Flick G1 Manual de usuario
PRODUCT MANUAL
V.4
FLICK G1
OPTICAL
MOUSE
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
SOFTWARE INSTALLATION
DOWNLOAD SOFTWARE INSTALLER,
FROM DOWNLOAD.FNATIC.COM
RUN THE INSTALLER IF YOU ARE PROMPTED BY ANY POP’UPS DUR-
ING THE INSTALLATION, PLEASE ACCEPT (IT IS
A REQUIREMENT FOR THE SOFTWARE TO RUN
PROPERLY).
WHEN INSTALLATION IS COMPLETE, PLEASE
REBOOT YOUR COMPUTER
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
CONTENTS
FEATURES 1
FEATURE DESCRIPTION 2
FUNCTIONS 3
BASIC SETTINGS 4
BUTTON ASSIGNMENT 5
COLOR SETTINGS 6
MACRO RECORDER 7
PRO TIPS 8
WARRANTY TERMS 9
PRODUCT SPECS 10
1
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
FEATURES
Made with the solely purpose to give the E-sports gamer a keen edge over its opponents, the Fnatic Gear
FLICK has been designed with a performance driven components and interesting features. The curvature
of the body, yet uncomplicated but ergonomically shape has been studied through countless of hours,
carved from clay and in the end approved by the Fnatic Teams. Additionally, the Fnatic Gear FLICK features
seven programmable buttons and scroll wheel, three user proles, macro recorder and a customizable
LED-lightning system, making it completely customizable to your personal preferences.
PIXART 3310 SENSOR
The latest optical LED sensor on that market which focus on performance in terms of optimal tracking
speed and acceleration apart from other sensors that push for more CPI. Performs best of all sensors on
the market and is the rst choice of sensor for any member of the Fnatic teams.
OMRON SWITCHES
Omron switches with a MTBF of 10M clicks is chosen for the Left and Right click ensures a long life time
FLICK mouse.
DRAG REDUCTION CORD
The exit of the cord support has been angled upward in a 30 degree angle.
This prevents the cord from touching the surface in front of the mouse and in that way reducing the drag
of the cord.
COLOR SYSTEM
The scroll wheel is equipped with a RGB LED that lights up the scroll wheel.
The RGB LED can be congured in any color preferred by the end-user as well as be congured in various
brightness modes.
ONBOARD MEMORY
An onboard memory that stores up to three proles with three CPI steps each, as well as macros and light
congurations. Gives the user the ability to smoothly switch between systems without any hassle.
2
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
FEATURE DESCRIPTION
EXAMPLES
LED’s lit while either Prole, CPI or both modes are active.
• If the user only has assigned a CPI changing function to the mouse,
the level LED’s present the CPI levels in orange.
• If both CPI and Prole functions is assigned, Orange is the primary
color which shows the CPI level. If the user decides to change prole
the LED’s change to white while the user is using a Prole changing
function.
• If only a Prole changing function is assigned, White is the primary
color which show the current Prole level. CPI level is not shown
since there isn’t a way to change it
• If none of the Prole or CPI changing functions are assigned, none
of the LED’s are lit
SCROLL WHEEL LED
Personalize your mouse by customizing the RGB LED in the scroll
wheel to any color you desire.
Pro Tip - A unique color can be set for each user prole
PROFILE LEVEL/CPI INDICATOR
Pressing the Prole cycle button cycles through three user dened
Prole levels. The number of lit LEDs in white corresponds to which
Prole level that is active.
White light indicates the current Prole level
Orange light indicates the current CPI level
Pro Tip - You can assign a button via the software to switch between
CPI. The number of lit LEDs in orange corresponds to which CPI level
is active.
3
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
FUNCTIONS
The graphical interface contains of three buttons at the top which indicate which Prole that currently
is selected, on the right you nd the Backup/Restore functions in which you can Backup a the currently
selected Prole.
Beneath the Proles you nd the feature tabs where you can switch between; Basic Settings, Button
Assignment and Color Settings, to the right you have the Macro recorder. A more detailed explanation of
each of the features can be found in separate sections of the manual.
In the far down left corner the Restore Default button is located which Restores the mouse to its default
settings.
In the main header of the software window you nd the FW (Firmware) and SW (Software) versions.
Pro tip - Do not forget to back up your proles to a local storage device before restoring the mouse to its
default settings.
