Flash F7100520 Manual de usuario

LED MOVING HEAD

PIXEL ZOOM 12x40W

User Manual

Instrukcja Obsługi

F7100520

Please keep this User Manual for future

      

another user, be sure that they also receive

this instruction booklet.

Unpack and check carefully there is no

transportation damage before using the



Before operating, ensure that the voltage

and frequency of power supply match the



It’s important to ground the yellow/green

conductor to earth in order to avoid electric

shock.

Disconnect main power before servicing

and maintenance.





only, but always by taking its base.

     

Don’t operate it where the temperature is

higher than this.







          

replaced if they are visibly damaged.

In the event of serious operating problem,

     



carried out by unskilled people can lead to

damage or malfunction. Please contact the

nearest authorized technical assistance

center. Always use the same type spare

parts.

Do not connect the device to any dimmer

pack.

Do not touch any wire during operation

and there might be a hazard of electric

shock.

To prevent or reduce the risk of electrical



rain or moisture.



visibly damaged.

Do not look directly at the LED light



2. SAFETY INFORMATION

1. INTRODUCTION

    LED MOVING HEAD PIXEL ZOOM 12x40W.

        



WARNING!

User Manual •Instrukcja Obsługi

LED MOVING HEAD ZOOM 12x40W •Art No F7100520









system with big cooling fan.



The unit should be mounted via its screw

holes on the bracket. Always ensure that



and slipping while operating. Always

ensure that the structure to which you

are attaching the unit is secure and is

       

5.1 Connecting DMX signal

     



4. INSTALLATION

5. CONNECTION

3. PRODUCT INFORMATION

















of the unit’s weight. Also always use a



weight of the unit when installing the



 

place where is out of the touch of people

and has no one pass by or under it.

      







FEMALE

XLR

GROUND

DMX +

DMX -

MALE

XLR

CAUTION!     

DMX signal has to be terminated with a







DMX

Controller DMX 512 DMX 512

The connection is performed using



    

operated by qualified personnel.

5.2 Voltage specification

Input Voltage Total Power Frequency

100~240V 550W 50/60Hz

5.3 Connecting power supply

CAUTION!

or repair can be made only on the manufacturer or by a person with

appropriate permissions.

