1/ FIAT 500 SPECIFICATIONS http://media.chrysler.com

500 • Specifications

New 2012 FIAT 500

SPECIFICATIONS

Dimensions are in inches (millimeters) unless otherwise noted.

GENERAL INFORMATION

Body Style

A-segment hatchback

EPA Vehicle Class

Subcompact

Assembly Plant

Toluca, Mexico

Introduction Date

March 2011 as a 2012 model

ENGINE: 1.4-LITER SOHC 16-VALVE MULTIAIR®INLINE FOUR-CYLINDER

Availability

Standard — Fiat 500 Pop, Sport and Lounge

Type and Description

Inline four-cylinder, liquid-cooled

Displacement

83.48 cu. in. (1368 cu. cm)

Bore x Stroke

2.83 x 3.31 in. (72.0 x 84.0 mm)

Valve System

Belt-driven, MultiAir®, SOHC,16 valves, hydraulic end-pivot roller

rockers

Fuel Injection

Sequential, multi-port, electronic, returnless

Construction

Cast iron block with aluminum-alloy heads and aluminum-alloy

bedplate

Compression Ratio

10.8:1

Power (SAE net)

101 bhp (75 kW) @ 6,500 rpm (73.8 bhp/L)

Torque (SAE net)

98 lb.-ft. (133 N•m) @ 4,000 rpm

Max. Engine Speed

6,900 rpm (electronically limited)

Fuel Requirement

87 octane (R+M)/2 acceptable

91 octane recommended

Oil Capacity

4.0 qt. (3.8L) with dry filter

Coolant Capacity

4.6 qt. (14.4L)

Emission Controls

Dual three-way catalytic converters, heated oxygen sensors

and internal engine features(a)

Max. Gross Trailer Weight

Not rated for trailer tow

Estimated EPA Fuel Economy mpg (City/Hwy)

30/38 (5-speed manual)

27/34 (6-speed automatic)

Engine Assembly Plant

GEMA Engine Plant, Dundee, Mich.

(a) Meets Federal Tier 2 Bin 5 emission requirements and ULEV II requirements in California, Massachusetts, New York, Maine, Vermont,

Connecticut, Pennsylvania, Rhode Island, New Jersey, Oregon and Washington.

2/ FIAT 500 SPECIFICATIONS http://media.chrysler.com

500 • Specifications

TRANSMISSION: AISIN AUTOMATIC SIX-SPEED OVERDRIVE WITH AUTO STICK

Availability

Standard on 500 Lounge

Optional on 500 Pop and 500 Sport models

Description

Auto Stick driver-interactive manual control and electronically

modulated torque converter clutch

Gear Ratios

1st

4.044

2nd

2.371

3rd

1.556

4th

1.159

5th

0.852

6th

0.672

Reverse

3.193

Final Drive Ratio

4.103

Overall Top Gear

6.01

TRANSMISSION: C514 FIVE-SPEED MANUAL

Availability

Standard on 500 Pop and 500 Sport

Description

1st, 2nd gear: Double Cone 3rd, 4th, 5th, gear: Single Cone

Gear Ratios

1st

3.909

2nd

2.158

3rd

1.345

4th

0.974

5th

0.766

Reverse

3.818

Final-drive Ratio

3.733

ELECTRICAL SYSTEM

Alternator

105-amp — Standard all

Battery

500 CCA, maintenance free

3/ FIAT 500 SPECIFICATIONS http://media.chrysler.com

500 • Specifications

DIMENSIONS AND CAPACITIES(D)

Wheelbase

90.6 (2,300)

Track, Front

55.4 (1,406.8)

Track, Rear

55.0 (1,397.0)

Overall Length

139.6 (3,546.7)

Overall Width

64.1 (1,627.0)

Overall Height

59.8 (1,519.6)

Ground Clearance

4.1 (104.0)

Drag Coefficient (Cd)

0.35

Curb Weight, lb. (kg)

2,363 (1,074.0) — 5-MTX

2,434 (1,106.4) — 6-ATX

Weight Distribution, percent F/R

64/36 — 5-MTX

66/34 — 6-ATX

Fuel Tank Capacity, gal. (L)

10.5 (40)

(d) All dimensions measured at curb weight with standard tires.

ACCOMMODATIONS

Seating Capacity, F/R

2/2

Front Seat

Head room

38.9 (989.1)

37.6 (956.3) with sunroof

Legroom

40.7 (1,034.8)

Shoulder room

49.4 (1,254.8)

Hip room

47.9 (1,215.4)

Total seat travel

Driver — 8.2 (210.0)

Passenger — 8.2 (210.0)

EPA front row interior volume, cu. ft. (cu. m)

43.8 (1.239)

Rear Seat

Head room

35.6 (902.9)

Legroom

31.7 (805.1)

Knee clearance

3.8 (96.5)

Shoulder room

46.4 (1,177.5)

Hip room

1083.1 (42.6)

EPA second row interior volume, cu. ft. (cu. m)

30.2 (0.854)

Total Interior Volume, cu. ft. (cu. m)

85.1 (2.409)

EPA Luggage Compartment Volume, cu. ft. (cu. m)

9.5 (0.269)

EPA Interior Volume Index, cu. ft. (cu. m)

75.6 (2.140)

Trunk Liftover Height

27.7 (703.6)

4/ FIAT 500 SPECIFICATIONS http://media.chrysler.com

500 • Specifications

BODY

Layout

Transverse-mounted front engine, front-wheel drive

Construction

Unitized steel body

SUSPENSION

Front

MacPherson suspension, coil spring with twin-tube shock

absorbers and stabilizer bar — included with 500 Pop and 500

Lounge

Sport-tuned shock absorbers and springs — included with 500

Sport

Rear

Rear twist-beam axle with coil springs and twin-tube shock

absorbers — included with 500 Pop and 500 Lounge

Sport-tuned shock absorbers and springs — included with 500

Sport

STEERING

Type

Power rack and pinion with electric power steering (EPS) column

Overall Ratio

16.3:1

Turning Diameter (curb-to-curb)

30.6 ft. (9.32 m)

Steering Turns (lock-to-lock)

3.0

TIRES

Availability

Standard on 500 Pop and 500 Lounge

Size and type

185/55R15 BSW all-season

Mfr. and model

Continental ContiProContact or Firestone Firehawk GTH or Pirelli

Cinturato P7 A/S

Revs per mile (km)

906 (563)

Availability

Standard on 500 Sport

Size and type

195/45R16XL BSW all-season

Mfr. and model

Pirelli Cinturato P7 A/S or Continental ContiProContact

Revs per mile (km)

901 (560) or 911 (566)

5/ FIAT 500 SPECIFICATIONS http://media.chrysler.com

500 • Specifications

WHEELS

Availability

Standard on 500 Pop

Type and material

Steel wheels with tech silver painted wheel covers

Size

15 x 6.0

Availability

Optional on 500 Pop

Type and material

Cast-aluminum, five oval spoke design, fully painted tech silver

Size

15 x 6.0

Availability

Standard on 500 Lounge

Type and material

Cast-aluminum, nine split-spoke design, fully painted tech silver

Size

15 x 6.0

Availability

Optional on 500 Lounge

Type and material

Cast-aluminum premium finish, radial design, fully painted

premium silver

Size

15 x 6.0

Availability

Standard on 500 Sport

Type and material

Cast-aluminum, polished face with dark mineral gray painted

pockets

Size

16 x 6.5

BRAKES

Front

Rotor size and type

10.1 x 0.86 (257 x 22) vented

Caliper size and type

2.12 (54) single-piston with aluminum housing

Swept area

193 sq. in. (1,244 sq. cm)

Rear

Rotor size and type

9.4 x 0.4 (240 x 11) solid

Caliper size and type

1.33 (34) single-piston with aluminum housing

Swept area

153 sq. in. (984 sq. cm)


