Frigidaire PLFU1778ES Manual de usuario

P08F0081.eps P08D0456.eps P08C0867.eps P08S0393.eps

Product No. PLFU1778ES0

Series 134A

Color stainless

Volts 115

Wiring Diagram 297005600

Owner's Guide 297055200

Market North America

Energy Guide 216795408

Electrolux Major Appliances

North & Latin America

P.O. BOX 212378

AUGUSTA, GA 30917

Publication No.

5995449815

05/09/30

(EN/SERVICE/MLR)

365

UPRIGHT FREEZER

Model No.

PLFU1778ES

Publication No: 5995449815 PLFU1778ES0

09/05 2

DOOR

21A

P08D0456

PLFU1778ES0 Publication No: 5995449815

# Functional Parts 3 09/05

* Non-Illustrated Parts

DOOR

POS. NO PART NO. DESCRIPTION

1 216522311 Gasket-door, black

9 216527813 Panel-inner door, frzr

11 216526561 Panel-outer door, stainless

12 240558802 Label-nameplate

13 216974400 Door Stop

18 240536801 Handle-door, stainless steel, with insert

* 218755503 Screw-shoulder, #10 AB, handle mounting

* 218755402 Screw-set, 10-32 x 0.375

21A 5303271077 Screw, flat head, #1/4-20, door stop/hng

26 216524200 Gasket, secondary

27 5303212828 Clip, panel mtg

27* 5304406520 Clip, panel mtg kit, (40)

28 216806100 Rack-door, contour, (3)

32 5309950074 Valve, breather, door base

59 216974500 Bearing, door closer

64 216403700 Plug-button, hole filler, door base

72 216514100 Shelf, tilt out, wire, (2)

73 216513900 End Cap, shelf, LH, (2), tilt-out

74 216514000 End Cap, shelf, RH, (2), tilt-out

93 5303161215 Screw, ph truss head, 8-18AB x 0.500

Publication No: 5995449815 PLFU1778ES0

09/05 4

CABINET

93A

93D

13 5

42A

139

138

138A

138C

137

137B

139B

15 16

132

P08C0867

28 152

71A 21

155

154 20

93B

22A

15A

34A

15A

16A

34B

131

60A

PLFU1778ES0 Publication No: 5995449815

# Functional Parts 5 09/05

* Non-Illustrated Parts

CABINET

POS. NO PART NO. DESCRIPTION

3 216503100 Screen-drain

5 # 216325600 Fan Blade

6 216604200 Breaker Kit w/corners

9 216603300 Breaker Kit w/corners, 32", top or bottom

13 # 216934100 Motor, fan, 115 V

14 216922800 Switch, light/lamp, ramp

15 216988100 Light Bulb/Lamp, long, blue tint, 40 W, 120V, (2)

15A 297048600 Light Bulb/Lamp, short, (2)

16 241507803 Socket-light

16* 297002600 Gasket, light socket

16A 216817600 Socket, light/lamp, 25 W

18 216707200 Knob, temp control

19 216204902 Gasket-evap cover

20 216967200 Cover, temp control

21 216715200 Control-temperature

22 216823500 Clamp, cap tube, cold control

22A 5303916855 Tube, sensor sleeve, plastic, clear

24 5300052943 Screw-clamp, truss hd cr, control

25 216949709 Cover-evaporator

28 216978201 Hinge, bracket, lower, LH

29 216313501 Hose-drain

* 297001704 Insulation, 24", drain tube

32 5308005500 Drain

34 216979500 Shield-light

34A 297053100 Shield-light, LH

34A 297053101 Shield-light, RH

34B 297053200 Lens, light

35 216629700 Clip

38 216939100 Hinge-upper

40 216809001 Cover-upper hinge, black

41 216936800 Screw-hinge, 12-24x.700 HWH

42 216983101 Glass-shelf, full shelf

42A 297007700 Glass-shelf, sliding

47 297053300 Plate, baffle, snap fit

50 216394000 Bracket, fan motor mount

59 216939300 Basket, (2)

60 297013500 Slide, shelf, (2)

