Frigidaire FPHD2481KF - Professional 24" -Built Instrucciones de instalación

frigidaire.com

24" Built-In

Signature Features

Product Dimensions

Height (Adjustable) 33-1/2"– 35"

Width 24"

Depth (Including Door) 25"

More Easy-To-Use Features

PowerPlus™ Cycle

For an extra-heavy wash performance.

Largest Silverware Basket3

There's room for over 180 items

in our largest, multicompartment

silverware basket.

Energy Saver Plus Cycle

Eco-friendly cycle uses less energy

without compromising cleaning

performance.

DishSense™ Technology

Sensors select the cycle for you

based on your cleaning needs.

Quick Clean

Clean dishes faster with Quick Clean.

Pro-Select™ Controls

Easily select options with the touch

of a button.

Professional / Solid Dish Racks

Adjustable Upper Dish Rack

Flexible racking system lets you adjust

the top rack to fit taller items.

Stay-Put Door

The door stays put at whatever

angle you open it.

Most Adaptable Delay Start

1- to 24-hour options.

Low-Rinse Aid Indicator

ENERGY STAR®

NSF® International

Certiﬁcation

Available in:

Based on industry standard dryability testing

using PowerPlus™ Dry.

2 Based on published manufacturer speciﬁcations

for plastic interior dishwashers.

3 Among leading brands.

Stainless

(F)

Quietest Dishwasher

in Its Class2

A quiet performance every time.

Best Drying Performance1

Our PowerPlus™ dry cycle offers the

best drying performance.1

Real Stainless Steel

Real stainless steel with a protective

coating that reduces fingerprints and

smudges so it’s easy to clean.

SpaceWise™

Organization System

Our SpaceWise™ Organization system

features adjustable racks and the

Largest Silverware Basket3so there’s

a place for virtually anything.

Dishwasher

FPHD2481K F

Specifications

subject to change.

Accessories information available

on the web at frigidaire.com

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Dishwasher

FPHD2481K F 24" Built-In

Product Dimensions

A - Height (Adjustable)

B - Width

C - Depth (Including Door)

D - Depth (To Tub Flange)

Depth with Door Open 90˚

33-1/2"– 35"

24"

25"

22-1/2"

49-1/4"

Cutout Dimensions

Height (Min.)

Height (Max.)

Width (Min.)

Depth (Min.)

34-1/4"

35-1/4"

24"

NOTE: For planning purposes only. Always consult local and national electric and plumbing codes.

Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.

24" Built-In Dishwashers with Integrated Controls

Frigidaire Professional

Meets requirements

of ASSE 1006

1 For use on adequately wired 120V, dedicated circuit having 2-wire service

with a separate ground wire. Appliance must be grounded for safe operation.

Features

Control Design

Digital Display

Door Latch / Stay-Put Door Hinge Design

Low Rinse-Aid Indicator Light

Interior Design / Interior Color

Wash System

Wash Levels / Wash Speeds

DishSense™ Technology

Sound Package

Filter / Filter Trap

Soft Food Disposer

dB Level

Drying System

Cycles

Number of Cycles

Heavy

Normal

Light

Quick

Favorite

China Crystal

Rinse Only

Energy Saver Plus

Upper Rack Wash Only

Cycle Indicator Light / Control Lock

Options

Heat / No Heat Dry

Hi-Temp Wash

NSF® Certiﬁed Sanitize Rinse

Delay Start

Rack System

Rack Design

Rack Coating

Upper Rack –

Rack Handles

Stemware / Champagne Glass Holders

Fold-Down Tines

Cup Shelves

Utensil Tray

Adjustable Rack Height

Lower Rack –

SpaceWise™ Silverware Basket

Fold-Down Tines

Small Items Cover

Certiﬁcations

ENERGY STAR®

NSF® International Certiﬁcation

Speciﬁcations

Water Inlet Location

Water Usage (Gallons)

Water Pressure (PSI)

Integral Air Gap on Supply

Leveling Legs

Power Supply Connection Location

Voltage Rating

Connected Load (kW Rating) @ 120 Volts 1

Amps @ 120 Volts

Shipping Weight (Approx.)

Fully-Integrated

Pro-Select™

Yes

Yes / Yes

Yes

Tall Tub / GraniteGrey™

Direct

5 / 5

Yes

SilentDesign™

S. Steel / Removable

Yes

PowerPlus™ Dry

Yes

No / Yes

Yes

1–24 Hour

Maximum

Nylon TufRacks™

Yes

3-Piece Split

2 Full Rows

Yes

Left Bottom Front

4.9 – 8.5

20 – 120

Yes

Right Bottom Front

120V / 60 Hz / 15A

1.44
