Frigidaire FGF334BG Manual de usuario

PRODUCT NO. BASE MODEL NO. COLOR MARKET

FGF334BGDA FGF334BG ALMOND USA

FGF334BGWA FGF334BG WHITE USA

Publication No.

5995308573

980611

-EN/SERVICE /CML

369

GAS - RANGE

Model No.

FGF334BG

FACTORY PARTS CATALOG

GAS RANGE

WIRING DIAGRAM # - 316002152

OWNER’S MANUAL # -316000276

INSTALLATION INST.# - 316002989

104 WARREN ROAD

AUGUSTA, GA 30907-3755

BACKGUARD

Publication No. FGF334BGDA,FGF334BGWA

5995308573

06/98 2

A = FGF334BG (FGF334BGWA)

B = FGF334BG (FGF334BGDA)

POS. NO PART NO DESCRIPTION

* 316002989 A B Instructions,installation

* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316021110 A B Screw-8-18x1/2 Tr Sqd black

1 316028701 A B Shield-backguard,rear wall

11 316083718 A B Trim-wrapper,black

12 # 5303271464 A B Thermostat-oven

15 316023108 A B Support-backguard,RH

15A 316023109 A B Support-backguard,LH

19 316100531 A B Panel-BG,Beta,black

20 # 316097901 A B Clock/Timer,electronic

20* 316098000 A B Overlay-clock,black

23 316033204 A B Bracket-timer

24 # 316005602 A B Switch-rocker,oven light ,black

32 316053602 A B Knob-thermostat black

36 316109502 A B Knob-top valve blk,black

40 316009267 A B Panel-manifold

42 316055200 A B Trim-vent

56 316074907 A B Deflector-flue,black

60 316021105 A B Screw,hex ,8-18 x 3/8 ,back\bodyside

BACKGUARD

FGF334BGDA,FGF334BGWA Publication No.

5995308573

# = Functional Part 3 06/98

* = Non-Illustrated Part

BURNER

Publication No. FGF334BGDA,FGF334BGWA

5995308573

06/98 4

A = FGF334BG (FGF334BGWA)

B = FGF334BG (FGF334BGDA)

POS. NO PART NO DESCRIPTION

1 # 316066201 A B Manifold Pipe

2 # 5303935130 A B Valve-top burner

2* 316048200 A B Screw-top valve mtg,hex washer head ,

1/4-20 x 0.31,w/gasket

3 # 316103600 A B Switch-ignitor,(4)

4 # 316059612 A B Tube-burner,red ,RF

5 # 316059613 A B Tube-burner,green ,LF

6 # 316059614 A B Tube-burner,nat. ,RR

7 # 316059615 A B Tube-burner,black ,LR

8 # 5303280394 A B Spark Module

8* 5303289034 A B Harness-wiring,module/igniter

10 # 5303935025 A B Burner Assy-top,sealed ,small ,9000 BTU

11 # 316011200 A B Ignitor-top burner,(4) ,w/mtg bracket

13 # 316065005 A B Tube,aluminum ,rgltr to manf ,

with fittings

14 # 316091706 A B Regulator-pressure

14* 316021104 A B Screw-regulator/brkt,hex ,8-18 x 3/8 ,

nick, 3

15 316091600 A B Bracket-regulator

16 # 316065006 A B Tube-valve to rgltr,3/8

17 # 3203459 A B Valve-safety

18 # 3131439 A B Burner-oven

19 # 5303935066 A B Ignitor-oven

20 3203265 A B Baffle-oven burner

21 5303013272 A B Nut,hex head sems

37 316069301 A B Screw-burner mtg,m3x0.50

44 5303210090 A B Orifice-top burner,small

45 316011100 A B Screw-ignitor mtg,self-tapping ,M3x5.8

46 316074700 A B Plate-burner tube

47 5303286386 A B LP Conversion Kit

48 3018603 A B Bracket-support,oven burner

49 3131438 A B Bracket,safety valve

BURNER

FGF334BGDA,FGF334BGWA Publication No.

