IMPORTANT SAFETY INSTRUCTIONS

WARNING

For your safety the following information in this manual must be followed

to minimize the risk of ﬁre or explosion or to prevent property damage,

personal injury or death.

Do not store or use gasoline or other ﬂammable vapors and

liquids in the vicinity of this or any other appliance.

WHAT TO DO IF YOU SMELL GAS:

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in

your building.

• Clear the room, building or area of all occupants.

• Immediately call your gas supplier from a neighbor’s phone.

Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the ﬁre department.

Installation and service must be performed by a qualiﬁed

installer, service agency or the gas supplier.

IMPORTANT SAFETY INSTRUCTIONS

Deﬁnitions

This is the safety alert symbol. It is used to alert

you to potential personal injury hazards. Obey all safety

messages that follow this symbol to avoid possible injury

or death.

Recognize safety symbols, words

and labels

Safety items throughout this manual are labeled with

a WARNING or CAUTION based on the risk type as

described below:

IMPORTANT

IMPORTANT indicates installation, operation or

maintenance information which is important but not

hazard-related.

WARNING

WARNING indicates a potentially hazardous situation

which, if not avoided, could result in death or serious

injury.

WARNING

Please read all instructions before using this dryer.

CAUTION

CAUTION indicates a potentially hazardous situation

which, if not avoided, may result in minor or moderate

injury.

DANGER

DANGER indicates an imminently hazardous situation

which, if not avoided, will result in death or serious

injury.

Save these instructions for future reference.

NOTE

The instructions appearing in this

Use and Care

Guide

are not meant to cover every possible condition

and situation that may occur. Common sense and cau-

tion must be practiced when installing, operating and

maintaining any appliance.

Read all instructions before using this appliance. This

book contains valuable information about:

• Operation

• Care

• Service

Keep it in a safe place.

Model Number _________________________

Serial Number _________________________

Purchase Date _________________________

This

Use and Care Guide

provides general operating

instructions for your dryer. It also contains information

about features for several other models. Your dryer may

not have every feature included.

Use the dryer only as instructed in this

Use & Care

Guide

Product Record

Record Your Model and Serial Numbers

The model and serial numbers of your dryer are found

on the dryer serial plate located inside the door opening.

Record and retain these numbers.

Avoid ﬁre hazard or electrical shock. Do not use an adaptor plug or extension cord or remove grounding

prong from electrical power cord. Failure to follow this warning can cause serious injury, ﬁre or death.

Grounding type

10-30R

3-wire

240 v Electric Dryer

120 v Gas Dryer

14-30R

4-wire

(fused 30 amp)

ll receptacl

ll receptacle

wer cord with

3-prong

ounded plug

Do not,

under

y cir

cumstances,

cut,

remo

ve,

or b

ypass th

UL-approved service

cord must be installed

on electric dryers (not

provided with unit

except those

manufactured for sale

in Canada).

ounding pr

ong.

PREVENT FIRE

• Do not dry items that have been previously cleaned in,

soaked in, or spotted with gasoline, cleaning solvents,

kerosene, waxes, etc. Do not store these items on or

near the dryer. These substances give off vapors that

could ignite or explode.

• Do not place items exposed to cooking oils in your dryer.

Items contaminated with cooking oils may contribute to

a chemical reaction that could cause a load to catch ﬁre.

• Do not dry articles containing rubber, plastic or similar ma-

terials such as bras, galoshes, bath mats, rugs, bibs, baby

pants, plastic bags and pillows that may melt or burn.

Some rubber materials, when heated, can under certain

circumstances produce ﬁre by spontaneous combustion.

• Clean the lint screen before or after each load. The in-

terior of the dryer, lint screen housing and exhaust duct

should be cleaned approximately every 18 months by

qualiﬁed service personnel. An excessive amount of lint

build-up in these areas could result in inefﬁcient drying

and possible ﬁre. See Care and Cleaning.

• Do not operate the dryer if the lint screen is blocked,

damaged or missing. Fire hazard, overheating and

damage to fabrics can occur.

• Do not obstruct the ﬂow of ventilating air. Do not stack

or place laundry or throw rugs against the front or back

of the dryer.

• Do not spray any type of aerosol into, on or near dryer

at any time.

• Do not use fabric softeners or products to eliminate

static unless recommended by the manufacturer of the

fabric softener or product.

• Do not continue to use the dryer is you hear squeaking,

grinding, rubbing or other unusual noises. This could be

a sign of mechanical breakdown and lead to ﬁre or seri-

ous injury. Contact a qualiﬁed technician immediately.

• Failure to comply with these warnings could result in

ﬁre, explosion, serious bodily injury and/or damage to

the rubber or plastic parts of the dryer.

