First Alert 2190F Cómo utilizar

Operation & Installation Guide

Model 2190F 2575F 2700F 2702F

Read These Instructions Very Carefully!

Limited Warranty

Home and Ofﬁce Security Safes

MFFS90F75F00F02FE0610

ENGLISH

LIFETIME AFTER FIRE REPLACEMENT GUARANTEE

If your First Alert® Firesafe is ever damaged by a ﬁre, BRK will replace it with a comparable model at

no charge to the consumer. Freight on the replacement unit is not included in the guarantee and

must be paid by the consumer.

For claims, submit your name and address, a photo of the damaged safe along with its Model

Number, and a copy of the Fire Department report to BRK Consumer Affairs as proof of loss. Once

the information is received, Consumer Affairs will contact you with further instructions.

LIMITED WARRANTY

BRK Brands, Inc., (“BRK”) warrants that for a period of ﬁve (5) years from the date of purchase, this

product will be free from defects in material and workmanship. BRK, at its sole option, will repair or

replace this product or any component of the product found to be defective during the warranty

period. Replacement or repair will be made with a new or remanufactured product or component.

If the product is no longer available, replacement may be made with a similar product of equal or

greater value. This is your exclusive warranty.

This warranty is only valid for the original retail purchaser from the date of initial retail purchase and

is not transferable. You must keep the original sales receipt. Proof of purchase is required to obtain

warranty performance. BRK dealers, service centers, or retail stores selling this product do not have

the right to alter, modify or in any way change the terms and conditions of this warranty.

This warranty does not apply to the ﬁnish on the product. This warranty does not cover normal

wear and tear of parts or damage resulting from any of the following: negligent use or misuse of

the product, use contrary to the operating instructions, disassembly, repair or alteration by anyone

other than BRK or an authorized service center, improper installation, or exposure to extremes of heat

or humidity. Further, the warranty does not cover Acts of God, such as ﬁre, ﬂood, hurricanes and

tornadoes.

BRK shall not be liable for any incidental or consequential damages caused by the breach of any

express or implied warranty. BRK is also not responsible for: costs associated with removing or

installing the product; damage or loss of the contents of the product; nor for the unauthorized

removal of the contents; or damages incurred during shipment.

Except to the extent prohibited by applicable law, any implied warranty of merchantability or

ﬁtness for a particular purpose is limited in duration to the duration of the above Warranty Period.

Some states, provinces or jurisdictions do not allow the exclusion or limitation of incidental or

consequential damages or limitations on how long an implied warranty lasts, so the above limitations

or exclusion may not apply to you. This warranty gives you speciﬁc legal rights, and you may also

have other rights that vary from state to state, or province to province, or jurisdiction to jurisdiction.

If you have any questions that cannot be answered by reading this manual,call

Consumer Affairs at 1-800-323-9005

3901 Liberty Street Road, Aurora, IL 60504-8122

www.FirstAlert.com

Firesafe

MODEL 5190

Firesafe

MODEL 5700

For Your Protection

• Do not remove the Serial Number tag from the safe.

• Record all Safe Identiﬁcation Numbers on Safe Identiﬁcation

Record (last page).

• Save this manual and NEVER keep it inside the safe.

Page 1

Page 2

Page 3

Page 4

Page 6

Index

Safe Identiﬁcation Record

Model Number

Serial Number

Key Number

4-Number Combination

Recovering Lost Combinations

The following information is needed to provide you with your combination:

• Name / Address / Telephone

• Safe Model Number / Serial Number

• Key Number (located on the key and on the Emergency Override Key lock)

• E-mail address if available

Home and Ofﬁce Security Safes

Overview of Your Safe .....................................................

Opening & Closing Your Safe.........................................

Opening The First Time

Your Combination

Opening With Combination Dial

Closing & Locking The Safe

Additional Features: Shelves..........................................

Consumer Affairs ..............................................................

Your Safe’s Unique Identiﬁcation #’s

How To Contact Us

Ordering Replacement Keys

Recovering Lost Combinations

Use, Care and Maintenance ...........................................

