316026800 A B Rod-light switch /door

14 316116400 A B Socket-light/lamp,oven

15 5303013071 A B Light Bulb/Lamp

16 08011086 A B Lens-light/lamp, glass , oven

17 316087500 A B Retainer-lens

18 # 316036300 A B Latch-door

21 3014099 A B Spacer-bodyside, (8)

25A 316092300 A B Shield-warmer, upper

28 3011813 A B Clip-wire, bodyside

30 316059200 A B Bracket-main top,RH

30A 316059201 A B Bracket-main top,LH

33 5303288495 A B Shield,rear wall

35 316116600 A B Gasket-flue

36 316133002 A B Flue

37 # 316111202 A B Probe-oven temp

38 316051700 A B Shield-heat

38A 316097100 A B Insulator,shield

39 # 3131425 A B Cord-electric power

40 3200836 A B Shield-heat baffle

40* 5303288570 A B Screw-heat shield, hd shldr sqdr ,8-18 X 1/2

41 3131570 A B Cover-hinge cutout

42 5303288578 A B Shield-bake burner

43 3131732 A B Screw-oven bottom, 8-18 x 1.438

44 3131903 A B Bumper-door/drawer, rubber

49 3051124 A B Clip-spring mtg

53 5303288579 A B Shield,main front

53A 08067992 A B Shield-insulation

55 316107800 A B Shield-flue

58A 316047708 A B Insulation, 2" ,oven wrapper

58B 316054200 A B Insulation, 2" ,oven back

58G 08067973 A B Insulation,main front

72 5303285692 A B Cover-light/switch rod

77 316105500 A B Glide-warmer, outer/RH & LH , (2)

10/00 8

Publication number

5995344289 FGF379WJCA, FGF379WJCB

CAUTION: Use the part number on all orders, not the position number.

BODY

# - Fast Moving Parts

* - Non Illustrated Parts 9 10/00

Publication number

FGF379WJCA, FGF379WJCB 5995344289

CAUTION: Use the part number on all orders, not the position number.

BODY

88 316026400 A B Rod-latch,auto

89 # 316028107 A B Motor-latch/lock

155 316095201 A B Shield-drawer, front warmer

170 5303935180 A B Anti-tip Kit,w/bracket,screw

170* 316107200 A B Bracket,anti-tip

170* 316112500 A B Template, Anti-tip bracket

170* 316116000 A B Screw,concrete tpg ,1.75 inch ,

anti-tip brkt

10/00 10

Publication number

5995344289 FGF379WJCA, FGF379WJCB

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER
