m3x5mmbutton headscrews.Laythisaside.
Takefourm3x30 mmpillars,usingtheallenwrenchandm3x5mmbutton headscrew,attachthefour
pillarsto theholes in thesideframe.Makesurethattheled sarefacingtotheoutside.Takethe
oppositesideframe making suretheled sarefacingoutwardsandtheWeldpointsareon thesame end.
Donottightenthescrewsyet,Nowtakethemotorwithit smountandpositionit inthebottomslots
that arecutinthesideframes,snugdownthebutton headscrewsforthemotor.Now takethelanding
gearand position it sothelong endispointingdown.Nowtightenalleight button headscrews.
Go throughthesame procedurefortheremaining threeframes.
Inspecttheassemblies tobesurethat all themotorsandthelanding gearsareseatedproperly.
Whenassembledproperly, theFeiyuTechLogo swill befacing upright andtheWeldingpointswillall
belinedup.
Step2:Buildingthe Fuselageandattachingand Weldingthe Frames
tothe Fuselage.
UnpackthethreeFrameassemblies.Youwillnotice thattheyaremarkedwithan “A”ononeside
anda “B”ontheother.Theimportant oneistheonewiththeElectronics mountedon it.Takeeight
m3x25mmpillarsandsecurethemwiththebuttonheadscrews.Makesurethattheelectronicsare
facingupandtheledplugisonthebottom.Takeanotherfuselageplateinonehand and with the
othertakeaframe assembly,place theassemblywiththeweldpointspointingdownand insertit inthe
slotsprovidedon theelectronics fuselage.
Takefourbuttonheadscrewsandthefuselageplateandalign theplatewiththeholes forthepillars,
making surethattheotherdiecut holes lineupproperly.Lightlyscrewthethreebutton headscrews
intothepillars,nowtaketheremaining Frames and place themintheslotsprovided.
Once allframes areinsertedintothetopandbottomFuselageplates,tightenthefourbuttonhead
screwsandinsert theremainingfourscrewsandtightenthemas before.
InspecttheFrames andmakesurethattheweld pointsareseatedsnuglyintheirlocations.If