RIGHT FOUR (4) turns and continue to:

LEFT TWO (2) turns and continue to:

RIGHT ONE (1) turn and continue to:

LEFT to:

Overview of Your Safe

WELCOME!

Your new First Alert® Fire Theft Safe™ will provide years of safe and secure

protection for your valuables, important documents and other personal items.

All First Alert® safes are designed and built using the highest manufacturing

standards to ensure maximum user satisfaction under a variety of conditions.

With proper care, your First Alert® safe will provide “Peace of Mind” for many

years to come.

Thank you and Enjoy!

The following list outlines the items and quantities of each included with

your new safe. Please carefully check the list to conﬁrm all items have been

received. If any item is missing, then please contact Customer Service

@ 1-800-323-9005.

Home and Ofﬁce Security Safes

Notes

Important: DO NOT RETURN SAFE TO STORE

If you are missing parts, have difﬁculty programming your safe or have any other questions pertaining

to its proper use and care, DO NOT RETURN your safe to the store. Please contact Consumer Affairs at

1-800-323-9005, 7:30 am – 5:00 pm Central Standard Time, Monday through Friday. To assist us in

serving you, please have the model number and date of purchase available when calling.

Package Contents

Models 2190F, 2575F, 2700F, 2702F

Operation & Installation Guide 1 ea

Companion Keys 2 ea

Storage Drawer Keys (2700, 2702) 2 ea

Removable Shelves (1 only for 2190) 2 ea

Shelf Support Clips (4 only for 2190) 8 ea

Firesafe

MODEL 5190

Firesafe

MODEL 5700

Opening & Closing Your Safe

Home and Ofﬁce Security Safes

Important: REDUCED LEVEL OF SECURITY

The safe is ONLY FULLY LOCKED after turning key to the locked position and spinning

the dial. For your security, we recommend always locking both the combination dial

and key lock for the highest level of protection & security.

Notes

Opening The First Time

The dial is preset to the fourth (last) number in the combination.

The safe door should open when you insert the Companion

Entry Key (with the round top), turn to the right and pull the door

open. The dial may move in transit, making it necessary to dial the

combination before opening the ﬁrst time We recommend

trying the following combination procedure with safe door open ﬁrst.

Your Combination

The combination for your safe can be found imprinted on the inside back

cover of this manual. It is a preset 4 number sequence that is unique to your

safe and cannot be changed. It is recommended that you keep this manual in

a secure place, but NEVER STORE THIS MANUAL INSIDE THE SAFE!

Opening With Combination Dial

1. Turn dial RIGHT (clockwise) three times to clear settings.

2. Start the dial on 0 (zero) to dial combination,

3. Turn dial RIGHT, passing ﬁrst combination number FOUR (4) times and

stop at number on ﬁfth time around.

4. Turn dial LEFT, passing second combination number TWO (2) times and

stop at number on third time around.

5. Turn dial RIGHT, passing third combination number ONE (1) time and

stop at number on the second time around.

6. Turn dial LEFT, to the last combination number and STOP.

7. Insert the key in the lock and turn key RIGHT, then move handle to the

open position and pull door open.

Closing & Locking The Safe

1. When open, the key is turned right (the unlocked position).

2. Close the safe door and turn the key to the left.

3. Handle will automatically move to closed position.

4. Remove the key and spin the combination dial twice.

Frequent Key-Only Access

When circumstances require frequent, quick and convenient access for limited

periods during the day, you may choose to keep the commbination positioned

on the last number and lock only the keylock. However, the safe is not fully

locked until spinning the dial.

Home and Ofﬁce Security Safes

Additional Features: Removable Shelves

Shelves

Adjustable & Removable Shelves

These models are designed with 5 position adjustable shelves to allow greater

ﬂexibility and further accommodate your particular security storage needs.

To Install:

Your Shelf and Shelf Support Clips have been

shipped inside your safe and wrapped for protection

from damage during shipping.

