Foxconn 6497MB Series Manual de usuario
This manual is the intellectual property of Foxconn, Inc. Although the
information in this manual may be changed or modified at any time,
Foxconn does not obligate itself to inform the user of these changes.
Statement:
All trademarks are the property of their respective owners.
More information:
If you want more information about our products, please visit Foxconn’s
website: http://www.foxconnchannel.com
Version:
Trademark:
User Manual V1.0 in English for 6497MB series motherboard
P/N: 91-181-U49-M2-0E
Symbol description:
Note: refers to important information that can help you to use motherboard
` better.
Attention: indicates that it may damage hardware or cause data loss,
and tells you how to avoid such problems.
Warning: means that a potential risk of property damage or physical
injury exists.
６４９７ＭＢ－Ｅｎｇｌｉｓｈ ｐｒｅｆａｃｅ．ｐ６５ 2005-5-9, 15:181
Item Checklist:
Thanks for your purchasing Foxconn’s 6497MB series motherboard. Please check
the package; if there are missing or damaged items, contact your distributor as
soon as possible.
6497MB motherboard (x1)
Foxconn Utility CD (x1)
6497MB User Manual (x1)
RAID User Manual (x1) (optional)
ICH6R RAID Floppy (x1) (optional)
IDE Ribbon Cable (x1)
FDD Ribbon Cable (x1)
I/O Shield (x1)
S-ATA Signal Cable (x1)
S-ATA Power Cable (x1)
６４９７ＭＢ－Ｅｎｇｌｉｓｈ ｐｒｅｆａｃｅ．ｐ６５ 2005-5-9, 15:182
Declaration of conformity
HON HAI PRECISION INDUSTRY COMPANY LTD
66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,
TAIPEI HSIEN, TAIWAN, R.O.C.
declares that the product
Motherboard
6497MB
is in conformity with
(reference to the specification under which conformity is declared in
accordance with 89/336 EEC-EMC Directive)
EN 55022/A1: 2000 Limits and methods of measurements of radio disturbance
characteristics of information technology equipment
EN 61000-3-2/A14:2000 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits for harmonic current emissions
(equipment input current <= 16A per phase)
EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)
Part 3: Limits
Section 2: Limits of voltage fluctuations and flicker in low-voltage
supply systems for equipment with rated current <= 16A
EN 55024/A1:2001 Information technology equipment-Immunity characteristics limits
and methods of measurement
Signature : Place / Date : TAIPEI/2004
Printed Name : James Liang Position/ Title : Assistant President
６４９７ＭＢ－Ｅｎｇｌｉｓｈ ｐｒｅｆａｃｅ．ｐ６５ 2005-5-9, 15:183
Declaration of conformity
Trade Name: Foxconn
Model Name: 6497MB
Responsible Party: PCE Industry Inc.
Address: 458 E. Lambert Rd.
Fullerton, CA 92835
Telephone: 714-738-8868
Facsimile: 714-738-8838
Equipment Classification: FCC Class B Subassembly
Type of Product: Motherboard
Manufacturer:HON HAI PRECISION INDUSTRY
COMPANY LTD
Address: 66 , CHUNG SHAN RD., TU-CHENG
INDUSTRIAL DISTRICT, TAIPEI HSIEN,
TAIWAN, R.O.C.
Supplementary Information:
This device complies with Part 15 of the FCC Rules. Operation is subject to the follow-
ing two conditions : (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
Tested to comply with FCC standards.
Signature : Date : 2004
６４９７ＭＢ－Ｅｎｇｌｉｓｈ ｐｒｅｆａｃｅ．ｐ６５ 2005-5-9, 15:184
Table of Contents
Product Introduction
Installation Instructions
Supply .............................................................................................
Standard CMOS Features .......................................................................... 25
BIOS Features ...........................................................................................
Advanced BIOS Features ..........................................................................
Advanced Chipset Features ......................................................................
Integrated Peripherals ................................................................................
Power Management Setup .........................................................................
PnP/PCIConfigurations ...............................................................................
PC Health Status ........................................................................................
Frequency/Voltage Control .........................................................................
Load Fail-Safe Defaults .............................................................................
Load Optimized Defaults ............................................................................
Set Supervisor/User Password ................................................................. 44
Save & Exit Setup ......................................................................................
Exit Without Saving ....................................................................................
