General Aircraft Data
USER MANUAL 4
The aircraft is a 3D printed UAV platform in a size that combines compactness
and high flight performance. Talon 1400 is in the popular layout with single
push propeller. The design focuses on optimizing flight performance as
possible, accommodating large battery pack and additional equipment, and
modularity. The geometry was carefully refined and studied using CFD and real-
world flight tests. Using optimal equipment and a large 4S6P battery, you can
achieve a flight time of about 4 hours. Easy accessibility for everyone and the
possibility of using different types of equipment is also an important aspect.
The aircraft has two tail variants to fit popular motor sizes. You can decide
which motor you will use. In addition, the nose is also available in two versions
and is fully detachable. You can choose a version with a VTX placed on the nose
along with a 19x19mm FPV camera or a clean option, with the FPV camera
alone. In addition, the nose as well as several other important parts are
available in STEP format, which allows easy editing and customization for more
individual needs. If you need to customize the nose to mount another payload
then you can easily do so. You can have several versions of the nose and
change them during the life of the model depending on the needs of the flight.
