Frigidaire FEB556CE Manual de usuario

PRODUCT NO. FACTORY NO. COLOR MARKET

FEB556CESH 38254431G6018 WHITE U.S.A.

FEB556CEBH 38254431G6068 BLACK U.S.A.

FEB556CETH 38254431G6038 ALMOND U.S.A.

ELECTRIC WALL OVEN

Model No.

FEB556CE

FACTORY PARTS CATALOG

ELECTRIC WALL OVEN

WIRING DIAGRAM #- 318046212

OWNER’S GUIDE #- 318200912

INSTALLATION INSTR. # - 318064300

TIMER INSTRUCTION GUIDE # - 318130806

FRIGIDAIRE HOME PRODUCTS

7075 ORDAN DRIVE

MISSISSAUGA, ONTARIO

CANADA, L5T 1K6

TEL: (905) 565-9200

Publication No.

5995333829

000222

-EN/SERVICE

377

Publication No. FEB556CE

5995333829

02/00 2

CONTROL PANEL

101

LA00CP82431-1

15A

18A

FEB556CE Publication No.

5995333829

# = Functional Part 302/00

* = Non-Illustrated Part

CONTROL PANEL

POS. NO PART NO DESCRIPTION

15 5303302286 A B CSupport backguard RH

15A 5303302287 A B CSupport backguard LH

18 5303311208 AEnd Cap RH white

18 5303311231 BEnd Cap RH black

18 5303311225 CEnd Cap RH almond

18A 5303311209 AEnd Cap LH white

18A 5303311232 BEnd Cap LH black

18A 5303311226 CEnd Cap LH almond

19 318030601 APanel-control white

19 318030600 BPanel-control black

19 318030603 CPanel-control almond

20 # 318010900 A B CClock/Timer

21 5303320425 ATrim-canopy white

21 5303300408 BTrim-canopy black

21 5303320658 CTrim-canopy almond

23 318111602 A B CBracket timer

42 5303316649 ATrim-vent white

42 5303316651 BTrim-vent black

42 5303316650 CTrim-vent almond

65 318038804 A B CCover-control housing

68 5303302397 A B CHousing control

78 5303302394 ACover, oven vent white

78 5303302396 BCover, oven vent black

78 5303302395 CCover, oven vent almond

80 318111500 A B CRelay (9 volts)

99 5303316956 AScrew, 6-32 X 3/8, white

99 5303307406 BScrew, 6-32 X 3/8, black

99 5303317307 CScrew, 6-32 X 3/8, almond

101 5303302412 A B CShield-backsplash

*5303211311 A B CScrew #8 X ½

A = FEB556CE (FEB556CESH)

B = FEB556CE (FEB556CEBH)

C = FEB556CE (FEB556CETH)

FEB556CE Publication No.

5995333829

02/00 4

CAVITY / ELEMENTS

58B

126

58C 62

LA00B82431-1

98A

103

101

127

141

99231

14 15 16

187

257

189

121

123

58A

129

128

FEB556CE Publication No.

