FACTORY PARTS CATALOG

ELECTRIC RANGE

P.O. Box 212378

Augusta, Georgia 30917

PRODUCT NO. BASE MODEL NO. COLOR MARKET

FEF322BAWJ FEF322BA WHITE USA

FEF322BADJ FEF322BA ALMOND USA

Publication No.

5995319265

980731

-EN/SERVICE /VLM

369

WIRING DIAGRAM # - 316002602

OWNER’S GUIDE # - 316000230

INSTALLATION GUIDE # - 316003025 ELECTRIC - RANGE

FEF322BAWJ

FEF322BADJ

03/98 2

Publication number

5995319265 FEF322BAWJ, FEF322BADJ

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

# - Fast Moving Parts

* - Non Illustrated Parts 3 6/98

Publication number

FEF322BAWJ, FEF322BADJ 5995319265

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

A = FEF322BA (FEF322BAWJ)

B = FEF322BA (FEF322BADJ)

POS. NO PART NO DESCRIPTION

* 316003018 A B Instructions,installation

* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316021110 A B Screw-8-18x1/2 Tr Sqd black

1 316081601 A B Shield-backguard,rear wall

2 316015907 A B Shield-backguard,inner

11 316083719 A B Trim-wrapper,textured ,black

12 # 316032400 A B Thermostat-oven,non sc

13 # 316032500 A B Switch-selector

14 316022504 A B Light-indicator,250v

15 316023108 A B Support-backguard,RH

15A 316023109 A B Support-backguard,LH

19 316024477 A B Panel-control

20* 316098000 A B Overlay-clock,black

23 316033204 A B Bracket-timer

24 # 316005602 A B Switch-rocker,oven light ,black

31 316109602 A B Knob-selector

32 316109600 A B Knob-thermostat

36 316025100 A B Knob-control,infinite sw

40 316025800 A B Panel-manifold

46 316040201 A B Lens-light/lamp,indicator ,red

54 # 316021500 A B Switch-infinite, 6" element

54A# 316021501 A B Switch-infinite, 8" element

69 5303292005 A B Screw-switch/handle,8-32 x 5/32

03/98 4

Publication number

5995319265 FEF322BAWJ, FEF322BADJ

CAUTION: Use the part number on all orders, not the position number.

BODY

# - Fast Moving Parts

* - Non Illustrated Parts 5 03/98

Publication number

FEF322BAWJ, FEF322BADJ 5995319265

CAUTION: Use the part number on all orders, not the position number.

BODY

A = FEF322BA (FEF322BAWJ)

B = FEF322BA (FEF322BADJ)

POS. NO PART NO DESCRIPTION

* 3203550 A B Plug-button

* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 5303051099 A B Nut,hex ,#10-32

1 316080804 A B Back-main, short,dipped ,black

3 316081028 A - Panel-bodyside,white ,RH

3 316081030 - B Panel-bodyside,almond ,RH

3* 316081029 A - Panel-bodyside,white ,LH

3* 316081031 - B Panel-bodyside,almond ,LH

4 5303271756 A B Burner Box

5 5303203397 A B Screw-leveling

5* 3934058 A B Anti-tip Kit

5* 316078600 A B Screw,anti-tip ,(4)

5A 5303288460 A B Nut,T-type ,leveling screw

6 316067902 A B Rack-oven

7 316007001 A B Hinge-oven door,(2)

8 3203540 A B Panel-oven bottom

9 316073800 A B Pan-broiler

10 3205234 A B Insert-broiler pan

14 316116400 A B Socket-light

15 5303013071 A B Light Bulb/Lamp

21 3014099 A B Spacer-bodyside,(8)

