Force 10 S55T Manual de instrucciones

Installing the S55T System

101-00368-03 June 6, 2011

Force10 Networks® reserves the right to change, modify, revise this publication without notice.

Trademarks

Force10 Networks® and E-Series® are registered trademarks of Force10 Networks, Inc. Force10, the Force10 logo, E1200, E600, E600i,

E300, EtherScale, TeraScale, ExaScale, FTOS, C-Series, and S-Series are trademarks of Force10 Networks, Inc. All other brand and product

names are registered trademarks or trademarks of their respective holders.

Statement of Conditions

In the interest of improving internal design, operational function, and/or reliability, Force10 Networks reserves the right to make changes to

products described in this document without notice. Force10 Networks does not assume any liability that may occur due to the use or

application of the product(s) described herein.

Installing the S55 System 3

Table of Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Preface

About this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Information symbols and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Chapter 1

The S55 System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Orderable S55 systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

System status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

LED displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Chapter 2

Site Preparations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Site selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Cabinet placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Rack mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Fans and airflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Storing components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Chapter 3

Install the S55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Install the S55 chassis in a rack or cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Attach mounting brackets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Install chassis into rack or cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Attach ground cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Insert optional modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Table of Contents

4 Table of Contents

Install the SFP and SFP+ optics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Connect stacking ports (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Connect two S55s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Connect three or more S55s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Supply power and power up the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Power up sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

AC power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

DC power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Hot-swap units in a stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Chapter 4

Power Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Install an AC or DC power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Replace an AC or DC power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Chapter 5

Fans. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Install a fan module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Replace a fan module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Chapter 6

Access the console ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Access the RJ45 console port (RS-232) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Access the RJ-45 console port with a DB-9 adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Access the USB-B console port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Chapter 7

S55 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Chassis Physical Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Environmental Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

AC Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

DC Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

IEEE Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Agency Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Safety Standards and Compliance Agency Certifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Electromagnetic Compatibility (EMC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Product Recycling and Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Installing the S55 System 5

Chapter 8

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

The iSupport website . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Accessing iSupport services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Contacting the Technical Assistance Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Requesting a hardware replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

6 Table of Contents

Installing the S55 System 7

This guide provides site preparation recommendations, step-by-step procedures for rack mounting and

desk mounting, inserting optional modules, and connecting to a power source.

After you have completed the hardware installation and power-up of the S55, refer to the FTOS

Configuration Guide for the S55 for software configuration information and the FTOS Command

Reference for the S55 for Command Line Interface (CLI) information.

Information symbols and warnings

The following graphic symbols are used in this document to bring attention to hazards that exist when

handling the S55 and its components. Please read these alerts and heed their warnings and cautions.

Preface About this Guide

Note: The S55 requires FTOS version 8.3.5.0. Refer to the S55 Release Notes for information on

upgrading the system, if necessary. Contact Force10 Networks Technical Support with any questions

regarding FTOS versions and upgrades.

Caution: Wear grounding wrist straps when handling this equipment to avoid ESD damage.

Danger: The installation of this equipment shall be performed by trained and qualified personnel only.

Read this guide before installing and powering up this equipment. This equipment contains two power

cords. Disconnect both power cords before servicing.

Danger: This equipment contains optical transceivers, which comply with the limits of Class 1

laser radiation.

Danger: Visible and invisible laser radiation may be emitted from the aperture of the optical

transceiver ports when no cable is connected. Avoid exposure to laser radiation and do not stare

into open apertures.

8 About this Guide

Table 1 describes symbols contained in this guide.

Related publications

For more information about the S55, refer to the following documents:

• FTOS Configuration Guide for the S55 system

• FTOS Command Reference for the S55 system

•FTOS Release Notes for the S55 system

Table 1 Information Symbols

Symbol Warning Description

Danger This symbol warns that improper handling and installation could result in bodily

injury. Before you begin work on this equipment, be aware of hazards involving

electrical circuitry, networking environments, and instigate accident prevention

procedures.

