Frigidaire FFU20FK0DW Manual de usuario
Product No. FFU20FK0DW0
Series 134A
Color white
Volts 115
Wiring Diagram 216857700
Owner's Guide 216960000
Market North America
Energy Guide 216795508
P08F0070.eps P08D0385.eps P08C0720.eps P08S0329.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995409850
04/05/12
(EN/SERVICE/MLR)
365
UPRIGHT FREEZER
Model No.
FFU20FK0DW
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.
Publication No: 5995409850 FFU20FK0DW0
05/04 2
DOOR
2
5
1
9
93
26
27
27
P08D0385
32
64
13
21A
22A
14
22
14
11
28
12
18
31
72
73
74
FFU20FK0DW0 Publication No: 5995409850
# Functional Parts 3 05/04
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 216522312 Gasket-door, white
2 5303925107 Lock Assy
5 # 216702900 Key, lock
9 216528113 Panel-inner door, frzr
11 216531200 Panel-outer door, white, white handle
12 216892800 Nameplate
13 08016354 Door Stop
14 5303313518 Washer, sealing
18 216140200 Handle, recessed, white
21A 08005520 Screw, door stop mtg, 4.0 x 0.7-19.7, flat hd, metric
22 216443600 Bearing, hinge, top
22A 216503200 Bearing, hinge, bottom
26 216524200 Gasket, secondary
27 5303212828 Clip, panel mtg
28 216951600 Rack-door, (5)
31 08009392 Gasket, white
32 5309950074 Valve, breather, door base
64 216403700 Plug-button, hole filler, door base
72 216514100 Shelf, tilt out, wire
73 216513900 End Cap, shelf, LH, tilt-out
74 216514000 End Cap, shelf, RH, tilt-out
93 5303161215 Screw, ph truss head, 8-18AB x 0.500
* 5303925098 Insulation
Publication No: 5995409850 FFU20FK0DW0
05/04 4
CABINET
6
26
41 28
9
47
63
14
25
19
18
71A 21
20
93B
80
24
22
42
42A
22A
9
7
P08C0720
93A
93
93
50
13 5
3
32
29
35
16
15
34
132
38
41
40
49 99
62
72
FFU20FK0DW0 Publication No: 5995409850
# Functional Parts 5 05/04
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
3 216503100 Screen-drain
5 # 216325600 Fan Blade
6 216604100 Breaker Kit w/corners
7 216603600 Breaker Kit w/corners, lock catch
9 216603300 Breaker Kit w/corners, 32", top or bottom
13 # 216914200 Motor, fan, 115 V
* 216912400 Screw, hex washer head, #8-32 x .500, bracket fan mtr, (2)
14 216822900 Switch, light/lamp, ramp
15 216846400 Light Bulb/Lamp
16 216817600 Socket, light/lamp, 25 W
18 216707200 Knob, temp control
19 216204901 Gasket-cover evap
20 216230300 Cover, temp control
21 216715200 Control-temperature
22 216823500 Clamp, cap tube, cold control
22A 5303916855 Tube, sensor sleeve, plastic, clear
24 5300052943 Screw-clamp, truss hd cr, control
25 216820300 Cover-evaporator
26 216503300 Ramp, door closer
28 216247400 Hinge, bottom
29 216313500 Hose-drain
32 5308005500 Drain
34 216816200 Shield-light
35 216629700 Clip
38 216939100 Hinge-upper
40 216809000 Cover-hinge
41 216954400 Screw, 12-24 x.700 hwh, hinge mtg.
42 216458400 Shelf, 14.50x27.88, (2)
42A 216458500 Shelf, wire, 16.69x26.88, white, (2)
* 216502400 Grommet-shelf mtg
47 216661600 Plate, baffle, snap fit
49 216937700 Trivet
50 216394000 Bracket, fan motor mount
62 131420300 Screw, cr truss head, 8-18AB x 0.750
63 216396900 Screw, leveling foot, plastic, adjustable
71A 5304416289 Screw, ph truss head, 8-18AB x 0.47, EVAP PANEL
72 216946600 Grille/Kickplate, 32", white
80 06594601 Bracket, control
93 5303161215 Screw, ph truss head, 8-18AB x 0.500
93A 216629600 Screw, hex washer head, 10-16 x 0.500, tapping
93B 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming
132 5303283898 Screw, 6-20AB x 3/8
* 09948773 Insulation, drain tube
* 216795508 Energy Guide
* 5303305324 Paint, touch-up, white
Publication No: 5995409850 FFU20FK0DW0
05/04 6
SYSTEM
FFU20FK0DW0 Publication No: 5995409850
# Functional Parts 7 05/04
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 5300083897 Condenser
2 5308000110 Strap-evap/heater, aluminum, (2)
4 216634500 Drier-filter
5 # 216895800 Harness-main
14 # 216730700 Heater-defrost
15 # 216737300 Evaporator
15A 216783200 Heat Exchanger, suct/cap tube
18 216727600 Insulator-evap, styrofoam
19 216727700 Insulator-evap, styrofoam
20 216731000 Thermostat, defrost
23 # 216744500 Timer-defrost
24 08016580 Bracket
27 5308002681 Grommet, compressor
29 # 216941800 Compressor, w/o electricals
30 # 216649315 Controller
32 216649100 Clamp, elec cont mtg, compressor
34 5306594529 Sleeve-compressor
35 5303272328 Screw, Ind hex sems, 1/4-28 unfx, compressor
43A 216629700 Clip
55 218909913 Capacitor-run, 220 VAC, 15 microfarad
86 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming
87 08037849 Screw, ph truss head, 6-32(T) x 0.500, thread cutting
105 216854000 Cup-drain
130 216486800 Support, evaporator mtg
* 216502500 Sleeve, suction line
* 5303298960 Spacer-tube, 0.237" ID
