The Celano™

FP5420PW

SPECIFICATION SHEET

Product Speciﬁcations Subject To Change

The Celano™Fan Assembly – FP5420PW

Dimensions shown in inches

10983 Bennett Parkway

Zionsville, IN 46077

Toll Free (888) 567-2055

FAX (866) 482-5215

Outside U.S. call (317) 733-4113

Visit Our Website www.fanimation.com

INSTALLATION REQUIREMENTS:

Ceiling fan attaches to electrical junction box securely anchored and capable of withstanding a load of at least 50 lbs.

ELECTRICAL REQUIREMENTS:

Ceiling fan requires a grounded electrical supply line of 120 volts AC, 60 Hz, 15 amp circuit.

MOTOR SPECS:

188 x 20 motor is designed for optimal performance with this fan.

FAN SPEEDS:

3 fan speeds with reversing switch (on top of the motor). High – 160 rpm; Med – 108 rpm; Low – 59 rpm

CONTROL OPTIONS:

The hand-held remote control (C24) with canopy receiver (RECFP5420) is included. Push button remote control will

consist of 3 separate fan speeds, inﬁnite light levels, and off position. Reversing switch located on fan housing. Optional

wall control (C25) is available (to be used in conjunction with fan receiver).

LIGHTING OPTIONS:

The 3-bulb (40 watt max candelabra bulbs - not included) downlight ﬁxture is included with this fan assembly. Maximum

downlight wattage not to exceed 120 watts.

DOWNROD OPTIONS:

The Celano™fan comes with a 1˝Dia. x 6˝(DR1-6) downrod. Optional downrods are available in 12”, 18”, 24”, 36”,

48”, 60”, and 72”. For installations requiring a longer downrod, a downrod coupler is available. Optional Decorative DR

Sleeve (DRS54PW) is available, requires a 18˝DR or longer. The Celano™fan can be mounted on a sloped ceiling up

to 30°. Most sloped ceiling installations require a downrod longer than the standard 6˝downrod. Optional sloped ceiling

ball kits (SCB1-52) are available for up to 52°. Call tech support for more information.

BLADE SETS:

A set of 5 walnut wood blades are included. Optional set of 5 cherry wood blades (B5400CY) is available and sold

separately. Not recommended for Damp Location.

DAMP LOCATION:

Fan not rated for Damp Location usage.

Optional DR Sleeve

DRS54PW

Optional Cherry

Blade Set

B5400CY

Fan Assembly - FP5420PW

Distance from Ceiling to Blade Edge

(with 6˝DR) 11.6˝

Blade Sweep / Pitch

54˝/ 14°

Canopy Diameter

6½˝

Net Hanging Weight:

(with Light Kit) 29 lbs

Distance from Ceiling to

Bottom of Fan

Fan w/6˝downrod 18˝

Fan w/12˝downrod 24˝

Fan w/18˝downrod 30˝

Fan w/24˝downrod 36˝

Fan w/36˝downrod 48˝

Fan w/48˝downrod 60˝

Fan w/60˝downrod 72˝

Fan w/72˝downrod 84˝

Available Finish

PW Pewter with Opal/Frosted

Glass
