Fridgemaster MC55274AFS/SA Instrucciones de funcionamiento
MC55274AFS/SA
MC55274AF/SA
Children aged from 3 to 8 years are allowed to load and
unload refrigerating appliances.
Contents
2
For your safety and correct usage, before installing and first
using the appliance, read this user manual carefully, including
its hints and warnings. To avoid unnecessary mistakes and
accidents, it is important to make sure that all people using the
appliance are thoroughly familiar with its
operation and safety features. Save these instructions and be
sure that they remain with the appliance if it is moved or sold,
so that anyone using it throughout its life, will be properly
informed on its usage and safety notices.
For the safety of life and property, keep the precautions of
these user's instructions as the manufacturer is not
responsible for damages caused by omission.
Safety for children and others who are vulnerable people
According to EN standard
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
According to IEC standard
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
Safety and warning information…........2
Installing your new appliance………....8
Description of the appliance.................9
Reversing the door............…..........10
Operation.............……….…...............13
Using your appliance.…….…..........14
Helpful hints and tips……….…........15
Cleaning and care.....……………….16
Troubleshooting......…………………18
Disposal of the appliance. ......…..…19
Children should be supervised to ensure that they do not
play with the appliance.
3
Keep all packaging away from children as there is risk of
suffocation.
If you are discarding the appliance, pull the plug out of the
socket, cut the connection cable (as close to the appliance
as you can) and remove the door to prevent children playing
from suffering an electric shock or from closing themselves
inside it.
If this appliance, featuring a magnetic door seals, is to
replace an older appliance having a spring lock (latch) on the
door or lid, be sure to make the spring lock unusable before
you discard the old appliance. This will prevent it from
becoming a death trap for a child.
General safety
WARNING —This appliance is intended to be used in
household and similar applications such as
-staff kitchen areas in shops, offices and other working
environments;
-farm houses and by clients in hotels, motels and other
residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
WARNING — Do not store explosive substances such as
aerosol cans with a flammable propellant in this appliance.
WARNING — If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
WARNING — Keep ventilation opening, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING — Do not use mechanical devices or other
means to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING — Do not damage the refrigerant circuit.
WARNING — Do not use electrical appliances inside the
food storage compartments of the appliance, unless they are
of the type recommended by the manufacturer.
use of the appliance by a person responsible for their safety.
WARNING ―Food needs to be packed in bags before
putting into the refrigerator, and liquids need to be packed
in bottles or capped containers to avoid the problem that
the product design structure is not easy to clean.
The symbol is a warning and indicates the
refrigerant and insulation blowing gas are flammable.
Warning: Risk of fire / flammable materials
4
WARNING — The refrigerant and insulation blowing gas are
flammable. When disposing of the appliance, do so only at
an authorized waste disposal centre. Do not expose to
flame.
WARNING —When positioning the appliance, ensure the
supply cord is not trapped or damaged.
WARNING —Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the appliance.
Refrigerant
The refrigerant isobutene (R600a) is contained within the
refrigerant circuit of the appliance, a natural gas with a high
level of environmental compatibility, which is nevertheless
flammable. During transportation and installation of the
appliance, ensure that none of the components of the
refrigerant circuit becomes damaged.
The refrigerant (R600a) is flammable.
If the refrigerant circuit should be damaged:
WARNING — Refrigerators contain refrigerant and gases in
the insulation. Refrigerant and gases must be disposed of
professionally as they may cause eye injuries or ignition.
Ensure that tubing of the refrigerant circuit is not damage
prior to proper disposal.
Replacing the illuminating lamps
WARNING—The illuminating lamps must not be replaced by
the user! If the illuminating lamps is damaged, contact the
customer helpline for assistance.
This warning is only for refrigerators that contain illuminating
lamps.
5
Daily use
Do not store flammable gases or liquids in the appliance,
There is a risk of an explosion.
Do not operate any electrical appliances in the appliance
(e.g.electric ice cream makers,mixers etc.).
When unplugging always pull the plug from the mains
socket,do not pull on the cable.
Do not place hot items near the plastic components of this
appliance.
Electrical safety
1.The power cord must not be lengthened.
2. Make sure that the power plug is not crushed or damaged.
A crushed or damaged power plug may overheat and cause a
fire.
3. Make sure that you can access the main plug of the
appliance.
4. Do not pull the main cable.
5. If the power plug socket is loose, do not insert the power
plug. There is a risk of electric shock or fire.
6.You must not operate the appliance without the interior
lighting lamp cover.
7.The fridge is only applied with power supply of single phase
alternating current of 220~240V/50Hz. If fluctuation of voltage
in the district of user is so large that the voltage exceeds the
above scope, for safety sake, be sure to apply A.C. automatic
voltage regulator of more than 350W to the fridge. The fridge
must employ a special power socket instead of common one
with other electric appliances. Its plug must match the socket
with ground wire.
It is dangerous to alter the specifications or modify this
product in any way.
Any damage to the cord may cause a short circuit, fire, and/or
electric shock.
-Avoid opening flames and sources of ignition.
-Thoroughly ventilate the room in which the appliance is
situated.
6
Do not place food products directly against the air outlet on
the rear wall.
Store pre-packed frozen food in accordance with the frozen
food manufacture’s instructions.
The appliances manufactures storage recommendations
should be strictly adhered to relevant instructions for
storage.
Do not place carbonated or fizzy drinks in the freeze
compartment as it creates pressure on the container,which
may cause it to explode,resulting in damage to the
appliance.
Frozen food can cause frost burns if consumed straight from
the freezer compartment.
Do not place the appliance in direct sunlight.
