FLIR Si124 Manual de usuario

User’s manual

FLIR Si124

Acoustic Camera

tester

Table of contents

1 Safety information...............................................................1

2 Notice to user .....................................................................2

2.1 List of contents...........................................................2

2.2 Read the manual before use ......................................... 2

2.3 Customer help ........................................................... 2

2.4 Disposal of electronic waste..........................................2

2.5 Markings .................................................................. 3

3 Introduction........................................................................4

4 Device parts .......................................................................5

5 Getting started....................................................................6

5.1 Required items........................................................... 6

5.2 Startup ..................................................................... 6

5.3 Shutdown .................................................................6

5.4 Operating modes........................................................ 6

6 Using the device for checking camera accuracy......................8

#T810596; r. AA/79681/79681; en-US v

Safety information

WARNING

The FLIR Si124 Acoustic Camera tester is capable of delivering sound pressure levels that

may cause permanent hearing damage. The user of the device should always use hearing

protection when the device is operated at a distance less than 0.5 m to avoid permanent

hearing damage.

Sound pressure level may exceed 80 dB (A) at a distance less than 0.5 m.

CAUTION

Follow all instructions. Please note that by using the device you agree to the terms of use.

Misuse might cause hearing damage, device damage, or false readings.

CAUTION

Do not try to repair the device or open the enclosure of the FLIR Si124 Acoustic Camera

tester. Do not use a damaged device or damaged power cords.

CAUTION

Use only the power supply provided by the FLIR Si124 Acoustic Camera with the FLIR

Si124 Acoustic Camera tester.

CAUTION

Protect the device and accessories from dirt, dust, impacts, and liquids.

CAUTION

Do not leave the device plugged in.

#T810596; r. AA/79681/79681; en-US 1

Notice to user

2.1 List of contents

• FLIR Si124 Acoustic Camera tester

• Table tripod

• Printed documentation

2.2 Read the manual before use

Before operating the device, you must read, understand, and follow all instruc-

tions, warnings, cautions, and legal disclaimers. Misuse can cause damage to

the camera or false sensor readings.

To access online documentation and technical data specifications for the

FLIR Si124 Acoustic Camera tester, go to:

http://support.flir.com/resources/g9wc

2.3 Customer help

Do not hesitate to contact our Customer Support Center if you experience

problems or have any questions about your product.

For customer help, go to http://support.flir.com.

2.4 Disposal of electronic waste

Electrical and electronic equipment (EEE) contains materials, components

and substances that may be hazardous and present a risk to human health

and the environment when waste electrical and electronic equipment (WEEE)

is not handled correctly.

#T810596; r. AA/79681/79681; en-US 2

Notice to user

Equipment marked with the below crossed-out wheeled bin is electrical and

electronic equipment. The crossed-out wheeled bin symbol indicates that

waste electrical and electronic equipment should not be discarded together

with unseparated household waste, but must be collected separately.

For this purpose all local authorities have established collection schemes

under which residents can dispose waste electrical and electronic equipment

at a recycling centre or other collection points, or WEEE will be collected di-

rectly from households. More detailed information is available from the techni-

cal administration of the relevant local authority.

2.5 Markings

An ID-label consisting of the identification data, CE, and WEEE markings are

on the back side of the FLIR Si124 Acoustic Camera tester.

#T810596; r. AA/79681/79681; en-US 3

Introduction

The FLIR Si124 Acoustic Camera tester is an accuracy checker that is used

together with the FLIR Si124 Acoustic Camera. The device produces a sound

signal that is perceived and evaluated by the camera. The perceived dB-level

of the signal can be used to ensure the correct level of the FLIR Si124 Acous-

tic Camera’s readings and the condition of the microphone array.

We recommend checking your FLIR Si124 Acoustic Camera using the FLIR

Si124 Acoustic Camera tester once a year. However, if the camera is used in

dusty and polluted environments, it is recommended to check it more

frequently.

#T810596; r. AA/79681/79681; en-US 4

Device parts

1. Loudspeaker

2. IR LED

3. Mode switch

4. Quick Release plate

5. Power LED

6. Power socket

#T810596; r. AA/79681/79681; en-US 5

Getting started

5.1 Required items

• The FLIR Si124 Acoustic Camera tester

• The FLIR Si124 Acoustic Camera battery charger (power supply)

• A tripod with quick release mount.

Any tripod that fits the quick release mount (4) can be used. If the tripod

provided with the device is used, see the tripod instruction manual.

5.2 Startup

Before startup, make sure the device’s switch (3) is in the OFF position. The

leftmost position is the OFF position (see the sticker on the front side of the

device). Connect the mains cable of the power supply into a wall socket be-

fore connecting the DC barrel connector to the power socket (6) of the device.

After connecting the DC barrel connector, the device will take about 10 sec-

onds to start

Note If the mains cable is plugged into a wall socket after the DC barrel con-

nector is plugged in, the device will not start up.

5.3 Shutdown

Turn the switch (3) to the OFF position. Remove the DC barrel connector from

the power socket (6) and the device will shut down. Remove the mains cable

from the wall socket.

5.4 Operating modes

Use the switch (3) to select operating mode. Operating modes are selected

by turning the switch (3) clockwise from the OFF position. The following oper-

ating modes are available:

1. OFF: No sound is emitted.

2. CALIBRATION: Test signal for checking the accuracy of the FLIR Si124

Acoustic Camera.

3. PD 1: The sound of a corona discharge.

4. PD 2: The sound of a floating discharge.

5. PD 3: The sound of a surface discharge.

6. LEAK: The sound of a compressed air leak.

#T810596; r. AA/79681/79681; en-US 6

Getting started

Operating modes 3, 4, 5, and 6 can be used to demonstrate the functionality

of the FLIR Si124 Acoustic Camera for detecting partial discharges and com-

pressed air leaks.

#T810596; r. AA/79681/79681; en-US 7

Using the device for

checking camera accuracy

Follow this procedure:

1. Power on the FLIR Si124 Acoustic Camera.

2. Tap Settings (the cogwheel icon) on the bottom left corner of the screen.

3. Tap Advanced settings.

4. Tap More... until you can see a Calibration mode selection available. De-

pending on your specific camera configuration, you may need to tap it

once, twice or more. If you accidentally miss the page containing the se-

lection, keep tapping until it appears again.

5. Power on the FLIR Si124 Acoustic Camera tester device.

6. Mount the device on a tripod. Place the device at least 1.0 meter from any

surface. If you are using the tripod provided with the FLIR Si124 Acoustic

Camera tester (or similar low tripod), place it on a table.

7. On the FLIR Si124 Acoustic Camera tester, select CALIBRATION mode

by turning the switch according to the label on the front side of the device.

8. On the FLIR Si124 Acoustic Camera screen, tap Activate to activate the

Calibration mode.

#T810596; r. AA/79681/79681; en-US 8