5995333829

# = Functional Part 502/00

* = Non-Illustrated Part

CAVITY / ELEMENTS

POS. NO PART NO DESCRIPTION

2 5303298946 A B CShield oven-top

6 5303299366 A B CRack-oven

6B 5303305676 A B CShelf-oven

95303317977 A B CPan-broiler

10 5303317976 A B CInsert broiler pan

12# 318089910 A B CSwitch-light

14 5308011085 A B CSocket-light/lamp

15 3201908 A B CLamp-oven light

16 3201911 A B CGlass-oven light lens

17 5304400195 A B CRetainer-lens

37# 316111203 A B CProbe-oven temp

41 5303310526 A B CCover-hinge cutout

54 5303310514 A B CHousing-oven light

56 5303302711 ATrim-bodyside white

56 5303298951 BTrim-bodyside black

56 5303302712 CTrim-bodyside almond

58A 5304409957 A B CInsulation wrapper

58B 3019048 A B CInsulation oven back

58C 5303311220 A B CInsulation oven vent

59 318072507 A B CTube-oven vent

62# 5303310518 A B CTerminal block

66# 5303322963 A B CElement-broil

67# 5303323865 A B CElement-bake

68 5304403015 A B CSupport-element

71 318071111 A B CShield-wire

76 318056139 A B CFront-oven

80 5303301261 A B CSpring-oven

81 5303323710 A B CBracket-oven

82 5303305035 A B CShield-insulation bottom

83 318089508 A B CLiner-oven assy

86 5303310524 A B CChannel-hinge

88 318118903 A B CRod-latch

89# 318095903 A B CMotor-latch/lock

89* 318120710 A B CCover-Motor

97 318066602 A B CWrapper-back & sides

98 318029322 A B CTrim side inner RH

98A 318029323 A B CTrim side inner LH

99 5303299686 A B CSupport-adjustable

101 318039512 ABracket-trim (white)

101 318039511 BBracket-trim (black)

101 318039513 CBracket-trim (almond)

103 318028711 ATrim-base white

103 318028710 BTrim-base black

103 318028712 CTrim-base almond

121 318145001 A B CWrapper-base

123 318071433 A B CShield-insulation top & sides

126 3016303 A B CClip-insulator retainer

127 5303310542 A B CAdapter assy

128 5303311163 A B CBushing

129 5303311164 A B CSpring

141# 5303300421 A B CThermostat-safety

187 318013501 A B cTube (rod-latch)

189 318042500 A B CRetainer plate

231 5303300421 A B CCover-capillary

257 3131903 A B CPlug

*08002868 A B CScrew, 10-24 X ½

*5303304015 A B CWasher, padded

*3201881 A B CLockwashed

*3018802 A B CClip-cable

*3051070 A B CScrew, 10-24 X 7/16

*5303323137 A B CScrew, 10-32 X 17/32

*318078522 A B CBx & wires ay

*5303935083 AScrew, 10-16 X 1 ¼, white

*5303302745 A B CScrew, 10-16 X 1 1/8, black

*5303325188 CScrew, 10-16 X 1 ¼, almond

A = FEB556CE (FEB556CESH)

B = FEB556CE (FEB556CEBH)

C = FEB556CE (FEB556CETH)

FEB556CE Publication No.

5995333829

02/00 6

DOOR

16 23

LA00D82431-1

FEB556CE Publication No.

5995333829

# = Functional Part 702/00

* = Non-Illustrated Part

DOOR

POS. NO PART NO DESCRIPTION

3 318026102 ATrim-oven door white

3318026520 BTrim-oven door black

3318026103 CTrim-oven door almond

4 5303302707 AGlass-oven door white

4 3202420 BGlass-oven door black

45303302708 CGlass-oven door almond

6 318073600 A B CShield-air wash

7 5303308470 A B CInsulation oven door

9 318038600 A B CLiner-oven door

10 5303311217 A B CScrew, 10-24 x 2 3/16-handle door

11 318065102 A B CStrike plate

12 318178801 A B CSeal-oven door

16 5303324250 A B CGlass-oven door

17 318139100 A B CSpacer-glass upper

18 3016263 A B CSeal-rope upper oven

19 318139201 A B CCollar glass mtg

20 318014301 ASpacer-handle white

20 318014300 BSpacer-handle black

20 318014302 CSpacer-handle almond

23 5303310506 A B CHinge-oven door

25 318048309 A B CLiner-door baffle

29 5303210003 A B CSpacer-handle mtg (2)

39 316091104 AHandle-door white

39 316091103 BHandle-door black

39 316091105 CHandle-door almond

*3202113 A B CButton plug

*5303308456 A B CScrew, 8-18 X 0.531

A = FEB556CE (FEB556CESH)

B = FEB556CE (FEB556CEBH)

C = FEB556CE (FEB556CETH)

Publication No. FEB556CE

5995333829

02/00 8

WIRING DIAGRAM

ELECTRIC - RANGE

Model No.

GEF357CB

FACTORY PARTS CATALOG

ELECTRIC RANGE

WIRING DIAGRAM # - 316002069

FRIGIDAIRE HOME PRODUCTS

7075 ORDAN DRIVE

MISSISSAUGA ONTARIO

CANADA L5T1K6

TEL (905)565-9200