60A 297054200 Slide-basket, RH, (2), w/4 clips

60A 297054201 Slide-basket, LH, (2), w/4 clips

62 131420300 Screw, cr truss head, 8-18AB x 0.750

63 216396900 Screw, leveling foot, plastic, adjustable

71A 5304416289 Screw, ph truss head, 8-18AB x 0.47, EVAP PANEL

72 297036901 Grille/Kickplate, 32", black

79 3017666 Nut-insert

80 06594601 Bracket, control

93 297048000 Screw, anchor, #8, white

93A 216629600 Screw, hex washer head, 10-16 x 0.500, tapping

93B 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming

93D 216912400 Screw, hex washer head, #8-32 x .500, bracket fan mtr, (2)

131 241513001 Channel-shelf mtg, side, (2)

132 5303283898 Screw, 6-20AB x 3/8

Publication No: 5995449815 PLFU1778ES0

09/05 6

CABINET

93A

93D

13 5

42A

139

138

138A

138C

137

137B

139B

15 16

132

P08C0867

28 152

71A 21

155

154 20

93B

22A

15A

34A

15A

16A

34B

131

60A

PLFU1778ES0 Publication No: 5995449815

# Functional Parts 7 09/05

* Non-Illustrated Parts

CABINET

POS. NO PART NO. DESCRIPTION

137 297050600 Frame-shelf, cantilever, (2)

137B 297007600 Frame-shelf, sliding

138 297050700 Trim-shelf, front

138A 216983601 Trim-shelf, side

138C 297007800 Trim-shelf, front

139 297050800 Trim-shelf, rear

139B 297007900 Trim-shelf, rear

152 216974600 Bearing, hinge closer

154 297053000 Wire, jumper

155 5303313703 Clip, (2)

* 216893600 Plug, ICE MAKER, internal

* 216901700 Installation Instructions, icemaker

* 216893800 Cover, external, ICE MAKER, (2)

* 240479601 Plug, button, cab liner holes, (2)

* 297013100 Instructions, water line

* 241586701 Plug-foam-wtr-inlet, round

* 216795408 Energy Guide

Publication No: 5995449815 PLFU1778ES0

09/05 8

SYSTEM

29 27

BACK

136

147

146

50A

107

31A

P08S0393

43A

FRONT

130

15A

PLFU1778ES0 Publication No: 5995449815

# Functional Parts 9 09/05

* Non-Illustrated Parts

SYSTEM

POS. NO PART NO. DESCRIPTION

1 # 5300083897 Condenser

2 5308000110 Strap-evap/heater, aluminum, (2)

4 # 216938600 Drier-filter

5 # 297033600 Harness-main

14 216730700 Heater-defrost

15 # 216737300 Evaporator

15A# 216783200 Heat Exchanger, suct/cap tube

18 216727600 Insulator-evap, styrofoam

19 216727700 Insulator-evap, styrofoam

20 216872200 Thermostat, defrost

22 216970300 Base, condenser

23 216744400 Timer, defrost, 12 hour

24 216968500 Bracket-timer

27 5308002681 Grommet, compressor

29 # 297048100 Compressor, kit w/grommets, & welded clip

30 297051000 Controller, compressor

31A 216994100 Pan-drain

32 297051100 Clamp, elec cont mtg, compressor

34 5306594529 Sleeve-compressor

35 5303272328 Screw, Ind hex sems, 1/4-28 unfx, compressor

43A 216629700 Clip

50A 240524001 Bracket, fan motor mount

58 218897002 Screw, hex washer head, 8-32 x 0.375

60 # 240525401 Motor-condenser fan

61 # 240524101 Fan Blade, galv steel, condenser fan

86 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming

87 08037849 Screw, ph truss head, 6-32(T) x 0.500, thread cutting

107 297001900 Shield, compressor, Compartment

107* 5303161215 Screw, ph truss head, 8-18AB x 0.500

130 216486800 Support, evaporator mtg

136 240405201 Grommet, rubber, black, cond tube/wire

146 216970200 Shroud-fan orfice

147 240560001 Ring-compression

* 216347500 Screw, quadrex, 8-32 x 0.300, grounding

* 216502500 Sleeve, suction line

* 297014500 Plug-suction line

* 5303298960 Spacer-tube, 0.237" ID