Keep buring candles,lamps and other items with naked
flames away from the appliance so that do not set the
appliance on fire.
The appliance is intended for keeping food stuff and/or
beverages in normal household as explained in this
instruction booklet. The appliance is heavy.Care should be
taken when moving it.
Do not remove nor touch items from the freezer
compartment if your hands are damp/wet,as this could cause
skin abrasions or frost/freezer burns.
Never use the base,drawers, doors etc. to stand on or as
supports.
Frozen food must not be refrozen once it has been thawed
out.
Do not consume ice popsicles or ice cubes straight from
the freezer as this can cause freezer burn to the mouth
and lips.
To avoid items falling and causing injury or damage to
the appliance, do not overload the door racks or put too
much food in the crisper drawers.
This refrigerating appliance is not intended to be used as
●
a built-in appliance.
7
Adequate air circulation should be around the appliance,
lacking this leads to overheating. To achieve sufficient
ventilation, follow the instructions relevant to installation.
Wherever possible, the back of the product should not be too
close to a wall to avoid touching or catching warm parts
(compressor, condenser) to prevent the risk of a fire, follow
the instructions relevant to installation.
The appliance must not be located close to radiators or
cookers.
Make sure that the mains plug is accessible after the
installation of the appliance.
Service
Any electrical work required to do the servicing of the
appliance should be carried out by qualified electrician or
competent person.
This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used.
1)If the appliance is Frost Free.
2)If the appliance contains freezer compartment.
Installation Important!
For electrical connection carefully, follow the instructions
given in this manual.
Unpack the appliance and check if there are damages on it.
Do not connect the appliance if it is damaged. Report
possible damages immediately to the place you bought it. In
this case retain packing.
It is advisable to wait at least four hours before connecting
the appliance to allow the oil to flow back in the compressor.
Before maintenance, switch off the appliance and disconnect
the mains plug from the mains socket.
Do not clean the appliance with metal objects, steam
cleaner, ethereal oils, organic solvents or abrasive cleansers.
Do not use sharp objects to remove frost from the appliance.
Use a plastic scraper.
Caution!
Care and cleaning
8
869
In order to improve efficiency
of the cooling system and save
energy, it is necessary to maintain
good ventilation around the appliance
for the dissipation of heat. For this
reason, sufficient clear space should
be available around the refrigerator.
Suggest :It is advisable for there to be
50-70mm of space from the back to
the wall, at least 100mm from its top,at
last 100mm from its side to the wall
and a clear space in front to allow the
doors to open 12 °. As shown in 5
following diagrams.
≥100
1068
≥100
50
-70mm
566
125°
This appliance performs wellfrom N
to ST.
The appliance may not work properly
if it is left for a longer period at a
temperature above or below the
indicated range.
50~70
9
Description of the appliance
Note: To get the best energy efficiency of this product, please place all shelves,
drawers on their original position as the illustration above.
View of the appliance
1.Refrigerator lamp
2.Door switch
3.Shelf
4.Vegetable drawer cover
5.Vegetable drawer
6.Freezer upper drawer
7.Freezer lower drawer
8.Adjustable foot
9.Egg rack(inside)
10.Upper rack
11.Refrigerator door
12.Lower rack
13.Freezer door
Freezer
Fridge
Reversing the door
Remove the door shelf
press
inwardly
2.Stand the refrigerator upright, first
unscrew the screw① by a cross-
shaped screwdriver, and remove the
upper hinge cover② which is at the
top right corner of the refrigerator,
and use a putty knife or thin-blade
screwdriver to prize the crew hole
cover③ which is at the top left corner
of the refrigerator.
3.Unscrew the flange screws①
which are used for fixing the right
upper hinge part② by a 8mm socket
wrench.
Note:
hand during step 3 to prevent door
dropping.
4. Remove the upper door and place
it on a smooth surface with its panel
upwards. Loose screws② , detach
part①, then install part① to the left
side with screws②.
5. Loose screws used to fix the
middle hinge and remove middle
hinge. Then remove the lower door.
Please hold the upper door by
10
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Refrigerador de Fridgemaster
Fridgemaster
Fridgemaster MUR49100 Manual de usuario
Fridgemaster
Fridgemaster MBUR60121MF Manual de usuario
Fridgemaster
Fridgemaster MS91515DFF Instrucciones de funcionamiento
Fridgemaster
Fridgemaster MTL55249 Manual de usuario
Fridgemaster
Fridgemaster MTRR102A Manual de usuario
Fridgemaster
Fridgemaster MC55264DS Manual de usuario
Fridgemaster
Fridgemaster MBUL60133 Manual de usuario
Fridgemaster
Fridgemaster MBC55249 Instrucciones de funcionamiento
Fridgemaster
Fridgemaster MUR4892 Manual de usuario
Fridgemaster
Fridgemaster MUL4892MF Instrucciones de funcionamiento
Fridgemaster
Fridgemaster MTM48120R Manual de usuario
Fridgemaster
Fridgemaster MS91518FFS Instrucciones de funcionamiento
Fridgemaster
Fridgemaster MTTR4442 Manual de usuario
Fridgemaster
Fridgemaster MC60283DFFB Manual de usuario
Fridgemaster
Fridgemaster MC55210S Manual de usuario
Fridgemaster
Fridgemaster MBC54242F Instrucciones de funcionamiento
Fridgemaster
Fridgemaster MC55224D Manual de usuario
Fridgemaster
Fridgemaster MUR4996 Manual de usuario
Fridgemaster
Fridgemaster MC55174FF Manual de usuario
Fridgemaster
Fridgemaster MUL55137 Manual de usuario
