Introduction

1.2

Introduction

IntroductionIntroduction

WELCOME TO THE FISKER

FAMILY

From everyone at Fisker, thank you for

purchasing one of our vehicles.

Your Karma is designed to deliver

uncompromised responsible luxury and

performance - Pure Driving Passion.

We are committed to providing you with an

ownership experience that is second to

none, and we look forward to serving you in

the years ahead.

USING THIS MANUAL

For your own safety, follow the instructions

and warnings contained in this manual.

Ignoring them could result in damage to the

vehicle or personal injury to you or others.

Vehicle damage caused by failing to follow

instructions is not covered by the New

Vehicle Limited Warranty.

Keep this manual in your vehicle as a

reference for the safe and enjoyable use of

your vehicle. Should you resell your car,

leave this manual with it for the next owner.

If you are unable to find the information you

need, it may be contained within one of the

additional documents included in your

Owner’s literature pack:

•Quick Reference Guide - a summarized

version of this document allowing you to

quickly familiarize yourself with the

vehicle.

•Touch-screen User’s Manual - describes

how to use the features of the touch-

screen.

•New Vehicle Limited Warranty and

Servicing - details of the vehicle

warranty and servicing requirements for

your vehicle.

•Tire Warranty - details the warranty for

the vehicle’s tires.

SYMBOLS GLOSSARY

The following symbols used within this

manual call your attention to specific types

of information.

WARNING: Indicates either an

instruction which must be followed

precisely, or information that should be

considered with great care in order to avoid

the possibility of personal injury or injury to

others.

CAUTION: Indicates either an

instruction which must be followed

precisely, or information that should be

considered with great care in order to avoid

the possibility of damage to your vehicle.

This symbol identifies instructions

that should be observed in order to

prevent unnecessary damage to the

environment.

NOTES ABOUT THIS MANUAL

All specifications and descriptions are

accurate at the time of printing. Because

improvement is a constant goal at Fisker

Automotive, we reserve the right to make

changes at any time, without notice and

without obligation.

Note: This manual applies to all Fisker

Karmas. As a result, you may find some

explanations for equipment or options not

installed on your vehicle

Owner's Handbook - US English.book Page 2 Friday, June 22, 2012 11:28 AM

Information About Your Vehicle

1.3

Information About Your Vehicle

ELECTRIC VEHICLE

PRECAUTIONS

MAINTENANCE AND REPAIRS TO

YOUR VEHICLE

Fisker Automotive recommends having

maintenance and repairs for your Karma

performed by an authorized Fisker Retailer.

To locate your nearest authorized Fisker

Retailer, go to www.fiskerautomotive.com

or contact Fisker Consumer Affairs.

BODY REPAIRS

If you're involved in a collision, you want

your vehicle to be returned to its pre-

accident condition when repaired. That's

why it is important to make sure your

vehicle is repaired with only genuine Fisker

Automotive parts.

Some repair shops and insurance

companies may suggest using non original

equipment or salvaged parts to save

money. However, these parts do not meet

Fisker's high standards for quality, fit and

corrosion resistance. In addition, non

original equipment and salvaged parts (and

any damage or failures they may cause) are

not covered by any Fisker warranty.

The best way to ensure that your vehicle is

repaired with genuine Fisker Automotive

parts is to take it to a Fisker Retailer. Each

Retailer works with selected collision repair

centers that meet Fisker's strict

requirements for training, equipment,

quality, and customer satisfaction. These

repair centers use genuine Fisker

Automotive parts exclusively in the repair of

Fisker vehicles.

IMPORTANT

Your Fisker Karma is an electric vehicle

with a range-extending gasoline engine.

The Karma has both high-voltage DC and

AC systems as well as a 12-volt system.

Both the DC and AC high voltage systems

are very dangerous and can cause

personal injury, severe burns, electric

shock and even fatal injury unless

appropriate precautions are taken.