WARNING - RISK OF FIRE

To reduce the risk of ﬁre, electrical shock, or injury to persons when using this dryer, comply with the basic warnings

listed below. Failure to comply with these warnings could result in serious personal injuries.

You can be killed or seriously injured if you don’t follow these Important Safety Instructions:

IMPORTANT SAFETY INSTRUCTIONS

WARNING

FIRE HAZARD

A clothes dryer produces combustible lint. The dryer

must be connected to an outdoors exhaust. Regularly

inspect the outdoor exhaust opening and remove any

accumulation of lint around the opening and in the

surrounding area.

PROTECT CHILDREN

• Do not allow children to play on or in the dryer. Close

supervision of children is necessary when the dryer is

used near children. As children grow, teach them the

proper, safe use of all appliances.

• Destroy the carton, plastic bag and other packing ma-

terials after the dryer is unpacked. Children might use

them for play. Cartons covered with rugs, bedspreads

or plastic sheets can become airtight chambers.

• Keep laundry products out of children’s reach. To pre-

vent personal injury, observe all warnings on product

labels.

• Before the dryer is removed from service or discarded,

remove the dryer door to prevent accidental entrapment.

• Failure to comply with these warnings could result in

serious personal injuries.

PREVENT INJURY

• To prevent shock hazard and assure stability during

operation, the dryer must be installed and electrically

grounded by a qualiﬁed service person in accordance with

local codes. Installation instructions are packed in the

dryer for the installer’s reference. Refer to INSTALLATION

INSTRUCTIONS for detailed grounding procedures. If the

dryer is moved to a new location, have it checked and

reinstalled by a qualiﬁed service person.

• To prevent personal injury or damage to the dryer, the

electrical power cord of a gas dryer must be plugged into

a properly grounded and polarized 3-prong outlet. The

third grounding prong must never be removed. Never

ground the dryer to a gas pipe. Do not use an extension

cord or an adaptor plug.

• ALWAYS disconnect the dryer from the electrical supply

before attempting any service or cleaning. Failure to do so

can result in electrical shock or injury.

• Do not use any type spray cleanser when cleaning dryer

interior. Hazardous fumes or electrical shock could occur.

• To prevent injury, do not reach into the dryer if the drum

is moving. Wait until the dryer has stopped completely

before reaching into the drum.

PREVENT INJURY AND DAMAGE TO THE DRYER

• All repairs and servicing must be performed by an

authorized servicer unless speciﬁcally recommended in

this Owner’s Guide. Use only authorized factory parts.

• Do not tamper with controls.

• Do not sit on, step on or stand on the dryer. Do not

rest heavy loads on top. The dryer is not meant to

support weight.

• Do not install or store the dryer where it will be ex-

posed to the weather.

• A thermal limiter switch automatically turns off the

motor in the unlikely event of an overheated situation

(electric dryers only). A service technician must replace

the thermal limiter switch after correcting the fault.

• Failure to comply with these warnings could result in

serious personal injuries.

IMPORTANT SAFETY INSTRUCTIONS

CAUTION

The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to publish a list of

substances known to the state to cause cancer, birth defects or other reproductive harm, and requires businesses to

warn customer of potential exposure to such substances. Included in this list are soot and carbon monoxide, both of

which may be produced by the use of this product.

FEATURES

*Not all models come with drying rack and

stacking kit from the factory. They may be

purchased as accessories.

Control Lock

LED Display

Drum Light

Exhaust Channel

Outlet

Heavy Duty

Drying Rack*

Reversible Door

Door Latch

Cycle Selector

Door Strike

Lint Filter

Large Surface

Moisture Sensor

Adjustable

Leveling Legs

Stacking Kit for Mounting

on Matching Washer*

OPERATING INSTRUCTIONS

Operating Your Dryer

(Mesh bag not included.)

1 Prepare load for drying.

• Dry items of similar fabric, weight and construction

in the same load.

• Separate dark items from light-colored items. Sepa-

rate items that shed lint from those that attract lint.

• Check for stains which may not have been removed

in washing. Repeat stain removal process and wash

again before drying. Dryer heat may permanently

set some stains.

• Place delicate or small items in a mesh bag.

• Be sure buckles, buttons and trim are heatproof

and won’t damage the drum ﬁnish. Close zippers;

fasten hooks and Velcro®-like fasteners. Tie strings

and sashes to prevent snagging and tangling.

WARNING

To reduce the risk of ﬁre, electric shock or injury to

persons, read the IMPORTANT SAFETY INSTRUCTIONS

in this Use and Care Guide before operating your dryer.

