Flymo 1200 R Manual de usuario

Easier by Design

www.ymo.co.uk

Preston Road,

Aycliffe Business Park,

Newton Aycliffe,

County Durham,

DL5 6UP

Helpline Number: 0844 844 4558

Part Number: 115 53 37-26

trademarks of Flymo S.A. The Husqvarna UK policy of continuous improvement and updating means that

specications can be altered without prior notice. All measurements quoted are approximate.

6. Adjust the robotic lawnmower to suit your garden

See chapter 6.3, 6.4 and 6.5 in the Installation Manual

Here you will nd some tips on important settings for your robotic lawnmower.

All settings for your robotic lawnmower are made via the menu functions.

Adjust the mower to suit the size of your lawn

The mowing results depend on mowing time. Adjust the mowing time to suit your garden using

the Timer function. If the mower cuts too often, the lawn will appear trampled down.

If the mower cuts too seldom, the lawn will not be properly mown.

Timer

You decide what times during the

day and days of the week the

mower is to work. The robotic

lawnmower mows about 30 m

per hour and day. For example; if

your g a rden consists of 360 m of

grass, the robotic lawnmower

should work on average 12 hours

per day.

Test run the mower through narrow passages

Narrow passages in the garden m a ke it dif cult for the mower to nd the charging station. Use the

Calibrate guide function for the Flymo 1200R to test that the mower can travel through the

narrowest passage.

1. Place the mower in the charging station.

2. Select Calibrate guide in the robotic lawnmower’s menu and press OK. Then press the

Start button and close the cover.

3. Check that the mower follows the guide wire through the passage.

a. If the mower travels through the passage, the test is complete.

b. If the robotic lawnmower does not get through the passage: Check that the guide

wire has been laid according to the instructions in chapter 3.6 in the Installation Manual.

12345

1 2 3

4 5 6

7 8

Start

5. Starting and stopping

See chapter 4.3 and 4.4 in the Installation Manual

Starting

1. Open the cover by pressing the STOP button.

2. Set the main switch to position 1. When you do this for the rst time, a start up

sequence starts where you select a four digit PIN code among other things.

3. Press the START button.

4. Close the cover.

Stopping

Press the STOP button

Easier by Design

www.ymo.co.uk

QUICK GUIDE

Robotic

Lawnmower

120 0 R

MINIMUM

150cm

SUITABLE

FOR LAWNS

UP TO

400m2

2.Charging the battery and

placement of the boundary wire

See chapter 3.3 and 3.4 in the Installation Manual

1. Place the robotic lawnmower in the charging station

to charge the battery while the boundary wire is laid.

Set the main switch to position 1.

2. Run the boundary wire ensuring it forms a loop

around the work area.

3. Make an eyelet at the point where the guide wire

will be connected later (see point 4.5).

20 cm / 8”

10 cm / 8”

0 cm / 0”

5 cm / 2”

30 cm / 12”

1. Placement of and connecting the

charging station

See chapter 3.2 in the Installation Manual

1. Place the charging station at a central position in the work area, with

a lot of open space in front of the charging station and on a relatively

horizontal surface.

2. Connect the transformer’s low voltage cable to the charging station

and the transformer.

3. Connect the transformer to a 230 V wall socket.

1. Main switch

2. STOP button

3. LED for function check of the

boundary and guide wires

4. Cutting height indication

5. Display

6. Keypad

Charging station

12345

1 2 3

4 5 6

7 8

Start

GETTING STARTED WITH THE FLYMO

min 2 m / 7 ft

4.Placement of and connecting the

guide wire

See chapter 3.6 in the Installation Manual

1. Run the guide wire through the slot at the bottom of the charging

station.

2. Fit the connector to the guide wire in the same way as for the

boundary wire, according to the instructions above.

3. Fasten the connector to the contact pin marked Guide on the

charging station.

4. Lay the guide wire at least 2 metres straight out from the front edge

of the charging station.

5. Run the guide wire to the point on the boundary loop the connection

will be made. Avoid laying the wire at tight angles.

6. Cut the boundary wire with a wire cutters at the centre of the eyelet

that was made in point 2.3.

7. Connect the guide wire to the boundary wire using the

accompanying couplers. Press the couplers completely together

with a pair of pliers.

1 2

3.Connecting the boundary wire

See chapter 3.5 in the Installation Manual

1. Open the connector and lay the wire ends in the recesses on

each connector.

2. Press the connectors together using a pair of pliers.

3. Cut off any surplus boundary wire. Cut 1 to 2 cm above

the connectors.

4. Press the connectors onto the contact pins, marked A, on

the charging station. It is important that the right-hand wire

is connected to the right-hand contact pin, and the left-hand

wire to the left-hand pin.

Transformer Low voltage cable Boundary wire

and couplers

Pegs Connectors Measurement

gauge

1200 R ROBOTIC LAWNMOWER

5cm

0cm

20cm

30cm

30 cm / 12”