Always observe and obey the instructions

on labels attached to components on the

vehicle - they are there for your safety.

Do not touch, attempt to remove or

replace any high voltage parts, wiring

(identified by the orange outer sleeving) or

connectors.

If the vehicle is involved in an accident, do

not touch any high voltage wiring,

connectors or the components

connected to the wiring.

If a vehicle fire occurs, extinguish it with a

Class D powder-type fire extinguisher.

Owner's Handbook - US English.book Page 3 Friday, June 22, 2012 11:28 AM

Information About Your Vehicle

1.4

Information About Your Vehicle

VEHICLE MODIFICATIONS

WARNING: The installation of non-

approved parts and accessories, or

the carrying out of non-approved

modifications, may be dangerous and could

affect the safety of the vehicle and

occupants and also invalidate the terms and

conditions of the vehicle warranty.

WARNING: Fisker Automotive will not

accept any liability for death, personal

injury or damage to property which may

occur as a direct result of non-approved

modifications or the installation of non-

approved accessories.

If you have a disability which may require

modification to the vehicle, please contact

Fisker Automotive before any modifications

are made.

QUALITY CONTROL

You may have noticed a few miles (kms) on

the odometer when you took delivery of

your Karma. This is a result of the

comprehensive process used to ensure the

quality of your vehicle.

This process includes extensive

inspections during and after production.

The final inspection takes place at the

selling Retailer and includes a road test

conducted by a trained Fisker Automotive

Technician.

CALIFORNIA PROPOSITION 65

WARNING: Certain vehicle

components contain or emit

chemicals known to the State of California

to cause cancer and birth defects or other

reproductive harm. In addition, certain fluids

contained in vehicles and certain products

of component wear contain or emit

chemicals known to the State of California

to cause cancer and birth defects or other

reproductive harm.

CALIFORNIA PERCHLORATE

ADVISORY

WARNING: Certain components of

this vehicle such as air bag modules,

seat belt pre-tensioners and Lithium

batteries may contain Perchlorate Material -

- Special handling may apply for service or

vehicle end of life disposal. See http://

www.dtsc.ca.gov/hazardouswaste/

perchlorate.

Owner's Handbook - US English.book Page 4 Friday, June 22, 2012 11:28 AM

Information About Your Vehicle

1.5

DATA RECORDING

Service data recording

Service data recorders in your vehicle are

capable of collecting and storing diagnostic

information about your vehicle. This

potentially includes information about the

performance or status of various systems

and modules in the vehicle such as engine,

throttle, steering or brakes. In order to

properly diagnose and service your vehicle,

Fisker Automotive and service facilities may

access vehicle diagnostic information

through a direct connection to your vehicle.

Event data recording

This vehicle is equipped with an Event Data

Recorder (EDR). The main purpose of an

EDR is to record, in certain crash or near

crash-like situations, such as an air bag

deployment or hitting a road obstacle, data

that will assist in understanding how a

vehicle's systems performed. The EDR is

designed to record data related to vehicle

dynamics and safety systems for a short

period of time, typically 30 seconds or less.

The EDR in this vehicle is designed to

record such data as:

•How various systems in your vehicle

were operating;

•Whether or not the driver and passenger

safety belts were buckled/fastened;

•How far (if at all) the driver was

depressing the accelerator and/or brake

pedal; and,

•How fast the vehicle was traveling;

•Where the driver was positioning the

steering wheel.

These data can help provide a better

understanding of the circumstances in

which crashes and injuries occur.

Note: EDR data are recorded by your

vehicle only if a non-trivial crash situation

occurs; no data are recorded by the EDR

under normal driving conditions and no

personal data (e.g., name, gender, age, and

crash location) are recorded. However,

other parties, such as law enforcement,

could combine the EDR data with the type

of personally identifying data routinely

acquired during a crash investigation.

