Lampada Visita
Examination Lamp
02.737.00 / 02.738.00
Manuale Utente
User Manual
02.737.00 - 02.738.00_UM_IT_EN_Rev.04_08.10.2012 .:: 6 / 8 ::.
MOUNTING INSTRUCTIONS
1. Mount rays [1] in the base [2] tighten the screws
[3]
2. Insert the five casters [4]in the rays [1] until they
“snap” into place.
3. Insert column [5]of the lamp into center hole of
the base.
4. Insert the flat washer and bolt/screw [6] into the
center hole from the other side.
5. Tighten head bolt/screw
LAMP REPLACEMENT
1. Allow the lamp to cool before replacing.
2. Turn the unit off and unplug the power cord from both the wall outlet and the lamp
3. Slide the cover up to remove it.
4. Grasp the lamp connector and pull the lamp straight out of its holder.
5. Pull the lamp from its connector and replace it with the spare lamp
6. Push the lamp back into the holder.
7. Close the lamp
8. Return the unit to the patient area and plug power cord back into bottom of unit and wall outlet.
LOCATION AND INSTALLATION OF UNIT
Your equipment has been fully operated, tested, and balanced in our plant prior to shipment, unless notified otherwise.
Follow the installation requirements below.
Do not place the unit near combustible materials or hazardous gas.
Do not install unit in a corrosive environment. A corrosive environment may lead to poor performance
and deterioration of plastic components.
Ventilation: The unit should be installed in an area where there is good air ventilation. Allow a minimum of 20mm
between any wall and any side of the unit (or to any equipment mounted to it).
Do not position the unit in a manner that would make it difficult to operate your main power cord.
1. Read this entire Operation
2. Do not use this equipment in any manner not specified in this manual. Improper use may impair the safety features
employed and will void your warranty.
3. This equipment is not designed for use with volatile or explosive materials. Do not install test articles that may
release explosive or flammable gas in the examination lamp. Loading of such materials may result in explosion or
fire.
4. Only qualified service personnel should ever be permitted to perform any service-related procedure on this
equipment!
5. Do not place the unit near combustible materials or hazardous fumes or vapors.
6. Do not install unit in a corrosive environment
7. Do not position the examination lamp in a manner that would make it difficult to operate your main power cord.
8. Before making the power supply connection to your equipment, you must follow the specific directions stated
under “Power Connection” in the Installation Instructions section. Failing to perform the directions stated may
damage your equipment and void your warranty!
9. Do not adjust any mechanical or electrical components.
10. Human exposure to extremes temperature can cause injury. Do not touch hot surfaces. Take appropriate
precautions before opening the heat examination lamp and upon handling any oven contents.
11. Do not modify any component on this unit. Use only original equipment manufactured (OEM) parts as replacement
parts. Modifications to any component, or the use of a non-OEM replacement part could cause damage to your
equipment or personal injury.
