Fantasia Elite Cirrus Guía de configuración
OWNERS INSTRUCTION
MANUAL
INSTALLATION
OPERATION
MAINTENANCE
102CM/40”
Cirrus
CAUTION
READ INSTRUCTIONS CAREFULLY FOR SAFE
INSTALLATION AND FAN OPERATION. IF UNSURE CONSULT
A QUALIFIED ELECTRICIAN
SUITABLE FOR 230V/50 CYCLE ELECTRICAL SUPPLY
Enquiries on installing your fan please call our help line on
01959-564440
E-mail :
IMPORTANT NOTES :
Please minimise risk of electrical shock by switching off electricity supply at the
main circuit breaker. And read the following point carefully.
To ensure the success of the installation be sure to read the instructions and study the diagrams
thoroughly before commencing.
All electrical work should only be undertaken after disconnection of the power by removing fuses
or turning off the circuit breaker to ensure all pole isolation of the electrical supply. If you are in any
doubt the services of a qualified electrician should be sought to ensure that all work is carried out
in accordance with the I.E.E. Regulations, current good practice and other national and local
electrical codes.
Make sure that your installation site will not allow the rotating fan blades to come into contact with
any object and that there is a minimum clearance of 150mm (6”) from the blade tip to the wall or
ceiling. Please note that the bigger this clearance is the better the airflow from your fan will be.
Ensure the blades are mounted at a minimum height of 2.3 meters (7’6”) from the floor when the
fan is installed.
The fixing point for the fan must be able to support a weight ten times that of the net weight of the
fan. Net weights can be found on the bottom of the unit’s box. If you are mounting the fan to a
ceiling junction box, the box and it’s fixing must be able to support the moving weight of the fan
and must not twist or work loose.
The fan must be earthed.
Do not connect the fan motor to a dimmer switch. This may give an unsatisfactory performance
(motor hum) and cause damage to the motor.
It is not recommended that ceiling fans and gas appliances are operated in the same room at the
same time.
The fan must be turned off and stopped completely before reversing the fan direction. This will
prevent any damage to the motor of the unit or controller (if installed).
Do not insert anything into the fan blades while the fan is operating. This will damage the blades
and upset the balance of the unit causing the unit to wobble.
After the fan is completely installed make sure that all connections are secure and tight to prevent
any problems.
Because of the fan’s natural movement, some connections may loosen. Check the support
connections, brackets and blade attachments twice a year to make sure they are all secure. If they
are loose tighten with a screwdriver. ( It is not necessary to take the fan down from the ceiling )
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Note : The important safeguards and instructions given in this manual are not meant to cover all
possible conditions and situations that may occur. It must be understood that common sense,
caution and care are factors, which cannot be built into any product. These factors must be supplied
by the persons caring for and using the unit.
For installation advice, or in the unlikely event of damaged or missing parts please ring:
HELP LINE : (01959) 564440
Canopy Decorative Plate
PART LIST
Mounting Screw
Hanger Bracket
Drop Rod
Canopy
Split Pin
Boss Cover
Canopy Screw
Cotter Pin
Fan Motor
Light Plate
Light Plate Screw
Push Connector
Glass shade
LED Light Fitter
blade support plate
Round Steel Washer
Spring Steel Washer
Joist of Beam
Blade
Light Fitter Screw
Handset
Receiver
Blade Set Screw
Blade Set Screw
Installing the fan
1. Hanger bracket installation
Picture A
Drop Rod Style
All electrical work should only be undertaken after disconnection of the power by removing fuses or
turning off the circuit breaker to ensure all pole isolation of the electrical supply.
Your fan can be installed in a drop rod style of fan (Picture A). In this situation the drop rod assembly
is used to lower the fan down from it’s mounting position slightly. Extension rods, ranging from 12”
to 72” (your fan is supplied with 6” Drop rod in the box), are available if you need to lower your fan
further. (This is normally the case in conservatories or rooms with very high ceilings.)
The following steps will guide you to a successful installation:
Hanging bracket installation
Down rod assembly style
The hanger bracket should be screwed on to a firm flat
surface. The fixing location must be able to withstand ten
times the static weight of the fan. If you have any doubts as
to the ability of your intended fixing location to be able to
withstand this loading. Please contact our service help-line
or another competent authority to advise you. In most
situation two wood screws screwed into a wooden joist is
more than adequate to support your ceiling fan. The hanger
bracket should be screwed onto the joist with the two wood
screws provided. The washers provided should go in the
following sequence:
Screw head > spring washer > round washer>Hanger bracket > Ceiling. Screw the hanger bracket to
the ceiling and make sure all connections are secure to prevent the fan from falling. Fixings must
screw into a joist and not just the plasterboard. Loosen the two canopy screws from the hanger
bracket.
1.
2.
Attaching the blades4.
Attaching the light plate and LED light fitter and glass5.
Remote Control function and setup6.
Remote Control and Wiring instructions3.
2. Drop rod assembly
Remove the cotter pin and cross pin from the drop rod
boss of the fan. If a longer drop rod (12” to 72” rod) is
going to be used transfer the ball joint and the earth
wire to the longer rod.
Put the drop rod through the flared end of the canopy
and pass the electrical supply leads from the top of the
motor through the drop rod and boss cover and
canopy decorative plate until they exit at the top of the
rod. Always ensure the rod passes through the
canopy and boss cover before the rod is connected to
the fan If an extension rod longer than 18” inches is to
be used, the cables will need to be extended in an
appropriate way.
FOR DROP ROD STYLE OF FAN:
Rotate the ball around until the groove in the side of
the ball aligns with the protrusion on the upper edge of
the recess. When aligned the fan should drop slightly
as it assumes it’s correct position.