Caution This symbol informs you that improper handling and installation could result in

equipment damage or loss of data.

Warning This symbol informs you that improper handling may reduce your component or

system performance.

Note This symbol informs you of important operational information.

ESD

Warning This symbol identifies that Electrostatic precautions should be taken when handling

the device.

Note: For the most recent documentation and software, please visit iSupport (registration for access to

some sections is required):

https://www.force10networks.com/CSPortal20/Main/SupportMain.aspx

Installing the S55 System 9

Introduction

The Force10 Networks S55 is a high performance, high capacity, low cost, stackable, Layer 2 switch/Layer

3 router that supports 44 built-in 10/100/1000 Base-T ports, four SFP (small form-factor pluggable) ports,

and two optional module slots, and optional 12G stacking module. The S55’s PSU (Power Supply Unit)

side (Figure 1) contains the Power Supply Units (PSUs), and optional module slots. As shown in Figure 2,

the S55’s I/O (Input/Output) side contains the 44 ethernet ports, the SFP ports, the management ports and

the displays for alarms and stacking identification.

Figure 1 The S55 PSU side

Figure 2 The S55 I/O

Orderable S55 systems

Chapter 1 The S55 System

Note: The ethernet ports are labeled 0-43. When cabling these ports, be sure not to interfere with the

airflow from the small vent holes above and below the ports.

Fan

Power Supply (PSU0) Power Supply (PSU1)

FanMounting Bracket Mounting Bracket

Optional Module slots

Ethernet Ports

RJ-45

Console

Port

SFP Ports USB-A Port

USB-B Port

Stack ID

Alarm LEDs

10/100/1000

Management Port

Grounding

10 The S55 System

The S55 can be ordered in several different configurations. Optional modules are ordered separately.

To successfully install the S55, ensure that you have the following:

• S55 chassis (or multiple chassis, if stacking)

• At least one grounded AC or DC power source per chassis

• Cable to connect the AC or DC power source to the chassis (US power cables included)

• Mounting brackets for rack installation (included)

• Screws for rack installation and #1#2 Phillips screwdrivers (not supplied)

• Ground cable (not supplied)

• Ground cable screws (included)

• Copper/fiber cables

Other optional components are:

• Additional Power Supply Unit

Hardware Catalog Number

44 port 10/100/1000 Base-T with 4 SFP ports and 2 expansion module slots S55T

44 port 10/100/1000 Base-T with 4 SFP ports and 2 expansion module slots, 1 AC

power supply and 2 fan units with airflow from I/O panel to utility panel S55T-AC

44 port 10/100/1000 Base-T with 4 SFP ports and 2 expansion module slots, 1 DC

power supply and 2 fan units with airflow from I/O panel to utility panel S55T-DC

44 port 10/100/1000 Base-T with 4 SFP ports and 2 expansion module slots, 1 AC

power supply and 2 fan units with airflow from utility panel to I/O panel S55T-AC-R

44 port 10/100/1000 Base-T with 4 SFP ports and 2 expansion module slots, 1 DC

power supply and 2 fan units with airflow from utility panel to I/O panel S55T-DC-R

S55 Series - Fan with airflow from I/O panel to utility panel S55-FAN

S55 Series - Fan with airflow from utility panel to I/O panel S55-FAN-R

S55 Series - AC Power supply with airflow from I/O panel to utility panel S55-PWR-AC

S55 Series - AC Power supply with airflow from utility panel to I/O panel S55-PWR-AC-R

S55 Series - DC Power supply with airflow from I/O panel to utility panel S55-PWR-DC

S55 Series - DC Power supply with airflow from utility panel to I/O panel S55-PWR-DC-R

S55 Series - 2 port 12 Gigabit stacking module S55-12G-2ST

S55 Series - 2 port 10 GE SFP+ module - SFP+ optics not included S55-10GE-2S

Tabla de contenidos

Otros manuales de Hardware de red de Force 10

Force 10

Force 10 Adit 3104 IP Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario
