FLIR Oryx Manual de usuario

INSTALLATIONGUIDE

FLIR

ORYX®

Version 1.0

Revised 10/27/2017

FCC Compliance

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesirable operation.

Korean EMCCertification

The KCC symbol indicates that this product complies with Korea’s Electrical Communication Basic Law regarding

EMC testing for electromagnetic interference (EMI) and susceptibility (EMS).

Hardware Warranty

The warranty for the Oryx camera is 3 years. For detailed information on how to repair or replace your camera,

please see the terms and conditions on our website.

Export Control

The ECCN for this product is EAR099.

WEEE

The symbol indicates that this product may not be treated as household waste. Please ensure this

product is properly disposed as inappropriate waste handling of this product may cause potential

hazards to the environment and human health. For more detailed information about recycling of this

product, please contact us.

Trademarks

Names and marks appearing on the products herein are either registered trademarks or trademarks of FLIR

Systems, Inc. and/or its subsidiaries.

Licensing

To view the licenses of open source packages used in this product please see What open source packages does

firmware use?

Table of Contents

1 Oryx Installation Guide 1

2 Handling Precautions and Camera Care 2

3 Oryx Installation 3

3.1 Preparing for Installation 3

3.2 Installing Your Interface Card and Software 4

3.3 Installing Your Oryx 5

3.4 Powering Your Oryx 6

4 Tools to Control the Oryx 7

4.1 Using the Spinnaker® Software Development Kit 7

4.1.1 SpinView Camera Evaluation Application 7

4.1.2 Custom Applications Built with the Spinnaker API 7

4.2 Using GenICam Applications 8

5 Configuring Oryx Setup 9

5.1 Configuring Camera Driver 9

5.2 Configuring the IP Address 11

5.3 Allocating Bandwidth 11

5.3.1 Determining Bandwidth Requirements 11

5.4 Configuring Other Ethernet Settings 12

5.4.1 Stream Channel Destination Address 12

5.4.2 Heartbeat 13

5.5 Camera Firmware 14

5.5.1 Determining Firmware Version 14

5.5.2 Upgrading Camera Firmware 14

6 Oryx Physical Interface 15

6.1 Oryx Physical Description 15

6.2 Oryx Dimensions 16

6.3 Interface Connector 16

6.3.1 Ethernet Connector 16

6.3.2 Interface Cables 16

6.3.3 Interface Card 17

6.3.4 General Purpose Input/Output (GPIO) 17

6.4 Mounting 19

10/27/2017

Imaging Solutions Inc.

FLIROryx®Installation Guide i

6.5 Case Temperature and Heat Dissipation 19

6.6 Lens Mounting 20

6.6.1 Back Flange Distance 20

6.7 Non-Volatile Flash Memory 21

6.8 Dust Protection 21

6.9 Infrared Cut-Off Filters 22

7 Input/Output Control 23

7.1 General Purpose Input/Output (GPIO) 23

7.2 GPIO Electrical Characteristics 25

7.2.1 Output Timing Characteristics 28

7.2.2 Input Timing Characteristics 29

8 Troubleshooting 30

8.1 Support 30

8.2 Status Indicator LED 31

8.2.1 Network Status LEDs 31

Contacting Us 32

10/27/2017

Imaging Solutions Inc.

FLIROryx®Installation Guide ii

1 Oryx Installation Guide

Welcome to the Oryx camera. We offer a number of resources to assist you with the Oryx.

nRelease Notes—information about the current firmware release including feature additions or changes,

bug fixes, and known issues.

nSpecifications—information about the camera model as it performs with the current firmware.

nGetting Started—quick start guide for installing the camera and software.

nInstallation Guide—information about installing the camera and SDK, the physical interface and

mechanical properties, troubleshooting and how to get help. This document is available as a PDF for

download or as a webpage included in the firmware release package.

nTechnical Reference—information about the features supported by the camera model with the current

firmware, including: image format control, acquisition control, sequencing, binning/decimation, and others.

This document is available as a PDF for download or as a webpage included in the firmware release

package.

nFirmware—programming inserted into the programmable ROM of the camera that can be updated in-field.

New firmware packages are available for download and include both the firmware file and documentation.

nSpinnaker SDK—software development kit that provides GenICam-compliant controls to create

applications for the camera. Spinnaker is available for download. Each installation includes API

documentation for C, C++, and C#.

Our website provides additional information in our Knowledge Base and Technical Application Note library. As

well, the Downloads site is the portal to access documentation and firmware updates.

10/27/2017

Imaging Solutions Inc.

FLIROryx®Installation Guide 1

2 Handling Precautions and Camera Care

Warning! Do not open the camera housing. Doing so voids the

Hardware Warranty described in the Terms and Conditions on

our website.

Your FLIR digital camera is a precisely manufactured device and should be handled with care. Here are some tips

on how to care for the device.

nAvoid electrostatic charging.

nWhen handling the camera unit, avoid touching the lenses. Fingerprints will affect the quality of the image

produced by the device.

nTo clean the lenses, use a standard camera lens cleaning kit or a clean dry cotton cloth. Do not apply

excessive force.

nExtended exposure to bright sunlight, rain, dusty environments, etc. may cause problems with the

electronics and the optics of the system.

nAvoid excessive shaking, dropping or any kind of mishandling of the device.