This is to prevent rotation of the rod and fan when the
unit is working.
REFER TO THE WIRING INSTRUCTIONS NEXT.
Carefully lift the fan motor assembly up to the hanger
bracket and seat the hanger ball/downrod assembly in
the mounting bracket socket.
Loosen the drop rod set screws on the boss, which is
on top of the motor and insert the drop rod into the
drop rod boss on top of the motor casing. Turn gently
to align the holes in the boss with those in the rod.
Ease the split pin through the boss and the rod taking
care not to pinch or damage any cables. Fix in place by
replacing the cotter pin.
Tighten all set screws at this point. This prevents the
rod and the fan moving in relation to one and other. It
also assists in maintaining a good earth continuity
through the fan, which is important to the safety of the
unit.
Failure to tighten the locking screws down may cause
the motor to oscillate badly.
3. Remote Control and Wiring Instructions
Warning: The power should have already been
disconnected. Follow the steps below to connect the
fan to your household wiring.
Insert the receiver into the hanger bracket with the
flat side of the receiver facing the ceiling.
Put the receiver of remote control through hanger bracket (as picture).
Connect the A.C. power supply wire that come from the ceiling to the Brown and blue wire of receiver
which is mark with label “L” & “N”. In most cases, BROWN/RED wire is LIVE is connected to “L”
BROWN wire , BLUE/BLACK wire is NEUTRAL is connected to “N” BLUE wire. GREEN/YELLOW wire
is EARTH.
Connect the 4 lead wires coming from the fan housing with 4 wires coming from the other side of the
remote control receiver where indicated sticker with brown, blue, orange block.
BROWN TO BROWN (Live wire of fan)
BLUE TO BLUE (Neutral wire of fan)
ORANGE TO ORANGE (Live wire of light)
GRN/YEL TO GRN/YEL (Earth wire)
BROWN (RECEIVER AC IN L) BROWN (” L” FROM RECEIVER)
BROWN (” L” FROM HOUSEHOLD)
BROWN (” L” FROM FAN)
ORANGE (” L1” FROM FAN)
ORANGE (” L1” FROM RECEIVER)
BLUE (” N” FROM FAN)
BLUE (” N” FROM RECEIVER)
BLUE ( RECEIVER AC IN N)
GRN/YEL (FROM BRACKET)
GRN/YEL (FROM FAN)
GRN/YEL (FROM HOUSEHOLD)
BLUE (FROM HOUSEHOLD)
RECEIVER
Put all the wires carefully into canopy after finishing
all the wires connection. Make sure connection
are neatly tucked in the canopy.
Slide the canopy up to the mounting bracket and place
the key hole on the canopy over the loose canopy
mounting screw on the mounting bracket. Turn the
canopy clockwise until the canopy locks in place at the
narrow section of the key holes.
Align the circular hole on the canopy with the remaining
hole on the mounting bracket. Secure the canopy
mounting screw previously removed in the hole, and
tighten the two canopy mounting screw.
Attach the canopy bottom cover to the canopy by
inserting the canopy mounting screw into the key
slots in the canopy bottom cover and rotating the
canopy bottom cover clockwise.
4. Attaching the blades
Remove the decorative cover from the fan motor housing
by remove the two decorative cover screws on the motor
housing.
Remove three blade upper section attachment screws
from the fan motor through the motor window.
Secure fan upper section with the screw previously
removed through the motor window.
Align three holes on blade support plate with three
holes on blade lower section and on blade arm, and
secure with three blade lower section attachment
screws with lock washers provided.
Repeat this procedure for remaining blades.
Re-install the decorative cover back to the fan motor
housing by using the two decorative cover screws
previously removed.
5. Attaching the light plate and LED light fitter and glass
The fan motor assembly is shipped with motor support
plate to prevent movement during transportation.
Remove the motor support plate .
Remove one of the three light kit mounting plate screws
from the mounting ring and loosen the other two screws.
(Do not remove.)
Place the key holes in the light kit mounting plate over
the two screws previously loosened from the mounting
ring. Turn the light kit mounting plate until the light kit
mounting plate locks in place at the narrow section of
the key holes.
Securely tighten the two light kit mounting plate screws
previously loosened and the one previously removed.
Remove one of the three light kit mounting screws from
the light kit mounting plate and loosen the other two
screws. (Do not remove.)
While holding the 18W LED light kit under the fan motor
assembly, make the 2-pin wire connections:
- White to white
- Black to black
Place the key holes in the 18W LED light kit over the two
mounting screws previously loosened from the light kit
mounting plate. Turn the 18W LED light kit until the 18W
LED light kit locks in place at the narrow section of the
key holes. Secure by tightening the two light kit mount-
ing screws previously loosened and the one previously
removed.
Position the notches in the outer rim of the 18W LED
light kit so they line up with the tabs on the inside of the
rim on the light cover. Carefully lift the light cover up
inside the 18W LED light kit and secure it to the fan by
turning the light cover clockwise until snug. DO NOT
OVERTIGHTEN.
Tabla de contenidos
Otros manuales de Admirador de Fantasia
Fantasia
Fantasia Propeller Guía de configuración
Fantasia
Fantasia Tau Guía de configuración
Fantasia
Fantasia Elite Angel Manual del propietario
Fantasia
Fantasia Delta Guía de configuración
Fantasia
Fantasia Kompact Guía de configuración
Fantasia
Fantasia Medina Guía de configuración
Fantasia
Fantasia Elite Zeta Guía de configuración
Fantasia
Fantasia Sigma Manual de usuario
Fantasia
Fantasia Omega Guía de configuración
Fantasia
Fantasia GEMINI Manual de usuario