1. Remove Shelf and (4) Shelf Support Clips

from protective wrapping.

2. Determine the desired position of your shelf

and note the corresponding Support Guide

Slots (2 on each side of interior walls) that

are best suited to support the shelf in that

position.

3. Install the (4) Shelf Support Clips in the same

position on all four support guides.

4. Install shelf into position by placing it inside

the safe (tilting if necessary) at a point above

the desired position.

5. Once inside, lower it into position until

resting on Shelf Support Clips.

To change the position of the shelf:

Simply remove the shelf and reposition the (4) shelf

support clips by sliding them up and out of the

support slots and reinstalling them into the new

positions. Then reinstall shelf as described above.

SUPPORT

GUIDES

Important: REMOVING SHELF

If you remove the shelf, it is strongly recommended that you DO NOT

DISCARD it. You may lay the shelf ﬂat in the bottom of the safe to assure

full ﬂexibility in the future.

Use, Care and Maintenance

Safe Care and Maintenance

When properly maintained, your safe will continue to provide protection for

many years. In order to ensure optimum performance of your safe, please

follow these simple precautions:

Clean Hands - Do not attempt to operate combination dial if your hands have

excessive dirt, debris, or liquids on them. Under normal circumstances, it is not

necessary to wash your hands before using the safe.

Clean Safe – To clean the outside surface of your safe, it is recommended that

you use a mild cleaner (e.g., window cleaner) to avoid scratching or discoloring

the surface. Do not use abrasive cleansers.

For future reference, store this Operation and Installation Guide in a secure area

away from the safe. DO NOT DISCARD!

Appropriate Use of Your Safe

First Alert® ﬁre safes protect paper records and many other valuables.

Veriﬁed ﬁre protection for:

Memory sticks, CD’s & DVD’s, USB Drives.

This product is NOT INTENDED to protect audio or video cassettes, ﬂoppy discs,

data cartridges, ﬁlm and photos or photo negatives

Testing shows that the interior temperature of the safe remains below 350°F

(177°C) for 2 hours during a ﬁre up to 1700°F (927°C) when used properly. Your

safe must be closed and latched in order to properly protect the contents from ﬁre.

Moisture Warning

We recommend that you place delicate items such as pictures or intricate jewelry

into an air-tight container before storing them in your safe. Avoid placing your

safe in areas of high humidity. For optimum performance, the safe should be

opened and aired out for at least 20 minutes every two weeks.

Firearms Warning

This safe is not designed to store medication, items with combustible content,

guns or other weapons. Please contact BRK at 800-323-9005 or shop

www.FirstAlert.com for information about safes that can securely store your

ﬁrearms or medication.

Pearls

Because pearls sustain heat damage at temperatures below 350° F, we advise

that you DO NOT store pearls in this ﬁre safe.

Home and Ofﬁce Security Safes

Your Safe’s Unique Identiﬁcation Numbers

When contacting Consumer Affairs, you should be prepared to supply some

important information that speciﬁcally identiﬁes your safe. This information is

extremely important to assuring prompt and accurate customer assistance.

It is strongly recommended that you identify and record the following information

in the “Safe Identiﬁcation Record” form located on the inside back cover of this

manual:

Model Number

Serial Number

Key Number

Locating Model and Serial Numbers

Most First Alert® safes include a small metallic silver or gray tag afﬁxed to one

of the surfaces. This tag is usually located on the front or right side of the safe.

This tag contains the Serial Number, and on selected models a similar tag is

attached containing the Model Number. If a Model Number tag is not attached

to the safe, then it can be located on the front or side panel of the box that the

safe was packaged in. Write this number down for future reference.

Key Number

The Key Number is located on the key. If you do not have the key, the

number is also imprinted on the Key lock.

Important: DO NOT REMOVE TAGS!

In case your safe becomes inoperable or you lose your keys, these identiﬁcation

numbers will be needed to correct the problem. It is recommended that the

number tags remain in place on the safe. If removal is necessary, then they

should be attached to the inside back cover of the Operation and Installation

Guide. Store in a safe and secure place for future reference.