To read data recorded by an EDR, special

equipment is required, and access to the

vehicle or the EDR is needed. In addition to

the vehicle manufacturer, other parties,

such as law enforcement, that have the

special equipment, can read the information

if they have access to the vehicle or the

EDR.

Owner's Handbook - US English.book Page 5 Friday, June 22, 2012 11:28 AM

Consumer Information

1.6

Consumer Information

IF YOU NEED ASSISTANCE

Both Fisker Automotive and your Fisker

Retailer are dedicated to serving your

automotive needs. Your complete

satisfaction is our first priority. Should you

have a problem or concern, please take the

following steps to ensure the quickest

possible response:

Step 1 - Discuss the situation with a

Retailer manager, such as the service

manager or customer satisfaction manager.

If necessary, ask the Retailer owner or

general manager for assistance. In most

cases, a satisfactory solution can be

reached at this step.

Step 2 - If the Retailer does not address

your concern to your satisfaction, call the

Fisker Consumer Affairs at:

1 (855) 575 7577

You may also write to us at:

Fisker Consumer Affairs Department

5515 East La Palma

Anaheim, CA 92807.

Whether calling or writing, please provide

the following information:

•17-digit Vehicle Identification Number

(VIN) found on the vehicle registration

paperwork and on the certification label

located on the driver's door pillar

•Current vehicle odometer reading

•Name of your selling and servicing

Fisker Retailers

•Your day and evening contact telephone

numbers

•Your email address

REPORTING SAFETY DEFECTS

United States

If you believe that your vehicle has a defect

which could cause a crash or could cause

injury or death, you should immediately

inform the National Highway Traffic Safety

Administration (NHTSA) in addition to

notifying Fisker Automotive.

If NHTSA receives similar complaints, it

may open an investigation, and if it finds

that a safety defect exists in a group of

vehicles, it may order a recall and remedy

campaign. However, NHTSA cannot

become involved in individual problems

between you, your dealer, or Fisker

Automotive.

To contact NHTSA, you may call the Vehicle

Safety Hotline toll-free at 1-888-327-4236

(TTY: 1-800-424-9153); go to

http://www.safercar.gov; or write to:

Administrator

National Highway Traffic Safety

1200 New Jersey Avenue SE.

Washington, DC 20590.

You can also obtain other information about

motor vehicle safety from

http://www.safercar.gov.

Canada

If you believe that your vehicle has a defect

which could cause a crash or could cause

injury or death, you should immediately

inform Transport Canada, in addition to

notifying Fisker Automotive.

To contact Transport Canada, call their toll-

free number: 1-800-333-0510.

Owner's Handbook - US English.book Page 6 Friday, June 22, 2012 11:28 AM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Automóvil de Fisker

Fisker

Fisker OCEAN ELECTRIC Manual de usuario

Manuales populares de Automóvil de otras marcas

Toyota

Toyota 2000 Tundra Manual de usuario

CITROËN

CITROËN DS4 DSign Manual de usuario

Lexus

Lexus 2015 CT 200h Manual de usuario

Cadillac

Cadillac CTS 2008 Manual de usuario

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manual de usuario

Porsche

Porsche Boxster S Manual de usuario

GMC

GMC 2010 Savana 1500 Cargo Manual de usuario

KIAM

KIAM SPORTAGE 2014 Manual de lista de piezas

GMC

GMC 2013 Terrain Instrucciones de montaje

GMC

GMC T-Series 1999 Manual de usuario

Mercury

Mercury 1998 Mystique Manual de usuario

Mercury

Mercury 2007 Mariner Manual de usuario

Mazda

Mazda 2007 Mazdaspeed 3 Guía

Mazda

Mazda 2014 CX-5 Manual de usuario

GMC

GMC Chevrolet Express 2022 Manual de usuario

GMC

GMC 1997 Jimmy Manual de usuario

Chevrolet

Chevrolet 2012 Malibu Manual de usuario

Cadillac

Cadillac 2010 Escalade Manual de usuario
