Freecom Mobile Drive II Manual de usuario

Rev. 902

USER MANUAL

MOBILE DRIVE II

EXTERNAL MOBILE HARD DRIVE / 2.5" / USB 2.0

Freecom Mobile Drive II

Dear user!

Thank you for choosing the Freecom Mobile Drive II as an external hard drive. For

optimal use and performance we advise you to read this manual carefully before using

this product.

Freecom Technologies • Germany

www.freecom.com

Contents of the box

Please check the contents of the box; the following items should be included:

•external Freecom Mobile Drive II*

• Data cable (USB 2.0)

•Manual, safety manual and application software pre-installed on the hard drive

•Quick Install Guide

* Operation without power pack possible, power supply occurs over the USB port.

When the power provided by the USB port is not sufficient, visit www.freecom.com/support for an optional

AC adapter.

Warning !

purposes and may be trademarks or registered trademarks of the respective companies.

This device was designed for home or office use.

Warning! This device is equipment complying with EN55022 class A. This equipment can

cause radio disturbances in a residential area. If this is the case, the user has to take ap-

propriate measures and assume all responsibility and costs for. It may not be used near

or with any life-sustaining systems.

Freecom cannot be made liable for any damages, loss of data or damage following thereof

-whatsoever (including, without limitation, damages for loss of business profits, business

interruption, loss of business information, or other pecuniary loss) arising out of the use

of or inability to use this Freecom product, even if Freecom has been advised of the pos-

sibility of such damages.

We reserve the right to upgrade our products in keeping with technological advances.

User manual

General Information ...........................................................................................................page 4

Precautionary measures....................................................................................................page 5

Freecom Mobile Drive II ...................................................................................................page 6

Chapter 1:

Hardware Installation.........................................................................................................page 7

Chapter 2:

Driver Installation ................................................................................................................page 7

Chapter 3:

Installation of the application software ......................................................................page 8

Chapter 4:

Freecom Hard Drive Protection Tool ...........................................................................page 10

Chapter 5:

Using Freecom Turbo USB 2.0 (only PC) .....................................................................page 19

Chapter 6:

Partitioning your Freecom Mobile Drive II ................................................................page 20

Table of Contents

Freecom Mobile Drive II

* To achieve optimal performance from the Freecom Mobile Drive II your PC should be equipped with an USB

2.0 port.

General Information

The following hardware and software requirements must be fulfilled to ensure trouble-

free operation.

System requirements

In order to use the Freecom Mobile Drive II, following components are needed:

PC:

• Intel Pentium III / AMD Duron 900 MHz or higher

• 256 MB RAM (Vista: 512 MB RAM) or higher

• Available USB 2.0 or USB 1.1 port*

• Internet connection for online warranty registration and software updates and

downloads

•Operating system: Windows 2000, Windows XP, Windows Vista

Mac:

• PowerPC G3/G4/G5, Mac Book Pro or Intel Mac

• 256 MB RAM or higher

• Available USB 2.0 or USB 1.1 port*

• Internet connection for online warranty registration and software updates and

downloads

•Operating system: Mac OS X v10.4 or higher

General Information

Precautionary measures

To ensure that your Freecom Mobile Drive II functions properly, please take note of the

following precautions. If these are not followed, you may void your warranty and dam-

age the Freecom Mobile Drive II.

• Safely remove the Freecom Mobile Drive II via your operating system (the "unplug or

eject hardware" option in the Windows taskbar) before disconnecting the USB cable

or power cable and before switching off the device. Failing to do so may result in data

loss.

•Do not drop the Freecom Mobile Drive II or expose it to other kinds of sudden me-

chanical shocks as this may result in data loss and damage to the Freecom Mobile

Drive II.

•Do not use the Freecom Mobile Drive II when the ambient temperature is below 10°C

or above 35°C.

•If the Freecom Mobile Drive II is moved from a cool environment to a warmer envi-

ronment, please allow the drive to acclimatize to the ambient temperature before

operating the device. Failing to do so may lead to condensation within the drive

enclosure, which in turn may cause the drive to malfunction.

•Do not place liquids or drinks on the Freecom Mobile Drive II. When liquids are spilled

and get in contact with the electronics within the drive enclosure, it will damage the

drive and will cause the drive to malfunction.

•Do not use the Freecom Mobile Drive II in a dusty environment. Dust inside the

enclosure may damage the internal electronics and result in drive malfunction.

•Opening the Freecom Mobile Drive II will void the warranty.

• Since USB 2.0 is backwards compatible with USB 1.1, the Freecom Mobile Drive II

can be connected to all USB ports. When connected to a USB 1.1 port, however, the

performance (data transfer rate) of the Freecom Mobile Drive II will be much lower

than when the drive is connected to a USB 2.0 port.