Chapter
Chapter
Chapter
Chapter Driver CD Introduction
Utility CD content ........................................................................................ 47
Start to Install Drivers ................................................................................. 48
BIOS Description
６４９７ＭＢ－Ｅｎｇｌｉｓｈ ｐｒｅｆａｃｅ．ｐ６５ 2005-5-9, 15:185
1. Attach the CPU and heatsink using silica gel to ensure full contact.
2. It is suggested to select high-quality, certified fans in order to avoid
damage to the motherboard and CPU due high temperatures.
3. Never turn on the machine if the CPU fan is not properly installed.
4. Ensure that the DC power supply is turned off before inserting or
removing expansion cards or other peripherals, especially when
you insert or remove a memory module. Failure to switch off the DC
power supply may result in serious damage to your system or
memory module.
Warning:
We cannot guarantee that your system will operate normally while
over-clocked. Normal operation depends on the over-clock capacity
of your device.
Warning:
Attention:
Since BIOS programs are upgraded from time to time, the BIOS
description in this manual is just for reference. We do not guarantee
that the content of this manual will remain consistent with the actual
BIOS version at any given time in the future.
Attention:
The pictures of objects used in this manual are just for your reference.
Please refer to the physical motherboard.
６４９７ＭＢ－Ｅｎｇｌｉｓｈ ｐｒｅｆａｃｅ．ｐ６５ 2005-5-9, 15:186
This manual is suitable for 6497MB motherboard. Each
motherboard is carefully designed for the PC user who
wants diverse features.
-L with onboard 100M LAN
-K with onbaord 1G LAN
-6 with 6 channel audio
-8 with 8 channel audio
-E with 1394 function
-S with SATA function
-R with RAID function
You can find PPID label on the motherboard. It indicates the
functions that the motherboard has.
For example:
On the blue mark of the PPID label, it means the
motherboard supports 6-channel audio(-6), 1394 port(-E),
onboard 100M LAN (-L), SATA function(-S).
６４９７ＭＢ－Ｅｎｇｌｉｓｈ ｐｒｅｆａｃｅ．ｐ６５ 2005-5-9, 15:187
Chapter
Thank you for buying Foxconn’s 6497MB series motherboard.
This series of motherboard is one of our new products, and
offers superior performance, reliability and quality, at a reason-
able price. This motherboard adopts the advanced SiS649 +
SiS964/SiS964L chipset, providing users a computer platform
with a high integration-compatibility-performance price ratio.
This chapter includes the following information:
Main Features
Motherboard Layout
1
1
Chapter 1 Product Introduction
2
Main Features
Size
mATX form factor of 9.6 inch x 8.5 inch
Microprocessor
Supports Intel® Prescott-T processor in an LGA775 package
Supports FSB at 533/800 MHz
Supports Hyper-Threading technology
Chipset
SiS649(North Bridge) + SiS964/SiS964L (South Bridge)
System Memory
Two 184-pin DIMM slots
Supports up to 2 GB DDR memory
Supports Single-Channel DDR 400/333/266
Registered memory not supported
Supports 128 Mb, 256 Mb, 512 Mb technologies
USB 2.0 Ports
Supports hot plug
Eight USB 2.0 ports (four rear panel ports, two onboard USB headers
providing four extra ports)
Supports wake-up from S1 and S3 mode
Supports USB 2.0 Protocol up to 480 Mbps transmission rate
Onboard Serial ATA (optional)
150 MBps transfer rate
Supports two S-ATA devices
Supports RAID 0, RAID 1, JBOD
3
Chapter 1 Product Introduction
Onboard 1394 (-E ) (optional)
Support hot plug
With rate of transmission at 400 Mbps
Self-configured addressing
Can connect with 2 independent 1394 units synchronously at most
Onboard LAN (-L/-K) (optional)
Supports 10/100/1000 (-K optional) Mbit/sec Ethernet
LAN interface built-in on board
Onboard Audio (-6)(optional)
AC’97 2.3 Specification Compliant
Supports SPDIF output
Onboard Line-in jack, Microphone-in jack, Line-out jack
Supports 6-channel audio (setting via software)
Onboard Audio (-8)(optional)
Supports 8-channel audio
Supports SPDIF output
Supports high quality differential CD input
PCI Express x16 Support
Supports 4 GB/sec (8 GB/sec concurrent) bandwidth
Low power consumption and power management features
Green Function
Supports ACPI (Advanced Configuration and Power Interface)
Supports S0 (normal), S1 (power on suspend), S3 (suspend to RAM), S4
(Suspend to disk - depends on OS), and S5 (soft - off).
Expansion Slots
Three PCI slots
One PCI Express x16 Graphics slot