Make sure that the power grid supply

parameters are consistent with device

parameters and limitations are not



User Manual •Instrukcja Obsługi

6.1 CH21 Mode

6. DMX CHANNELS

LED MOVING HEAD ZOOM 12x40W •Art No F7100520

CH Function Value Description

1Pan 0-255 0-540°

2Pan ne 0-255

3Tilt 0-255 0-220°

4Tilt ne 0-255

5Pan/Tilt spead 0-255 Fast - Slow

6Zoom 0-255 Wide 45°- Narrow 5°

7Dimmer 0-255 0-100%

8Strobe 0 Open

1-84 Strobe

85-170 Pulse

171-255 Random

9Red 0-255 0-100%

10 Green 0-255 0-100%

11 Blue 0-255 0-100%

12 White 0-255 0-100%

13 CTC 0 Open

1-255 Warm - Cold

14 Color Macro 0 Open

1-30 Red

31-40 Green

62-92 Blue

93-123 White

124-154 Yellow

155-185 Magenta

186-261 Cyan

217-255 White

15 Macro 0-20 Open

21-32 Macro 1

33-45 Macro 2

46-58 Macro 3

CH Function Value Description

59-71 Macro 4

72-84 Macro 5

85-97 Macro 6

98-110 Macro 7

111-123 Macro 8

124-136 Macro 9

137-149 Macro 10

150-162 Macro 11

163-175 Macro 12

176-188 Macro 13

189-201 Macro 14

202-214 Macro 15

215-227 Macro 16

228-255 Macro 17

16 Macro Rate 0-255 Fast - Slow

17 Red background 0-255 0-100%

18 Green background 0-255 0-100%

19 Blue background 0-255 0-100%

20 White background 0-255 0-100%

21 Reset 0-244 Open

245-255 Reset

User Manual •Instrukcja Obsługi

6.2 CH 61 Mode

LED MOVING HEAD ZOOM 12x40W •Art No F7100520

CH Function Value Description

1Pan 0-255 0-540°

2Pan ne 0-255

3Tilt 0-255 0-220°

4Tilt ne 0-255

5Pan/Tilt spead 0-255 Fast - Slow

6Zoom 0-255 Wide 45°- Narrow 5°

7Dimmer 0-255 0-100%

8Strobe 0 Open

1-84 Strobe

85-170 Pulse

171-255 Random

91 Red 0-255 0-100%

10 1 Green 0-255 0-100%

11 1 Blue 0-255 0-100%

12 1 White 0-255 0-100%

13 2 Red 0-255 0-100%

14 2 Green 0-255 0-100%

15 2 Blue 0-255 0-100%

16 2 White 0-255 0-100%

17 3 Red 0-255 0-100%

18 3 Green 0-255 0-100%

19 3 Blue 0-255 0-100%

20 3 White 0-255 0-100%

21 4 Red 0-255 0-100%

22 4 Green 0-255 0-100%

23 4 Blue 0-255 0-100%

24 4 White 0-255 0-100%

25 5 Red 0-255 0-100%

26 5 Green 0-255 0-100%

27 5 Blue 0-255 0-100%

28 5 White 0-255 0-100%

CH Function Value Description

29 6 Red 0-255 0-100%

30 6 Green 0-255 0-100%

31 6 Blue 0-255 0-100%

32 6 White 0-255 0-100%

33 7 Red 0-255 0-100%

34 7 Green 0-255 0-100%

35 7 Blue 0-255 0-100%

36 7 White 0-255 0-100%

37 8 Red 0-255 0-100%

38 8 Green 0-255 0-100%

39 8 Blue 0-255 0-100%

40 8 White 0-255 0-100%

41 9 Red 0-255 0-100%

42 9 Green 0-255 0-100%

43 9 Blue 0-255 0-100%

44 9 White 0-255 0-100%

45 10 Red 0-255 0-100%

46 10 Green 0-255 0-100%

47 10 Blue 0-255 0-100%

48 10 White 0-255 0-100%

49 11 Red 0-255 0-100%

50 11 Green 0-255 0-100%

51 11 Blue 0-255 0-100%

52 11 White 0-255 0-100%

53 12 Red 0-255 0-100%

54 12 Green 0-255 0-100%

55 12 Blue 0-255 0-100%

56 12 White 0-255 0-100%

57 CTC 0 Open

1-255 Warm - Cold

58 Color Macro 0 Open

1-30 Red

User Manual •Instrukcja Obsługi

LED MOVING HEAD ZOOM 12x40W •Art No F7100520

CH Function Value Description

31-40 Green

62-92 Blue

93-123 White

124-154 Yellow

155-185 Magenta

186-216 Cyan

217-255 RGBW

59 Macro 0-20 Open

21-25 Red

26-31 Green

32-37 Blue

38-43 Yellow

44-49 Magenta

50-55 Cyan

56-61 RGBW

62-67 Macro 1

68-73 Macro 2

74-79 Macro 3

80-85 Macro 4

86-91 Macro 5

92-97 Macro 6

98-103 Macro 7

104-109 Macro 8

110-115 Macro 9

116-121 Macro 10

122-127 Macro 11

128-133 Macro 12

134-139 Macro 13

140-145 Macro 14

146-151 Macro 15

152-157 Macro 16

158-163 Macro 17

CH Function Value Description

164-169 Macro 18

170-175 Macro 19

176-181 Macro 20

182-187 Macro 21

188-193 Macro 22

194-199 Macro 23

200-205 Macro 24

206-211 Macro 25

212-217 Macro 26

218-255 Random

60 Macro Rate 0-255 Fast - Slow

61 Reset 0-244 Open

245-255 Reset