Consumer Affairs Consumer Affairs

How to Obtain Warranty Service

If service is required, do not return the product to your retailer. In order to

obtain warranty service, contact the Consumer Affairs Division at 1-800-323-9005,

7:30 am – 5:00 pm Central Standard Time, Monday through Friday. To assist us in

serving you, please have the model number and date of purchase available when

calling.

For Warranty Service return to:

BRK Brands, Inc.,

23610 So. Banning Blvd.

Carson, CA 90745

Ordering Replacement Keys

If a key becomes misplaced or you would like additional keys, you may conveniently

purchase them from our Consumer Affairs Department. You must supply the following

information to assure accurate processing:

• Name / Address / Telephone

• Safe Model Number / Serial Number

• Key Number (located on the key and on the Emergency Override Key lock)

• Number of keys requested

• E-mail address if available

Checks or Money Orders are required for orders received by mail and should be made

payable to First Alert. Contact our Consumer Affairs Department for costing information

prior to ordering.

Mail to: First Alert

Consumer Affairs

3901 Liberty Street Road

Aurora, IL 60504-8122

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Seguro de First Alert

First Alert

First Alert MMSKYE0709 Cómo utilizar

First Alert

First Alert 2601DF Cómo utilizar

First Alert

First Alert 2096DF-BDC Cómo utilizar

First Alert

First Alert 2087F-BD Cómo utilizar

First Alert

First Alert 3035DF Cómo utilizar

First Alert

First Alert 2583DF Cómo utilizar

First Alert

First Alert 2087F-BD Cómo utilizar

First Alert

First Alert 2484D - Executive Fireproof Safe Cómo utilizar

First Alert

First Alert 2087FA Cómo utilizar

First Alert

First Alert 2096DF Cómo utilizar

First Alert

First Alert 4003DFB Cómo utilizar

First Alert

First Alert 2054DF Cómo utilizar

First Alert

First Alert 2190DF Cómo utilizar

First Alert

First Alert LW-592117 Cómo utilizar

First Alert

First Alert 2025F Cómo utilizar

First Alert

First Alert 2077DF Cómo utilizar

First Alert

First Alert PROTECTOR 6720F Cómo utilizar

First Alert

First Alert 5200DF Manual de usuario

First Alert

First Alert 2070A Cómo utilizar

First Alert

First Alert 2096DF-BD Cómo utilizar

First Alert

First Alert 2087EF Cómo utilizar

First Alert

First Alert 1041864 Cómo utilizar

First Alert

First Alert 2087F Cómo utilizar

First Alert

First Alert ANTI THEFT SAFE 2074EF Cómo utilizar

Manuales populares de Seguro de otras marcas

Squire

Squire Stronghold Keysafe Manual de usuario

Phoenix

Phoenix FS0352C Hoja de información del producto

Phoenix

Phoenix KS0030E Series Manual de usuario

Vaultek

Vaultek 10 Series Hoja de especificaciones

Arregui

Arregui CLASS Manual de usuario

Beaumont

Beaumont SMART KEYBOX Manual de usuario

Honeywell

Honeywell 2077D - 1.21 Cubic Foot Anti-Theft Safe Manual de usuario

Hornady

Hornady SnapSafe Trunk Safe II Manual de usuario

SPORTS AFIELD

SPORTS AFIELD SA-HD5-BIO Manual de usuario

Honeywell

Honeywell 5912 Manual de usuario

Phoenix

Phoenix FS1280F Manual de usuario

Phoenix

Phoenix SS0992K Hoja de información del producto

Technomax

Technomax Trony Series Manual

SPORTS AFIELD

SPORTS AFIELD INSTINCT BIOMETRIC Series Manual de usuario

RICHTER CZECH

RICHTER CZECH LA Manual de operación

Olymp

Olymp GOsafe 110 Manual de usuario

Phoenix

Phoenix SS0100E Hoja de información del producto

Clarke

Clarke Strong-Arm CS1000K Manual de instrucciones
