Step 1 Before proceeding, decide which of fitting options you wish to use and
prepare the side guides prior to assembling the unit.
Unika Window Screens (All MUV models)
FACE FITTING Option A Drill a 3.5 mm hole through
the outer groove, ensuring you remain within the
recessed area in pic 2.
(Tip) Use a 2mm bit for the pilot hole into the frame.
Please note you will need a hex bit for the screws
FACE FITTING Option B Drill directly through the
guide using a 3mm bit. Open up the front facing
hole to 7mm and use the cover caps provided for a
neat finish.
(Tip) Use a small screw (3.5x 16) to affix to frame.
RECESS FITTING Option C Drill 3.5 mm holes
through the sides of guides, for directly fixing into
the recess. Typically two or three depending on
height.
(Tip) Use the special tool 8460.0 to allow the fluffy
pile to be safely moved when fittin .
Step Fitting the Concealed Catches to the side guides.
To avoid the fluffy pile being pulled back into the
cassette during use. Trim about 6mm off the length
of the pile. Simply crimp the channel top and
bottom with a flat headed screwdriver and hammer.
(Tip) Gently does it! Avoid bendin the uide out of
shape by hittin too hard.
Slide the catches (marked L or R) into the
appropriate guide as shown. Ensure the hook is to
the (grooved) front .Crimp the guide to hold the
catch firmly in place. This prevents catches being
forced out in operation.
( uides are shown with no pile for illustration
purposes)
OPTIONAL INTERMEDIATE STOPS. If using the
optional intermediate stops, slide into the guide
ensuring the “ wedge “ is to the (grooved) front of
the side guide Leave loose, adjust to desired height
once the screen has been installed.
(Tip) Gently does it! Avoid overti htenin the rub
screws when adjustin . This can cause dama e to
the side uide and failure to work properly