CAUTION

Do not continue to use the dryer if you hear squeaking,

grinding, rubbing or other unusual noises. This could

be a sign of mechanical breakdown and lead to ﬁre or

serious injury. Contact a qualiﬁed technician immediately.

Normal Operating Sounds

You may or may not hear the following sounds from your

new dryer:

A. SUSPENSION ROLLERS The dryer drum is

supported by a set of suspension rollers. At times

there may be a thumping or rolling sound when the

dryer starts. This may happen if the dryer has not

been in use for a period of time, or after a heavy

load has remained in the dryer drum for an extended

period, creating a temporary ﬂat spot on the edge

of the roller. The noise should dissipate as the dryer

operates and the ﬂat spots smooth out.

B. AIR FLOW SYSTEM Your dryer is equipped with a

high volume air handling system. In some installations

there may be some sounds associated with air

movement throughout the dryer, including the air

duct, blower, and exhaust system. This is normal and

can vary with load size and type.

C. GAS VALVE (Gas models only.) The ﬂow of gas is

controlled by electric solenoids. During operation there

may be a clicking sound as the valve opens and closes to

control the gas ﬂow.

D. GAS BURNER (Gas models only.) When the burner

is operating, there may be sounds generated as the

air ﬂow mixes with the gas ﬂame. This noise is normal

and will only occur when the gas is ignited in the

combustion tube.

OPERATING INSTRUCTIONS

2 Check that the lint ﬁlter is

clean and in place.

3 Load the dryer and close the door.

• Load items loosely. The average wet load will

ﬁll the drum 1/3 to 1/2 full. Items need room to

tumble freely for even drying and less wrinkling.

• If desired, place a dryer fabric softener sheet on

top of the load at the beginning of the cycle.

• To save energy and time and avoid uneven drying

and wrinkling, do not overload the dryer.

• When drying large items, dry only two or three

items at a time. Fill out the load with small and

medium sized items.

• For delicate or very small loads, add two or three

similar items to improve tumbling action.

4 Select the appropriate cycle and settings for

each load.

• Adjustments made to a cycle will be remembered

and recalled each time that cycle is selected in the

future.

• Turn the cycle selector knob in either direction to

select the cycle desired.

• The estimated drying time for Auto Dry cycles or

the actual drying time for Timed Dry cycles will be

displayed.

• A suitable drying temperature, dryness level and

options will automatically be indicated for the cycle

selected. See the “Dryer Settings Chart” for more

details.

• To change the drying temperature and dryness

level, press the temp or dry level buttons to scroll

to the desired settings.

• To select or delete an option, press options; then,

while the indicator is blinking, press select. The

indicator will light when the option has been se-

lected. It will no longer be lighted when the option

has been deleted.

Operating Your Dryer, continued

5 Start the cycle.

• Close the door and press START to begin the

cycle. The dryer will not operate with the door

open. To interrupt the cycle, press pause; press

START to resume the cycle. Press cancel to stop

the cycle.

• If changes to the cycle, temperature, dryness level

or options are attempted after the cycle starts, the

lights will blink and a signal will beep.

• To change the cycle once the cycle has begun,

press cancel and select a new cycle. To change

the temperature, dryness level or options once the

cycle has begun, press pause and make the new

selections.

• To add or remove items when the dryer is running,

open the door. The dryer will stop when the door

is opened. Allow the drum to come to a complete

stop before reaching inside.

• Close the door and press START to resume the cycle.

• A signal will sound at the end of the cycle if the

chime option has been selected.

6 When the cycle ends, remove items immedi-

ately and hang or fold.

IMPORTANT

Clean the lint ﬁlter after every load.

CAUTION

Do not operate dryer without

lint ﬁlter in place.

NOTE

If drying a single large or bulky item, such as a

comforter, remove the item part way through the cycle

and turn it “inside out” to maximize drying effectiveness.

Place item back in dryer and re-start cycle.

NOTE

If a setting is not available for the cycle selected, the

indicator will not light.

NOTE

Over-drying can cause wrinkles, shrinkage, lint,

harshness and a build up of static electricity.

To return to factory

settings, press these

two buttons at the

same time and

hold until the signal

sounds.

OPERATING INSTRUCTIONS

This manual covers many models and not all cycles, options, or features listed are available on every model. Consoles shown

above for reference only. Your model may differ.

Turn the cycle selector in either direction to the cycle

desired.

To change the cycle once it has begun, press the cancel

button before selecting a new cycle. Just turning the

cycle selector knob to another selection will not change

the cycle.

