GWP 10

Repair instructions

C-SC_CSSM

Version 1.0

2016-02-02

FEIN retains all rights of disposal, such as copying and circulation.

Page 1of 39

GWP 10

Contents

C-SC_CSSM

Version 1.0

2016-02-02

FEIN retains all rights of disposal, such as copying and circulation.

Page 2of 39

1. Models described

2. Technical data

3. Notes and requirements

4. Tools required

5. Lubricants and auxiliary substances required

6. Removal

7. Fitting

8. Connection diagram

GWP 10

1. Models described

C-SC_CSSM

Version 1.0

2016-02-02

FEIN retains all rights of disposal, such as copying and circulation.

Page 3of 39

These repair instructions describe how to repair the following models:

Model Order number

GWP 10 7 209 38 .. .. .

GWP 10

2. Technical data

C-SC_CSSM

Version 1.0

2016-02-02

FEIN retains all rights of disposal, such as copying and circulation.

Page 4of 39

Technical data

All the technical data can be found in the operating instructions for the model.

Test data

Up-to-date test data for all models can be found on the FEIN Extranet (Customer Service →Repair Guides).

Lubricants

The lubricants and container sizes available from FEIN can be found on the FEIN Extranet (Customer Service →Repair Guides).

Lists of spare parts

Lists of spare parts and exploded views are available online at www.fein.com

GWP 10

3. Notes and requirements

C-SC_CSSM

Version 1.0

2016-02-02

FEIN retains all rights of disposal, such as copying and circulation.

Page 5of 39

Please note

These instructions are only intended for persons with suitable technical training. It is assumed that the reader has mechanical and

electrical training.

Only use original FEIN spare parts.

Provisions

Please note that power tools may only be repaired, maintained and checked by a trained electrician, as improper repair can result in

serious risks to the user.

The provisions set out in DIN VDE 0701-0702 should be observed after repairs.

The relevant accident prevention regulations of the employer’s liability insurance associations are to be observed when

commissioning.

The German Equipment and Product Safety Act [ProdSG] applies for correct use.

Outside Germany, the regulations applicable in the relevant country must be observed.

GWP 10

4. Tools required

C-SC_CSSM

Version 1.0

2016-02-02

FEIN retains all rights of disposal, such as copying and circulation.

Page 6of 39

Standard tools

Special tools

Torx T20 Assembly aid 6 41 22 121 01 0

Cross-tip screwdriver PH1, PH2 Expansion wedge, 12 mm 6 33 05 009 01 3

Slotted screwdriver (small) Drawing-off socket cap 6 41 04 150 00 8

Combination pliers Chuck cone with 16 mm diameter 6 41 07 016 00 1

Plastic hammer Chuck cone with 17 mm diameter 6 41 07 017 00 0

Arbor press Chuck cone with 19 mm diameter 6 41 07 019 00 7

Punch 5 mm; 6 mm; 9 mm

Long-nosed pliers

Slide hammer

Inner puller

Sleeve 11 mm inner diameter

26 mm outer diameter

7 mm inner diameter

30 mm outer diameter

19 mm inner diameter

30 mm outer diameter

~16 mm inner diameter

19 mm outer diameter

8 mm inner diameter

~17 mm outer diameter

GWP 10

4. Tools required

C-SC_CSSM

Version 1.0

2016-02-02

FEIN retains all rights of disposal, such as copying and circulation.

Page 7of 39

Standard tools

Sleeve 8 mm inner diameter

~19 mm outer diameter

GWP 10

5. Lubricants and auxiliary substances required

C-SC_CSSM

Version 1.0

2016-02-02

FEIN retains all rights of disposal, such as copying and circulation.

Page 8of 39

Lubricants

Grease 0 40 101 0100 4 25 g Housing

GWP 10

6. Removal

C-SC_CSSM

Version 1.0

2016-02-02

FEIN retains all rights of disposal, such as copying and circulation.

Page 9of 39

Removing the handle half shell

1. Unscrew the countersunk screw (1).

2. Remove the switch pushbutton (2).

3. Unscrew the three screws (3).

4. Remove the handle half shell (4).

Tools:

- PH1 cross-tip

screwdriver

- PH2 cross-tip

screwdriver

GWP 10

6. Removal

C-SC_CSSM

Version 1.0

2016-02-02

FEIN retains all rights of disposal, such as copying and circulation.

Page 10 of 39

Removing the handle half shell

1. Unscrew the screw (1).

2. Remove the cable clamping piece (2).

3. Remove the cover (3).

4. Remove the handle half shell (4).

Tools:

- PH2 cross-tip

screwdriver
