Frigidaire FGC30S4D Manual de usuario

FGC30S4DC.eps LA9922T15-1.eps LA00BR77490-1.eps 318047105.eps

318047111.eps

Product No. FGC30S4DCA FGC30S4DCB

37754262740S1 37754262740S2

Series 30" gas 30" gas

Color stainless stainless

Market North America North America

Wiring Diagram 318047105 318047111

Owner's Guide 318200657 318200657

Installation Instructions 318201451 318201451

ELECTROLUX HOME PRODUCTS, INC.

P.O. Box 212378, Augusta, GA 30917

Publication No.

5995417598

04/10/01

(EN/SERVICE/ECL)

377

GAS COOK-TOP

RANGE

Model No.

FGC30S4D

Publication No: 5995417598 FGC30S4D

10/04 2

COOK TOP

FGC30S4D Publication No: 5995417598

# Functional Parts 3 10/04

* Non-Illustrated Parts

COOK TOP

Model Index: AFGC30S4D (FGC30S4DCA)

BFGC30S4D (FGC30S4DCB)

POS. NO PART NO. DESCRIPTION

16 318191520 A B Main Top, stainless

19 318167903 A B Pan, burner, medium, black

19A 318167904 A B Pan, burner, large, black

19B 318167905 A B Pan, burner, small, black

20 318227002 A B Grate, burner, black, (4)

22 318076410 A B Cap, burner, black, medium LF & LR

22A 318076420 A B Cap, burner, black, large RF

22B 318076400 A B Cap, burner, black, small RR

43 318196141 A B Knob, control, black

46 318156000 A B Burner Box

47 318144002 A B Cord, Service

64 5303304033 A B Bracket, retainer

65 5303304032 A B Seal, rubber

132 3201437 A B Strain relief

136 5303935029 A B Support

137 5303285443 A B Screw, lock bracket, 10-24 x 2.00

* 318163602 A B Cleaner, stainless steel

* 5303307980 A B Screw, 8-32 x 0.437

Publication No: 5995417598 FGC30S4D

10/04 4

BURNER

FGC30S4D Publication No: 5995417598

# Functional Parts 5 10/04

* Non-Illustrated Parts

BURNER

Model Index: AFGC30S4D (FGC30S4DCA)

BFGC30S4D (FGC30S4DCB)

POS. NO PART NO. DESCRIPTION

1 318177003 A B Manifold Pipe

* 08011955 A B Screw, 10-24 x 0.375, square drive

2 # 318087040 A B Valve, top burner, 13000 BTU

2A # 318087001 A B Valve, top burner, 5000 BTU

2B # 5303935042 A B Valve, top burner, 2-position, 9100 BTU

3 # 316032002 A - Switch, ignitor

3 # 318232604 - B Wiring Harness, w/igntr switch

4 # 318167714 A B Tube, burner, RF

5 # 318167700 A B Tube, burner, LF

6 # 318167702 A B Tube, burner, RR

7 # 318167701 A B Tube, burner, LR

8 # 316135701 A B Module, spark

10 # 318148001 A B Burner, top, 9100 BTU, medium LF & LR

10A# 318148002 A B Burner, top, 13000 BTU, large RF

10B# 318148000 A B Burner, top, 5000 BTU, small RR

14 # 5308007974 A B Regulator, pressure

35 318146300 A B Bushing

72 5303323141 A B Screw, valve mtg, 1/4-20 x 5/16

73 318024201 A B Bracket, spark module

74 # 318148700 A B Ignitor, top burner

75 318148800 A B Clip, electrode

76 # 318167801 A B Tube, mixing, medium & large

76A# 318167800 A B Tube, mixing, small

77 318112010 A B Bracket, burner mtg, medium & large

77A 318112000 A B Bracket, burner mtg, small

77B 318180900 A B Bracket, burner tube

78 318220100 A B Shield, burner box

* 318232400 A - Harness, wiring

* 318199729 - B Wiring Harness, ignitor

* # 318127407 A B LP Conversion Kit

* 5303311532 A B Screw, 6-32 x 1/4", back

* 5304403558 A B Screw, 10-16 x 0.250

Publication No: 5995417598 FGC30S4D

10/04 6

WIRING DIAGRAM FGC30S4DCA

FGC30S4D Publication No: 5995417598

# Functional Parts 7 10/04

* Non-Illustrated Parts

WIRING DIAGRAM FGC30S4DCB