5995308573

# = Functional Part 5 06/98

* = Non-Illustrated Part

BODY

Publication No. FGF334BGDA,FGF334BGWA

5995308573

06/98 6

A = FGF334BG (FGF334BGWA)

B = FGF334BG (FGF334BGDA)

POS. NO PART NO DESCRIPTION

* 3203550 A B Plug-button

* 316001219 A B Harness-wiring,main

* 316021105 A B Screw,hex ,8-18 x 3/8 ,back\bodyside

* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

1 316029412 A B Back-main

3 316081028 A - Panel-bodyside,white ,RH

3 316081030 - B Panel-bodyside,almond ,RH

3* 316081029 A - Panel-bodyside,white ,LH

3* 316081031 - B Panel-bodyside,almond ,LH

4 316011912 A B Burner Box,black

5 5303203397 A B Screw-leveling

5* 3934058 A B Anti-tip Kit

5* 316078600 A B Screw,anti-tip ,(4)

5A 5303288460 A B Nut,T-type ,leveling screw

6 316067902 A B Rack-oven

7 316007001 A B Hinge-oven door,(2)

7* 5303012323 A B Clip,hinge ,(4)

8 5303212540 A B Panel-oven bottom

8* 316064600 A B Support-oven bottom

14 3014073 A B Socket-light/lamp,oven

15 5303013071 A B Light Bulb/Lamp

21 3014099 A B Spacer-bodyside,(8)

26 08067757 A B Cover Plate

27 5303284616 A B Clip-thermo bulb

28 3011813 A B Clip-wire,bodyside

30 316059200 A B Bracket-main top, RH

30A 316059201 A B Bracket-main top, LH

33 316055601 A B Shield-spark module

34 3018607 A B Cover Plate

35 08067965 A B Gasket-flue

36 5303273108 A B Flue

39 3202006 A B Cord-electric power

40* 5303288570 A B Screw-heat shield,hd shldr sqdr ,

8-18 X 1/2

41 3131570 A B Cover-hinge cutout

43 3131732 A B Screw-oven bottom,8-18 x 1.438

49 3051124 A B Clip-spring mtg

54 5303271606 A B Housing-oven light

55 5303289358 A B Shield-flue

58A 3017142 A B Insulation,oven wrapper

58B 3203541 A B Insulation,oven back

60 5303015372 A B Cover-oven front

73 5303281627 A B Base-broiler

93 316110000 A B Shield-ignitor connecito, metal ,

galvanized

BODY

FGF334BGDA,FGF334BGWA Publication No.

5995308573

# = Functional Part 7 06/98

* = Non-Illustrated Part

TOP/DRAWER

Publication No. FGF334BGDA,FGF334BGWA

5995308573

06/98 8

185 316112900 A

A = FGF334BG (FGF334BGWA)

B = FGF334BG (FGF334BGDA)

POS. NO PART NO DESCRIPTION

* 316021105 A B Screw,hex ,8-18 x 3/8 ,back\bodyside

* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316021110 A B Screw-8-18x1/2 Tr Sqd black

* 316021112 A - Screw-8-18x1/2 Tr Sqd White

* 316021113 - B Screw-8-18x1/2 Tr Sqd Almond

* 5303280311 A B Screw,waf hd sdr ,10-32 x 5/16 ,(2)

1 316110401 A B Carriage,broiler

2 316110101 A B Liner-low broil

2A 316110800 A B Shield-broiler

4 316056205 A - Panel-drawer,white

4 316056206 - B Panel-drawer,almond

5 3131387 A B Fastener-spacer,push-in nut ,nylon

9 5303013568 A B Pan-broiler

10 5303131356 A B Insert-broiler pan

10 5303280308 A B Screw-handle mtg,wafer head ,10-24T x 2

13 316111500 A B Glide-drawer,outer

13A 316111600 A B Glide-drawer,inner

16 5303301546 A - Main Top,white

16 5303301547 - B Main Top,almond

18 316059200 A B Bracket-main top,RH

18A 316059201 A B Bracket-main top,LH

19 # 316011401 A B Pan-burner,(4)

20 # 316085201 A B Grate,(4)

22 316098501 A B Cap-burner,black ,(4)

30 316111400 A B Insulation,broiler drawer

39 316019505 A - Handle-drawer,white

39 316019508 - B Handle-drawer,almond

85 316110500 A B Rack,warmer drawer

60 316089500 A B Screw,10-16 x .486 ,handle,(2)

TOP/DRAWER

FGF334BGDA,FGF334BGWA Publication No.

5995308573

# = Functional Part 9 06/98

* = Non-Illustrated Part

DOOR

Publication No. FGF334BGDA,FGF334BGWA

5995308573

06/98 10