Title Article

Cleaning the imaging surface of your

camera

Knowledge Base Article

10243

Related Knowledge Base Articles

10/27/2017

Imaging Solutions Inc.

FLIROryx®Installation Guide 2

3 Oryx Installation

3.1 Preparing for Installation

What system configuration is recommended?

Operating

System CPU RAM Ports Software to run /

compile example code

Recommended

System

Configuration

Windows7,

Windows8, or

Windows10

(32- or 64-bit)

Intel i5

8 GB

(dual

channel

memory)

FLIRACC-01-1101—

NBASE-T Ethernet

PCI Express 2.0 x4,

1 port, Tehuti TN4010

Microsoft Visual Studio 2010,

Visual Studio 2013, or

Visual Studio 2015

Do you have all the parts you need?

To install your camera you will need the following components:

nEthernet cable (see Interface Cables)

nGPIOcable (see General Purpose Input/Output (GPIO))

nC-mount Lens (see Lens Mounting )

nInterface card (see Interface Card)

FLIR sells a number of the additional parts required for installation. To purchase, visit our Accessories page.

Do you have a downloads account?

Our downloads page has many resources to help you operate your camera effectively, including:

nSpinnaker SDKsoftware, including drivers (required for installation)

nFirmware updates and release notes

nDimensional drawings and CADmodels

nDocumentation

To access the software and firmware downloads you must have a downloads account.

1. Go to the FLIR website.

2. In the upper right corner, click Register.

3. Complete the form, then click Register.

After you submit your registration, you will receive an email with instructions on how to activate your account.

10/27/2017

Imaging Solutions Inc.

FLIROryx®Installation Guide 3

3 Oryx Installation

3.2 Installing Your Interface Card and Software

1. Install your Interface Card

Ensure the card is installed per the manufacturer's instructions.

Connect the internal IDE or SATApower connector on the card to the computer power

supply.

Alternatively, use your PC's built-in host controller, if equipped.

Open the Windows Device Manager. Ensure the card is properly installed. Ethernet cards appear under Network

Adapters. An exclamation point (!) next to the card indicates the driver has not yet been installed.

2. Install the Spinnaker® Software

Note: For existing users who already have Spinnaker installed,

we recommend ensuring you have the latest version for optimal

performance of your camera. If you do not need to install

Spinnaker, use SpinView to install and enable drivers for your

card.

a. Login to the Downloads page.

b. Select your Product Family,Camera Model and Operating System from the drop-down lists.

c. Click on the Software search results to expand the list.

d. Click the appropriate link to begin the download and installation.

After the download is complete, the Spinnaker setup wizard begins. If the wizard does not start automatically,

double-click the .exe file to open it. Follow the steps in each setup dialog.

3. For Ethernet cards: Enable jumbo frames

a. In Start->All Programs-> Point Grey Spinnaker SDK->SpinView, right click on the Network Adapter

and select Adapter Configuration, then select IP Configuration.

b. Click Open Network Connections.

c. Click Change Settings.

d. Click on the Advanced tab and from the Settings list select Jumbo Packet.

e. Set the Value to 9014 Bytes and click OK.

10/27/2017

Imaging Solutions Inc.

FLIROryx®Installation Guide 4

3 Oryx Installation

3.3 Installing Your Oryx

1. Attach a Lens

Unscrew the dust cap from the lens holder to install a lens.

2. Connect the interface Card and Cable to the Camera

Plug the interface cable into the host controller card and the camera. The cable jack

screws can be used for a secure connection.

When the camera is first connected, the operating system automatically installs the camera driver. Camera

drivers are available with the Spinnaker SDK installation.

3. Plug in the GPIO connector

GPIOis used for power, trigger, and strobe.

4. Configure IPSettings

By default, a dynamic IPaddress is assigned to the camera according to the DHCP protocol. If DHCP addressing

fails, a link-local address is assigned. If necessary, change the IPaddress of the camera to be on the same subnet

as the NIC.

5. Confirm Successful Installation

Run the SpinView application: Start->All Programs-> Point Grey Spinnaker->SpinView

The SpinView application can be used to test the camera's image acquisition capabilities.

Changes to your camera's installation configuration can be made using the SpinView application.

10/27/2017

Imaging Solutions Inc.

FLIROryx®Installation Guide 5

3 Oryx Installation

3.4 Powering Your Oryx

Power is provided externally through the GPIO interface: 12 - 24 V. Power consumption is 15W maximum, 11 W

nominal.

The camera does not transmit images for the first 100 ms after power-up. The auto- exposure and auto- white

balance algorithms do not run while the camera is powered down. It may therefore take several images to get a

satisfactory image.

When the camera is power cycled (power disengaged then re-engaged), the camera reverts to its default factory

settings, or if applicable, a saved user set.

10/27/2017

Imaging Solutions Inc.

FLIROryx®Installation Guide 6
