Firecom UHW50X Manual de usuario
UHW50X
WIRELESS HEADSET
Quick Start Guide
Power
Right Push to Talk
Volume down /
Listen through volume down
Volume up /
Listen through volume up
(UHW505/507 only)
Press both arrows to
switch between volume
and listen through
Status LED
Volume Up
Volume down
Left Push to Talk
BASIC FEATURES — CONTROLS
Charge port
Adjustable
headstrap
Battery
door
Adjustable headband
Listen through
mute OFF (long press)
Listen through
mute ON (long press)
External radio
port
Microphone
BASIC FEATURES — CONTROLS
STATUS LED FUNCTIONALITY
Battery level and connection status
are both shown with the status LED.
Connection Status
When powered on,
the color of the LED ashes
indicates connection status.
On
Bluetooth
connected
DECT
pairing
DECT
connected
DECT + Bluetooth
connected
Battery Level
Number of pulses indicates
battery charge level.
LED color will vary depending on
connection type.
Charge Status
When plugged in, the color of the
LED indicates charge state. Slow
ashing indicates a charge fault.
Charging
Fully charged
Charge fault
1/8ʺ
NEW BLUETOOTH PAIRING (If Bluetooth equipped)
1: Turn o headset.
2: Turn on headset.
3: Headset enters
Bluetooth pairing mode.
10 min.
4: On phone, search for “Sonetics-HS-XX”. Password is “0000”.
BLUETOOTH USE
Answer Call Press left PTT button.
End Call Press left PTT button.
MIC POSITIONING
Position mic no more than 1/8″ from lips.
DECT PAIRING
For rst use:
1: Place Base Station into pairing
mode (see base station manual
for details).
2: Starting with the headset o, push and
hold Push To Talk, then add the Power
button and hold both until status LED
ashes red and green.
3: The status LED ashes green when
connection is successful. If it does
not, repeat the pairing process.
4hr 24hr
BLACK
1.5A Fuse
RED
18″ MAX
HEADSET CHARGING
Use only supplied adapter.
Vehicle wiring.
600-0385-00 Rev F
www.recom.com
800-527-0555
17600 SW 65th Ave
Lake Oswego, OR 97035 USA
© 2023 Firecom Corporation. All Rights Reserved.
The information in this document is subject to change without notice.
No part of this document may be copied or reproduced in any form
without the prior written consent of Firecom Corporation.
Scan code to access
complete manual or visit
recom.com/support
