Foxconn nT-425 Manual de usuario
NETBOX
User’s Manual
CAUTION
!
© All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
All images are for reference only, please refer to the physical product for specic features.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
W
A
R
N
I
N
G
!
Trademark:
All trademarks are the property of their respective owners.
Version:
User’s Manual V1.0 for NETBOX.
P/N: 3A2226200-000-G
Symbol description:
Caution : refers to important information that can help you to use NETBOX
better, and tells you how to avoid problems.
Warning: indicating a potential risk of hardware damage or physical injury may
exist.
WEEE:
The use of this symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could other-
wise be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city ofce, your
household waste disposal service or the shop where you purchased this product.
Before using this product, please read the below safety notice carefully,
this will help to extend the product’s lifecycle, and work normally.
■ When NETBOX is working, please make sure its ventilation system is
working.
■ The power adapter is dissipating heat during normal use, please be sure
not to cover it and keep it away from your body to prevent discomfort or
injury by heat exposure.
■ Please use the power adapter that comes with the product’s package,
wrong power adapter may damage your device.
■ Make sure all the peripherals are properly connected before using NET-
BOX.
■ This product should only be used in an environment with ambient tem-
peratures between 0◦C and 40◦C.
■ Always shut down the computer before installing or uninstalling the pe-
ripheral which does not support hot plug.
■ Disconnect all peripherals before servicing or disassembling this equip-
ment.
■ Please do not disassemble this product by yourself, any disassembly not
approved by the original manufacturer may result in malfunction, and void
warranty.
■ Risk of explosion if battery is replaced by an incorrect type, please dis-
pose of used batteries according to the instructions.
CAUTION
!
Safety Notice :
TABLE OF CONTENTS
Chapter 1 Introducing the NETBOX
Product Overview.....................................................................................2
LED Indicator Introduction........................................................................4
Chapter 2 Placing and connecting the NETBOX
Placement of NETBOX
On the Desk .........................................................................................6
On the Display Back.............................................................................6
Connection of NETBOX
Connect the Monitor.............................................................................8
Connect the USB Devices....................................................................8
Connect the Network Cable .................................................................8
Connect the Power Cord......................................................................9
Chapter 3 Install Windows OS
Install Windows XP.................................................................................11
Install Windows 7 ...................................................................................15
Chapter 4 FoxMC Introduction
First Boot................................................................................................20
Desktop Overview ..................................................................................22
Recovery of FoxMC................................................................................24
The NETBOX is a compact and easy to use desktop. It features all
the desktop capabilities but with a slim body design which enables
your to browse the internet in a relaxable and comfortable way.
This chapter introduces the following information:
■ Product Overview
■ LED Indicator Introduction
1
2
NETBOX features all the desktop capabilities but with a slim body design which enables you to
browse the internet in a relaxable and comfortable way.
1-1 Product Overview
1. Top View
2. Front Side View
No. Name Description
1 Headphone Port Connects to a headphone
2
Microphone In and S/PDIF In
Port
Connects to a microphone or playback devices with
optical connectors(3.5mm jack)
3 Multi-Function Card Reader Supports SD/SDHC/MS/MS Pro/MMC memory cards
4 USB Ports Connect to USB devices
5WLAN_LED Indicates Wireless connection states
6LLS_LED Indicates different system states
7HDD_LED Indicates hard disk states
8 Suspend Button with
Integrated LED Indicator
Enter suspend mode in operating system
Indicates suspend states
9 Power Button with
Integrated LED Indicator
Turning the power on/off
Indicates system states
0.95in
(24mm)
123 6 984 7
LLS_LED1 LLS_LED5
5
(190mm)
7.5in
5.3in
(135mm)
1
3
3. Back Side View
4. Bottom View
No. Name Description
1 Sheet Metal NETDVD(optional accessory) or Magnet-Metal-Feet can mag-
netize them to seat rmly
There are four Magnet-Metal-Feet in the package. Just align them to the sheet metal
on the bottom, then they can magnetize the NETBOX easily. The feet can seat and
protect NETBOX when it is placed on the tabletop.
CAUTION
!
No. Name Description
1 USB Ports Connect to USB devices
2Display Output Port(VGA) Connects to display device
3 Network Port Standard RJ-45 network port
4
Line Out and S/PDIF Out Port
Connects to powered analog speakers or record-
ing devices with optical connectors(3.5mm jack)
5 Power Input Port Connects to the power adapter
1
12 3 54
1
4
1-2LED Indicator Introduction
The LLS_LEDs status in this table only show BIOS error message.
CAUTION
!
Indication Suspend_
LED
Power_
LED
HDD_
LED
WLAN_
LED
LLS_
LED1
LLS_
LED2
LLS_
LED3
LLS_
LED4
LLS_
LED5
Boot - Green Red
Blink - - - - - -
S0(Working Mode) - Green - - Off Off Off Off Off
S1(Power-Saving Mode) - Green Off - Off Off Off Off Off
S3(Standby Mode)
[Press Suspend Button]
Red
Blink - Off - Off Off Off Off Off
S4(Hibernation Mode)&
S5(System Power Off Mode)
- Off Off - Off Off Off Off Off
CPU
Initialization Error
- - - - Blue,
Blink - - - -
DRAM Error - - - - - Blue,
Blink - - -
BIOS Boot Block Fail - - - - - - - Blue,
Blink -
BIOS Checksum Error - - - - - - - - Blue,
Blink
CMOS Cleared [Press
Suspend Button for 4Sec.] -Red,
Blink - - - - - - -
HDD R/W Data - - Red - - - - - -
Wireless
Network
Enable
Link to AP - - - Blue - - - - -
No Link to AP - - - Blink
(Once every 5Sec.)
- - - - -
Data
Transmission - - - Blink
(Indenite interval)
- - - - -
In this chapter, the placement and the connection of some neces-
sary peripherals will be introduced.
This chapter includes the following information:
■ Placement of NETBOX
■ Connection of NETBOX
2
6
To install this bracket, your display must follow VESA75/VESA100 standard. The two
groups of holes on your display have different space between, and they help you
easily fasten the bracket onto your display.
CAUTION
!
2-1 Placement of NETBOX
1. On the Desk
You can install your NETBOX in the mount directly.
If there is enough space on your desk, you can simply put your NETBOX with Magnet-Metal-
Feet on the tabletop.
2. On the Display Back
This is the best space-saving way.
2.1. Use four screws(M4X10mm) to fasten the bracket onto the display back.
