Foxfury Lighting Solutions TAKER R40 Manual de usuario
PRODUCT MANUAL
700-331
TAKER R40
2
TABLE OF CONTENTS
INTRODUCTION
Taker R40 Reference Guide 3
Overview 4
Physical Characteristics & Warnings 4
POWER PACK
Charging the Power Pack 5
Reassembling the Taker R40 after Charging 6
Power Pack Life 6
OPERATION
Operational Modes 6
SHIELD INSTALLATION
Removing the Adaptor Shroud 7
Riot Shield Installation with Bolts 8
Riot Shield Installation with 3M Reclosable Fastener 9
Capture Shield Installation 10
Drilling Template 15
MAINTENANCE
Replacing the O-Ring 11
Removing the Guards 11
WARRANTY 12–13
CONTACT FOXFURY 13
3
FULL ASSEMBLY
(TOP VIEW—POWER/MODE SWITCH VISIBLE)
DISASSEMBLED
POWER PACK
DISASSEMBLED
LIGHT HEAD
POWER/MODE
SWITCH
ADAPTOR
SHROUD
M6 BOLT
HOLES (2)
POWER PACK
BOLT (2)
CHARGE
INDICATOR
LED
CAPTURE ADAPTOR
POWER CONTACTS
USB
CHARGE
PORT
LOCKING
POST
LED CONTACT
CAVITY (2)
“O”-RING
ACCESS SCREW
LED MODULE
SCREW HOLE (4)
TAKER R40 REFERENCE GUIDE
4
WARNINGS
When used for extended periods of time the R40 will become HOT to the
touch.
Do not stare into the LEDs for long periods of time or from a close range
(less than 2 ft (.06 m)).
FoxFury’s Turbo-Strobe™is purposely designed to induce disorientation.
Prolonged viewing may produce vertigo or even vomiting.
While using any FoxFury product, please operate at safe speeds.
Be sure to rinse the Taker R40 with fresh water immediately after use if
product has been subjected to chemicals or saltwater.
OVERVIEW
The Taker R40 is a compact and powerful LED Light, the first of its kind,
which has the ability to be fastened to a riot or capture shield, held by
hardware or with industrial-strength Reclosable fasteners. Mounted to the
inside of the shield, it prevents the light from being grabbed by the opposing
force, and gaining control of the shield. Having two different intensities
(650 Lumens on HIGH, and Turbo-Strobe™), makes it a powerful tool for LE,
Corrections, and the Military. A Charge Indicator and Quick Swap™Power Pack
makes the Taker R40,patents pending,unequaled in the field.
IMPORTANT!
PHYSICAL CHARACTERISTICS
Please read below before using your Taker R40 as it relays beneficial
operating and safety information.
TAKER R40
DIMENSIONS 2.6 x 2.4 x 3.8 in (66 x 60 x 97 mm)
WEIGHT 7.3 oz (206 g) with Power Pack and Light Head
2.4 oz (69 g) Power Pack
!
!
!
!
Please fully charge the Power Pack before using the Taker R40 for the first
time.
5
CHARGING THE POWER PACK
1. Press and hold the Power Pack Release Lever located on the Light Head
portion of the Taker R40.
2. While maintaining pressure on the Power Pack Release Lever, pull the Light
Head and the Power Pack apart.
If unable to pull apart easily (due to resistance of the internal rubber
gasket), try moving the Power Pack back and forth while pulling apart.
NOTE: Once apart, be sure to keep both ends dry and away from
water, moisture and dust. While the Power Pack and Light Head are
separated, the unit DOES NOT maintain its waterproof rating.
3. Insert the provided Micro USB Cable into the Power Pack— respect the
orientation/alignment. Then, insert the opposite end, USB (Type A) into a
USB compatible power source or into the included AC/DC Adaptor.
(Input: 100V–240VAC 50/60 Hz, Output: 5V DC 1000mAH).
The Charge Indicator will be solid red while charging. Once fully
charged, it will turn green.
Charging time will be approximately 2.5 hours.
After the Power Pack is charged, disconnect it from USB Cable.
IMPORTANT: The R40 in steps 1–3 is shown without the Adaptor Shroud and
is flipped to show the Power Pack Release Lever. The R40 does NOT need to
be removed from the Adaptor Shroud to change Power Packs.
1
1
2
3
2
3
6
REASSEMBLING THE R40 AFTER CHARGING
1. Install the Power Pack to the Light Head—confirm position of alignment
posts to their respected cavities.
2. Push both halves together. A ‘click’ should be heard as they become
locked together.
Test the light to make sure that the Power Pack is properly connected
to the Light Head by pressing the Power/Mode Switch.