Pro tip - It is not necessary to run the settings software to change proles; the software is only needed to
setup and customize proles. Once set, proles are stored in the internal memory and will remain saved
until the mouse is restored to its default settings.
Pro tip - Proles can also be saved to an external device, such as a USB stick. This allows you take your
settings with you when you are not playing using your own system and/or mouse, or wish to share your
favorite settings with a friend
4
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
BASIC SETTINGS
CPI SETTINGS
CPI (Counts Per Inch) is an expression of how
many counts that will be reported by the mouse
when it is moved one inch, a higher CPI indicates
therefore a higher mouse cursor velocity.
The horizontal and vertical CPI axes can as well
be separated from each other resulting in a higher
or lower speed in one axis.
Each prole contains of three levels which
corresponds to the CPI level indicator that is
located on the mouse.
POINTER SENSITIVITY
The Pointer Sensitivity is a operating system
setting which controls the speed of the mouse
cursor
(This function is global and used across all
proles)
Pro tip - We strongly encourage leaving this at six
(6). Six is the direct translation of data from the
mouse to the OS – anything below or above 6 gets
resampled by the OS, which could affect mouse
functionality.
DOUBLE CLICK SPEED
The Double Click Speed is a operating system
setting which controls how fast you would need to
double click the Left mouse button to for example
execute a program which you double click on.
(This function is global and used across all
proles)
DOUBLE CLICK SPEED
The Double Click Speed is a operating system
setting which controls how fast you would need to
double click the Left mouse button to for example
execute a program which you double click on.
(This function is global and used across all
proles)
SCROLL SPEED
Scroll Speed is an operating system deciding the
incremental movement of rows per scroll step.
Scroll by page indicates that instead of scrolling
across rows you scroll one page at a time.
(This function is global and used across all
proles)
POLLING RATE
The polling rate represents how often the mouse
communicates with the computer.
Pro tip - E-Sports professionals use 1000Hz
5
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
BUTTON ASSIGNMENT
Every button on the FLICK is fully customizable.
To recongure a button, click on its respective dropdown, a menu will display all the available commands.
Buttons can be also be disabled to avoid miss-clicks when not being used.
When you are happy with your changes, press the Apply button, and the new commands are saved.
HOW TO ASSIGN A FUNCTION
A. Identify a button that you want to assign a function to
B. Locate the corresponding dropdown for that button
C. Select the preferred function
Pro tip - As a safety precaution, the software will not allow you save to without having “Left click” or “Right
click” functionality assigned.
Pro tip - As a safety precaution, the software will not allow you save to without having “Left click” or “Right
click” functionality assigned.
A
B
6
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
COLOR SETTINGS
The scroll wheel of the FLICK Gaming Mouse have an LED that is customizable in 16 million different
colors. The LED’s can be congured in various brightness modes, a rainbow effect as well as been turned
of
The color settings is divided into two different areas; Color selection and Light conguration.
Turn on the LED by click the Off/On button [A]
The currently mixed color [H]
HOW TO PICK A COLOR
1a. Select a color with the Color slider [B]
OR
1b. Turn on Color cycle [G]
Color cycle switch cycles between all colors available
2. Select the Saturation [C] of that the selected color
(equals the amount of white that is mixed into the color)
HOW TO MODIFY THE LIGHT CONFIGURATION
3. Select one different brightness modes [D] that is available
(brightness congurations cannot be selected while Color cycle is enabled)
4a. If the mode CUSTOM were chosen you can specify the brightness [E] of the LED
OR
4b. If any of the other modes were chosen, you can set the Interval [F], in seconds, of that mode.
The interval slider does also control the Color cycle.
B
C
D
E
F
A
G H
7
FLICK OPTICAL GAMING MOUSE PRODUCT MANUAL
MACRO RECORDER
The macro recorder can record up to 254 actions where one key press is two actions, means that you can
record a 128 characters long macro.
While a macro is executed it is played with 1ms delays between each of the actions.
A macro that is eight characters long will execute in 16ms
HOW TO RECORD A MACRO
1. Press the record button [A]
2. Type the macro
The recorded keyboard and mouse clicks will be displayed in the Macro Recorder area [B]
3. Press the record button a second time [A]
4. Type a name in the name eld [C]
5. Press save [E]
MACRO LIBRARY
Recorded macros will be shown in the Macro Library [F] area where, the macros as well can
be deleted.
A ED
B
F