On some computers it might occur that the USB port does not deliver enough

power to the Mobile Drive II. In that case, you need to use an external power

supply.

For safety reasons you must only use Freecom’s Power Supply Part.No. 30921.

Don’t use any other power supply!

Freecom Mobile Drive II

The hi-speed data transfer through the USB 2.0 interface makes it ideally suitable for

data-storage, file sharing, backup, archiving, audio playback and all applications that

need fast file access.

For your convenience, the Freecom Mobile Drive II has been partitioned (1 partition) and

pre-formatted (FAT32 file system). The FAT32formatensures maximum interchangeabil-

ity of the Freecom Mobile Drive II between different computers. Should you choose to

format the Freecom Mobile Drive II in another file system (e.g. NTFS), please be aware of

possible problems when connecting the Freecom Mobile Drive II to another computer

than the one you used for formatting.

Hardware Installation

Chapter 1: Hardware Installation

1. Connect the USB cable to the Freecom Mobile Drive II.

2. Plug the cable into the USB port on your computer.

Since USB 2.0 is backwards compatible with USB 1.1, the Freecom Mo-

bile Drive II can be connected to all USB ports. When connected to a USB

1.1 port, however, the performance (data transfer rate) of the Freecom

Mobile Drive II will be much lower than when the drive is connected to

a USB 2.0 port.

On some computers it might occur that the USB port does not deliver

enough power to the Mobile Drive II. In that case, you need to use an

external power supply.

For safety reasons you must only use Freecom’s Power Supply Part.No.

30921. Don’t use any other power supply!

Chapter 2: Driver Installation

Under Windows 2000 / XP / Vista and Mac OS X a separate Freecom driver is not required.

The drivers will be installed automatically by the operating system after plugging in the

Freecom Mobile Drive II into the USB port of the computer.

Freecom Mobile Drive II

Chapter 3: Installation of the application software

3.1 Installation software PC

1. Click on"StartPC.exe" in themain directory ofthe hard drive.TheFreecom start menu

opens.

2. Click on "Software Installation" -> "NTI Shadow", "NTI Ripper" or other software. The

installation starts now. Follow the instructions on the screen, confirm with "Next" in

order to continue with the installation.

3.1.1 Saving Freecom data

The user manuals and complementary software (when applicable) are pre-loaded

onto the hard drive. We recommend that you save these files to your computer ("My

Documents"/"Freecom"), to always have a backupof these files incase you (accidentally)

reformat the drive or delete these files from the drive.

Saving these files from the external hard drive to your computer is easy:

1. Click on the button „Save Freecom files“.

2. All provided data on the Freecom hard drive will be saved to the folder "Freecom" in

"My Documents".

Installation of the application software

3.2 Installation software Mac

1. Click on "Start MAC" in the main directory of the hard drive. The Freecom start menu

opens.

2. Click on "Install NTI Shadow". The installation starts now. Follow the instructions on

the screen, confirm with "Next" in order to continue with the installation.

3.2.1 Saving Freecom data

The user manuals and complementary software (when applicable) are pre-loaded onto

theharddrive.Werecommendthatyousave these filestoyourcomputer("Documents"/

"Freecom"), to always have a backup of these files in case you (accidentally) reformat

the drive or delete these files from the drive.

Saving these files from the external hard drive to your computer is easy:

1. Click on the button "Save Freecom files".

2. All provided data on the Freecom hard drive will be saved to the folder "Freecom" in

"Documents".

Freecom Mobile Drive II

Chapter 4: Freecom Hard Drive Protection Tool

4.1 Using the Freecom Hard Drive Protection Tool (PC)

Your Freecom Mobile Drive II is equipped with a password protection feature. This pro-

vides the best possible protection. Your data is always protected, even if the internal

hard drive is taken out of the enclosure and connected to a computer, you still will not

be able to access the data.

If your PC is shut down or sent to hibernation, we recommend to completely disconnect-

ing the Mobile Drive II from your PC in order to reactivate the password protection. Some

PCs keep USB devices supplied with power when being in hibernation mode, therefore

you remain logged in with your password.

4.1.1 Configuring the password protection

1. Connectyour FreecomMobile Drive II toyour PC. A HardDisk Drive (“FREECOMHDD”)

and a Virtual CD-ROM Drive (“Password”) will appear in “My Computer”.

The Virtual CD-ROM Drive is an undeletable partition on your Mobile Drive II on

which the Freecom Hard Drive Protection software is stored. This ensures that you

always have the password protection application available when needed, it can not

be accidentally deleted.

2. If the virtual CD-ROM drive does not automatically open after the harddrivehas been

connected, double-click on the virtual CD ROM drive icon (“Password”) to open it.