Auto Dry Cycles

Auto Dry cycles take the guesswork out of selecting the

correct drying time for each load. Moisture sensing bars

at the back of the dryer drum sense the moisture level of

the load as it tumbles through the heated air. With Auto

Dry cycles, the load will automatically be dried at the

selected temperature to the desired dryness level. Auto

Dry cycles save time and energy and protect fabrics.

The estimated drying time will be displayed for about 5

minutes. Then the outside of the display will light up in a

circular track to indicate the drying time is automatically

being determined by the sensors.

Cycle Selection

When the load has reached the selected dryness level, it

will continue to tumble during a cool down period. This

helps reduce wrinkling and makes items easier to handle

during unloading.

Drying time varies depending on size and dampness of

load and fabric type. If the load is too small or almost

dry, the moisture sensing bars may not detect enough

moisture to continue the cycle and the cycle may end

after a few minutes. If this occurs, select a Timed Dry

cycle.

Room temperature and humidity, type of installation and

electrical voltage or gas pressure can also affect drying

time.

bulky

Select this Auto Dry cycle to dry bedding and bulky

items such as comforters, blankets, sleeping bags and

parkas.

normal

Select this Auto Dry cycle for cotton items.

casual

Select this Auto Dry cycle for cottons and blends with a

no-iron ﬁnish.

Timed Dry Cycles

To manually select the drying time for any load,

turn the knob to a numbered setting: 30, 60, or 90

minutes. Actual drying time will be displayed.

Because this is not an Auto Dry cycle, you will not be

able to select a dryness level. Moisture sensing bars are

not active and dryer will continue to heat throughout

the cycle until the ﬁnal cool down period.

1. initial 2. calculating 3. estimated

Follow the fabric care label

instructions on items

to be dried.

For best results

WARNING

FIRE HAZARD

To avoid ﬁre hazard, do not use heat to dry items

containing feathers or down, foam rubber, plastics

similarly textured, rubber-like materials. Use the Timed

Dry cycle and the Air Dry setting.

OPERATING INSTRUCTIONS

Cycle Options

Dryness Level (Auto Dry)

To change the preset level, press the dry level button to

scroll to the degree of dryness desired.

To protect your fabrics, not all dryness levels are available

with every cycle. If a dry level is not appropriate for the

cycle, it cannot be selected.

The dry level selected for the cycle will be remembered

and recalled each time that cycle is selected in the future.

Select the normal dry level for most Auto Dry cycles.

Occasionally a load may seem too damp or over-dried at

the end of the cycle. To increase drying time for similar

loads in the future, select high. For loads requiring less

drying time, select low.

Select damp for items you wish to partially dry before

hanging or ironing.

To select an option, press options until the indicator

for the desired option ﬂashes, then press select. If an

option is not available for a cycle, the indicator will not

light. Follow the same steps to delete an option. The

options selected for the cycle will be remembered and

recalled each time that cycle is selected in the future.

wrinkle release

Select wrinkle release if the dried load might not

be removed promptly at the end of the cycle. The dry

load will continue tumbling without heat to help reduce

wrinkling. When Chime is selected, a beep will be

heard periodically. The load may be removed any time

during wrinkle release.

chime

A signal will sound at the end of the cycle (and

periodically during wrinkle release) if this option is

selected. The signal has an adjustable volume level or

can be turned off.

Drying Temperature

To change the preset temperature, press the temp

button to scroll to the desired setting.

To protect your fabrics, not all temperatures are available

with every cycle.

The temperature selected for the cycle will be remembered

and recalled each time that cycle is selected in the future.

max

Recommended for durable fabrics and towels.

high

Recommended for most cotton fabrics.

normal

Recommended for wrinkle free, easy care, lightweight

fabrics and bulky loads.

low

Recommended for delicate fabrics.

air dry

This setting (no heat) should only be used with a

Timed Dry cycle to dry items containing feathers,

down, foam rubber, plastics or rubber-like materials;

to refresh clothing, stuffed animal, pillows or blankets;

and to dust draperies.

Cycle Settings

Appropriate drying Temperature, Dryness Level and

Options will automatically be displayed for each cycle.

The settings can be changed before the cycle is started.

Modiﬁcations for each cycle will be remembered and

recalled each time that cycle is selected in the future. If

changes are attempted after the cycle starts, the lights

will blink, the signal will beep and “

Err

” will be displayed.

To return to factory

settings, press these

two buttons at the

same time and

hold until the signal

sounds.

Follow the fabric care label

instructions on items

to be dried.

For best results

NOTE

To change settings after the cycle starts, press pause,

adjust the setting and press START to resume the cycle.

NOTE

To change options after the cycle starts, press pause,

adjust the setting and press START to resume the cycle.