POWER PACK LIFE
MODE POWER PACK LIFE LUMENS
CONTINUOUS ON 1 hour 650
TURBO-STROBE™ 1.75 hours 650
*Power Pack life may vary according to age and ambient conditions.
1
2
OPERATIONAL MODES
For CONTINUOUS ON mode: Press and hold the Power/Mode Switch
once.
For TURBO-STROBE™ mode: From CONTINUOUS ON mode, press the
Power/Mode Switch once.
For OFF or EXIT a mode: From TURBO-STROBE™ mode, press the
Power/Mode Switch once.
LOW POWER INDICATOR*: At a low level, the Charge Indicator will flash
for approximately 0.5–1.0 sec. It is suggested that you then charge or
replace the Power Pack with a fully charged one.
NOTE: Once the LOW POWER INDICATOR comes on, there is approximately
1–2 minutes of power remaining.
7
REMOVING THE ADAPTOR SHROUD
1. Begin with the R40 in the "Top View" (positioned the same as the "Full
Assembly" diagram on pg. 3) and locate the two (2) pre-installed bolts (
and ) on the top of the Light Head. Then position the R40 into the "Side
View," and re-locate the two (2) pre-installed bolts.
2. While still in the "Side View," use a small adjustable wrench to hold the
bottom nut of one (1) of the bolts. Then, while still holding the wrench, use
the provided Hex Key (2.5 mm AF) to loosen the top of the bolt by turning
counter-clockwise, until it comes off completely. Repeat this step again for
the second bolt.
3. Once both bolts are loose, the R40 can be removed from the Adaptor
Shroud by pulling it forward and off.
FOR REINSTALLATION: Repeat the steps above in reverse order.
1
2
2
3
3
1A
B
TOP VIEW SIDE VIEW
A
B
8
RIOT SHIELD INSTALLATION
1. Drill two (2) holes in the riot shield using the included Drilling Template on
pg. 15.
2. Assemble the R40 light to the Adaptor Shroud then place the light against
the INSIDE of the riot shield.
3. Use a Phillips head screwdriver and crescent wrench to install and secure
the R40 to the inside of the riot shield using the supplied hardware (M6
bolt, washers, and nuts).
NOTE: Be careful not to overtighten the bolts!
INSTALLING THE R40 TO A RIOT SHIELD USING BOLTS
1
2
3
ADAPTOR
SHROUD
RIOT SHIELD
Place the shield in
FRONT of the R40.
(The shield pictured is cut in
half for this visual)
FRONT OF SHIELD
INCLUDED HARDWARE
M6 Bolts (2)
Bolts (2)
Washers (8)
Nuts (4)
9
INSTALLING THE R40 TO A RIOT SHIELD USING THE 3M
RECLOSEABLE FASTENER ADAPTOR
ADAPTOR
SHROUD
FRONT OF SHIELD
RIOT SHIELD
Place the shield in
FRONT of the R40.
(The shield pictured is cut in
half for this visual)
3M RECLOSABLE
FASTENER
(ADHESIVE SIDE)
Peel the backing and
place the adhesive
side against the back
of the shield.
3M RECLOSABLE
FASTENER
ADAPTOR
1. FIRST, REMOVE THE CAPTURE ADAPTOR. Assemble the 3M
Reclosable Fastener Adaptor to the Light Head using the included
hardware. Use a Phillips head screwdriver and crescent wrench to tighten
adaptors to each other (NOTE: Do NOT overtighten).
2. Align the center cutouts and press the 3M Reclosable Fastener together
with the 3M Reclosable Fastener Adaptor.
3. Peel the backing from the 3M Reclosable Fastener (exposing the adhesive)
and then press it firmly against the inside of the shield.
Press the 3M Reclosable Fastener adhesive firmly for at least 5 sec.
1
2
3
RIOT SHIELD INSTALLATION
INCLUDED HARDWARE
Bolts (2)
Washers (2)
Nuts (2)
CAPTURE ADAPTOR
(REMOVE THIS!)
10
CAPTURE SHIELD INSTALLATION
1. Drill two (2) holes in the riot shield using the included Drilling Template on
pg. 15.
2. Assemble the R40 light to the Adaptor Shroud AND the Capture Adaptor
then place the light against the INSIDE of the riot shield.
3. Use a Phillips head screwdriver and crescent wrench to install and secure
the R40 to the inside of the riot shield using the supplied hardware (M6
bolt, washers, and nuts).
NOTE: Be careful not to overtighten the bolts!
1
2
3
ADAPTOR
SHROUD
CAPTURE SHIELD
Place the shield in
FRONT of the R40.
(The shield pictured is cut in
half for this visual)
FRONT OF SHIELD
INCLUDED HARDWARE
M6 Bolts (2)
Bolts (2)
Washers (8)
Nuts (4)
CAPTURE ADAPTOR