27 5303284616 A B Clip-thermo bulb

29 3051162 A B Glide-drawer,front

30 5303283574 A B Bracket-hinge,main top RH

30A 5303283575 A B Bracket-hinge,main top LH

41 3131570 A B Cover-hinge cutout

57 316081101 A B Cover-access

58 3200847 A B Insulation,oven bottom

58A 316047707 A B insulation, wrapper

58B 316054202 A B Insulation, oven back

59 316073601 A B Tube-oven vent

62 # 5303935061 A B Terminal Block

63 5301145190 A B Plate-ground strap

66 # 5303051140 A B Element-broil

67 # 316075102 A B Element-bake,lower oven

68 316075300 A B Support-element, broil

71 316015805 A B Shield-rear wall

82 5303289913 A B Shield-insulation

87 316081200 A B Bracket-cable mtg

03/98 6

Publication number

5995319265 FEF322BAWJ, FEF322BADJ

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

# - Fast Moving Parts

* - Non Illustrated Parts 7 03/98

Publication number

FEF322BAWJ, FEF322BADJ 5995319265

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

A = FEF322BA (FEF322BAWJ)

B = FEF322BA (FEF322BADJ)

POS. NO PART NO DESCRIPTION

* 316001725 A B Harness-wiring,surface element

* 316021108 A B Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316021110 A B Screw-8-18x1/2 Tr Sqd black

* 316021112 A - Screw-8-18x1/2 Tr Sqd White

* 316021113 - B Screw-8-18x1/2 Tr Sqd Almond

* 316058601 A B Clip-surface element,(4)

* 316089600 A B Spacer-drawer,(2)

* 5303280311 A B Screw,waf hd sdr ,10-32 x 5/16 ,(2)

* 5308014215 A B Screw,#6-20 x 5/16 ,(4)

1 316011501 A B Drawer-utility

2 3131975 A B Shield-panel

4 316084405 A - Panel-drawer,white

4 316084406 - B Panel-drawer,almond

4* 08067785 - B Screw,hex washer head ,8-18AB x 1/2

7 3051163 A B Glide-drawer,rear

15 # 5308011964 A B Element-surface,large/8 inch ,(2) ,

medallion incl

15A# 5308011963 A B Element-surface,small/6 inch ,

medallion incl

16 316020907 A - Main Top,white

16 316020908 - B Main Top,almond

17 316057601 A B Rod-maintop support

18 5303273062 A B Hinge-main top,RH

18A 5303273063 A B Hinge-main top,LH

19 # 5303935053 A B Pan-surface element,black ,lg/8 inch ,

(2)

19A# 5303935055 A B Pan-surface element,black ,sml/6 inch ,

(2)

27 # 5301167733 A B Terminal Block Kit,surface element

28 5303017715 A B Meddallion, 1 ½” dia. Black surface element.

03/98 8

Publication number

5995319265 FEF322BAWJ, FEF322BADJ

CAUTION: Use the part number on all orders, not the position number.

DOOR

# - Fast Moving Parts

* - Non Illustrated Parts 9 03/98

Publication number

FEF322BAWJ, FEF322BADJ 5995319265

CAUTION: Use the part number on all orders, not the position number.

DOOR

A = FEF322BA (FEF322BAWJ)

B = FEF322BA (FEF322BADJ)

POS. NO PART NO DESCRIPTION

* 316021110 A B Screw-8-18x1/2 Tr Sqd black

* 5303212671 A B Screw,cr pan hd sems ,8-32BP x 1.00

* 5303212762 - B Screw,8-18 X 1/2

* 5303271648 A B Screw,wafer hd sq dr ,8-18AB x 1/2

* 5303280311 A B Screw,waf hd sdr ,10-32 x 5/16 ,(2)

3 316067802 A B Trim-oven door,black

4 316089000 A B Glass-oven door,black ,outer

6 316088403 A B Shield-wool

7 316076401 A B Insulation,oven door

8 316088600 A B Glass-oven door,inner

9 316066610 A B Liner-oven door

10 5303280308 A B Screw-handle mtg,wafer head ,10-24T x 2

12 5303202011 A B Seal-oven door,non self-clean

39 316091114 A B Handle-door,black ,oven

39* 316008401 A B Washer,3/4 x 1/4 ,steel

39* 5303292005 A B Screw-switch/handle,8-32 x 5/32

52 316081303 A B Shield-oven door,black ,top

03/98 10

Publication number

5995319265 FEF322BAWJ, FEF322BADJ

CAUTION: Use the part number on all orders, not the position number.

WIRING DIAGRAM
