1500 LCD Projector

User Guide

FAVI ENTERTAINMENT

1500 User Guide

©Yakel Holdings LLC

Table of Contents

Introduction................................................................................1

Technical Specifications..................................................................1

Safety (must read before operating) ...............................................2

Quick Start Guide......................................................................4

Step 1 – Connecting Your Projector................................................4

DVD Player .............................................................4

TV ...........................................................................4

Laptop / PC.............................................................5

Step 2 – Turning on Your Projector.................................................5

Step 3 - Focusing............................................................................5

Lamp Replacement...................................................................6

PROJECTOR HD

Introduction

he FAVI 1500 LCD Projector is one of the most cutting edge projectors on

the market today. The 1500 has reverse imaging capabilities for front and rear

projecting, displays up to a 200 inch picture, and incorporates FAVI’s famous

IllumiBright™ Lamp technology.

Technical Specifications

Model P1500

Lamp life 6,000-8,000 hours

Lamp type 150W IllumiBright™

Image Size 40—200 inches

Net weight 9.4 pounds

Inputs Composite A/V, S-Video, VGA

Outputs Composite Audio

Projector Noise 34 db

Native Resolution 800 x 480

Compatible Resolution 1024 x 768, 800 x 600

Contrast Ratio 600:1

Speakers 1 x 5w

Chapter

PROJECTOR HD

Power Supply 110V-120V AC 50/60 Hz or 210V-240V

Accessories Spare IllumiBright™ Lamp, 2 Remote

Controls, VGA Cable, Composite AV

Cable, S-Video Cable, Lens Tissue, Power

Cable

Safety

Please read below before operating:

•Do not look directly into the lens or open the case while the projector is

running. This could cause severe injury to your eyes.

•Please keep the projector away from liquids. This could cause electric

shock and damage your projector.

•Do not attempt to change the lamp while the projector is running or soon

after it has been turned off. If you need to change the lamp please consult

the “Lamp Replacement” section at the end of this user guide.

•After you turn off the projector please wait 15 minutes before turning it

back on. Failing to wait 15 minutes will decrease the life of the lamp and

the projector.

•Please only use the unit or remote power button to turn off the projector.

Do not unplug the unit while it’s running or turn the unit off using the

main power switch. This will cause severe damage to the lamp and the

projector.

•Do not cover any of the projector vents.

•There are protective circuits and alarming devices located inside the

projector. When the internal temperature rises caused by an improper

environment or blocked vents, the projector will shut down automatically.

We strongly recommend you keep the projector in a cool room. This will

prolong the overall life of the projector.

•Please keep the projector where the temperature does not exceed 85 °F

(29.4 °C). The LCD inside the projector will develop black spots if left in

warm environments. This heat damage will not be covered under

warranty.

PROJECTOR HD

•Please leave the projector in a ventilated environment. Do not enclose

your projector when mounting. This could cause heat damage.

•Avoid using the projector in a high temperature, dusty, and or dirty

environment.

•Do not touch the projector lens with your hands. If the projector is left

unused for long periods of time please cover the lens with the cap

provided.

•When you are done using the projector and the fan has shut off, please

turn off the main power switch and remove the plug. This will avoid

damage from potential voltage waves.

•The projector is composed of many precise electronic and optical

components. Other than changing the lamp there are no parts that should

be serviced by the owner. If you attempt to open the projector yourself

any warranty will be null and void. FAVI provides a 6 month warranty on

all its projectors. Please contact your FAVI dealer for any warranty claim.

PROJECTOR HD

Quick Start Guide

Before turning on your projector please read the safety section. Failing to do so could

cause severe injury and damage to the projector.

Step 1 – Connecting

DVD Player

•Composite Audio/Video – Take your red, white, and yellow cable and

connect it to the corresponding output on your DVD player. Then

connect the free ends to the corresponding colored Inputs on your

projector.

•S-Video – Connect the S-Video cable to the output S-Video on your DVD

player then connect the free end of the cable to your projector S-Video

Input. Next connect a red and white composite audio cable to the output

of your DVD player and the free end to the red and white inputs on the

projector.

•Regular Cable Box

•Composite Audio/Video – Take your red, white, and yellow cable

and connect it to the corresponding colored outputs on your cable

box. Then connect the free ends to the corresponding colored

Inputs on your projector.

•S-Video – Connect your S-Video cable to the S-Video output on

the cable box and connect the free end of the S-Video cable to

your projector S-Video Input. Next connect a red and white

Chapter

PROJECTOR HD

composite audio cable to the output of the cable box and the free

end to the red and white inputs on your projector.

•Regular Satellite Box

•Composite Audio/Video – Connect your red, white, and yellow

composite cable to the corresponding outputs on your satellite

box. Then connect the free ends to the corresponding colored

inputs on your projector.

•S-Video – Connect your S-Video cable to the S-Video output on

the satellite box. Then connect the free end of the cable to your

projector S-Video input. Next connect a red and white composite

audio cable to the output of the satellite box and the free ends to

the corresponding composite audio inputs on your projector.

Laptop / PC

•Your VGA cable should first be connected to your PC/Laptop then to your

projector. Please ensure the cable is screwed tightly in place on both ends.

Now set your source button on the projector to PC or VGA. If at this time

you do not see your computer screen projecting you may need to consult your

computer manual for the correct setting. In most cases the correct key

combination to read a VGA signal is function, f4.

Step 2 - Turning on Your Projector

Please first place the projector in the proper viewing position. Next, plug in the

power cord and turn on the main power switch in the rear of the unit. You will

now see the side indicator light blink red. Now, press the top power button.

Please note once you have turned off the unit you should not attempt to turn the

unit back on for 15 minutes. The main power switch should not be turned off

during this cooling period.

Step 3 - Focusing

The image size can only be adjusted by moving the projector. Once you have the

correct image size please gently twist the lens to focus. If the image is distorted

please use the keystone correction wheel located on the bottom of the unit.

PROJECTOR HD

Lamp Replacement

Figure 1. Remove the screw from lamp compartment cover.

PROJECTOR HD

Figure 2. Remove the cover.
