Frigidaire FGC30S4A Manual de usuario

FGC30S4A.eps LA9922T15.eps LA00BR77490-1.eps 318047111.eps

Product No. FGC30S4AQC FGC30S4ASC

3775421261043 3775421261013

Series 30" gas 30" gas

Color bisque white

Market North America North America

Wiring Diagram 318047111 318047111

Owner's Guide 318200657 318200657

Installation Instructions 318201451 318201451

ELECTROLUX HOME PRODUCTS, INC.

P.O. Box 212378, Augusta, GA 30917

Publication No.

5995422820

04/11/24

(EN/SERVICE/ECL)

377

GAS COOK-TOP

RANGE

Model No.

FGC30S4A

Publication No: 5995422820 FGC30S4A

11/04 2

COOK TOP

FGC30S4A Publication No: 5995422820

# Functional Parts 3 11/04

* Non-Illustrated Parts

COOK TOP

Model Index: AFGC30S4A (FGC30S4ASC)

BFGC30S4A (FGC30S4AQC)

POS. NO PART NO. DESCRIPTION

16 318159142 A - Panel, main top, white

16 318159145 - B Panel, main top, bisque

19 318167906 A - Pan, burner, white, medium

19 318167909 - B Pan, burner, bisque, medium

19A 318167907 A - Pan, burner, white, large

19A 318167910 - B Pan, burner, bisque, large

19B 318167908 A - Pan, burner, white, small

19B 318167911 - B Pan, burner, bisque, small

20 318227000 A - Grate, burner, grey, (4)

20 318227001 - B Grate, burner, brown, (4)

22 318076411 A - Cap, burner, grey, medium LF & LR

22 318076414 - B Cap, burner, brown, medium LF & LR

22A 318076421 A - Cap, burner, grey, large RF

22A 318076424 - B Cap, burner, brown, large RF

22B 318076401 A - Cap, burner, grey, small RR

22B 318076404 - B Cap, burner, brown, small RR

23 318242303 A - Panel, control, white

23 318242304 - B Panel, control, bisque

43 318196140 A - Knob, control, white

43 318196142 - B Knob, control, bisque

46 318156000 A B Burner Box

47 318144002 A B Cord, service

64 5303304033 A B Bracket, retainer

65 5303304032 A B Seal, rubber

132 3201437 A B Strain relief

136 5303935029 A B Support

137 5303323138 A B Screw, 10-24x1/2

* 5303323140 A B Screw, ground, 10-32 x 0.375

Publication No: 5995422820 FGC30S4A

11/04 4

BURNER

FGC30S4A Publication No: 5995422820

# Functional Parts 5 11/04

* Non-Illustrated Parts

BURNER

Model Index: AFGC30S4A (FGC30S4ASC)

BFGC30S4A (FGC30S4AQC)

POS. NO PART NO. DESCRIPTION

1 318177003 A B Manifold Pipe

* 08011955 A B Screw, 10-24 x 0.375, square drive

2 # 5303935042 A B Valve, top burner, 2-position, 9100 BTU

2A # 318087001 A B Valve, top burner, 5000 BTU

2B # 318087040 A B Valve, top burner, 13000 BTU

3 # 318232604 A B Wiring Harness, w/igntr switch

4 # 318167714 A B Tube, burner, RF

5 # 318167700 A B Tube, burner, LF

6 # 318167702 A B Tube, burner, RR

7 # 318167701 A B Tube, burner, LR

8 # 316135701 A B Module, spark

10 # 318148001 A B Burner, top, 9100 BTU, medium LF & LR

10A# 318148002 A B Burner, top, 13000 BTU, large RF

10B# 318148000 A B Burner, top, 5000 BTU, small RR

14 # 5308007974 A B Regulator, pressure

35 318146300 A B Bushing

72 5303323141 A B Screw, valve mtg, 1/4-20 x 5/16

73 318024201 A B Bracket, spark module

74 # 318148700 A B Ignitor, top burner

75 318148800 A B Clip, electrode

76 # 318167801 A B Tube, mixing, medium & large

76A# 318167800 A B Tube, mixing, small

77 318112010 A B Bracket, burner mtg, medium & large

77A 318112000 A B Bracket, burner mtg, small

77B 318180900 A B Bracket, burner tube

78 318220100 A B Shield, burner box

* 318199729 A B Wiring Harness, ignitor

* # 318127407 A B LP Conversion Kit

* 5303311532 A B Screw, 6-32 x 1/4", back

* 5304403558 A B Screw, 10-16 x 0.250

Publication No: 5995422820 FGC30S4A

11/04 6

WIRING DIAGRAM
