Model:39DLE172

Fix the T V o n the wall

1.First,put the TV on the table smoothly and put some soft cloth on the table to avoid

scratching the screen.

2.User the screw driver to take off the screws which are fixed on the bottom stand

(the direction of the arrow, refer to the ptoto1).And take off the bottom stand(please

take off the screws and bottom stand carefully).

3.Make one bracket which can fix on the wall according to the size of arrow direction

of photo2 and photo3.

4.Drill four holes properly on the wall (the size only for reference) and put into four

screws.(optional parts) Drill four holes properly on the wall (the size only for reference)

and put into four screws.(optional parts)

5.according to the step 4,use the screwdriver to lock the screw on the back of the TV.

then hang the TV on the wall.

Note:

1.The bracket fixed on the wall is optional part.

2.when you assemble the TV, there should be no other articles on the around and front

and please keep the distance from other articles.

3.When assemble the TV, please ask the career man to fix in order to avoid the danger.

4.The fixing picture is only for reference.

5.Please follow the use manual about bracket assemble to fix the TV.

6.Attach the mounting bracket from the VESA compatible wall mounting kit.

1 2

34

NOTE:

IF YOUR PROGRAM ON TV WILL BE INCLUDED BY CABLE TELEVISIONS,

PLEASE CHECK YOUR EARNING AND POTENTIAL EVALUATION ON THE CABLE OF YOUR

CABLE OPERATOR.

FOR THESE INFORMATION CONTACT YOUR CABLE OPERATOR.

HDMI

AV input

External AV Signal Input

Y Pb Pr input

Connect to the composite terminal of

your DVD/VCR

HDMI input

Digital signal input from HDMI video

connector.

ANT 75

Connect the antennal/cadle tv input

(75/VHF/UHF)

VGA input

PC analog signal input

PC AUDIO INPUT

VGA input and audio input when VGA

input

EARPHONE output

When earphones are plugged in,

speakers are disabled

USB input

Connect a USB device here to play

its media files or to recordprograms

via the PVR function.

COAXIAL COAXIAL

Connect the SPDIF receiver.

AV IN

Ypbpr IN
