Exmark LAZER Z AS Manual

LAZERZ®AS

SetupInstructions

ForSerialNos.790,000&Higher

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.Partnumbersnotshownareavailableonthedealer

extranet.

DealerPack

Part#DescriptionQty.Use

—WarrantyRegistrationReminder

103-2106Key,ExmarkLogo1

1-603511Key,Standard1

Fillouttheonlinewarrantyregistration

formandplacekeysintoliterature

pack.

LiteraturePack

Part#DescriptionQty.Use

—Manual,Operator’s1

—Manual,Parts1Readbeforeoperatingthemachine.

—DVD,ExmarkSafetyVideo1Viewbeforeoperatingthemachine.

RaisetheRolloverProtection

System(ROPS)

1.Pulltheknobandrotate90°totheunlatched

position(seeFigure1).

Figure1

1.Rollbarupperhoop4.Rotate90°tohold

unlatched

2.Knobin“latched”position5.Knobin“unlatched”

position

3.Pullknobtounlatch

2.Raiseandholdtheupperhoopoftherollbarinthe

uprightposition.

3.Tolocktherollbarintheraised,operateposition,

rotatetheknobs90°sothatthetabsinterlock

partially.Applyforwardpressuretotherollbarhoop

andobservethattheknobsreturntothecompletely

latchedpositionasshowninFigure1.

CheckingTirePressure

1.Checkthetirepressureinthedrivetires.Proper

inationfordrivetiresis13psi(90kPa).

2.Adjustifnecessary.

ServicingtheBattery

WARNING

CALIFORNIA

Proposition65Warning

Batteryposts,terminals,andrelated

accessoriescontainleadandleadcompounds,

chemicalsknowntotheStateofCalifornia

tocausecancerandreproductiveharm.

Washhandsafterhandling.

P .O.Box808

Beatrice,NE68310

PartNo.4500-443Rev.A

PrintedintheUSA

AllRightsReserved

Note:Themachineisshippedwithalledleadacid

battery.

DANGER

Chargingthebatterymayproduceexplosive

gasses.Batterygassescanexplodecausing

seriousinjury.

•Keepsparks,ames,orcigarettesawayfrom

battery.

•Ventilatewhenchargingorusingbatteryin

anenclosedspace.

•Makesureventingpathofbatteryisalways

openoncebatteryislledwithacid.

1.Checkthevoltageofthebatterywithadigital

voltmeter.Locatethevoltagereadingofthebattery

inthetablebelowandchargethebatteryforthe

recommendedtimeintervaltobringthechargeup

toafullchargeof12.6voltsorgreater.

Important:Makesurethenegativebattery

cablesaredisconnectedandthebatterycharger

usedforchargingthebatteryhasanoutputof

16voltsand7ampsorlesstoavoiddamaging

thebattery(seechartforrecommendedcharger

settings).

Voltage

Reading

Percent

Charge

Maximum

Charger

Settings

Charging

Interval

12.6or

greater

100%16volts/7

amps

NoCharging

Required

12.4–12.675–100%16volts/7

amps

30Minutes

12.2–12.450–75%16volts/7

amps

1Hour

12.0–12.225–50%14.4volts/4

amps

2Hours

11.7–12.00–25%14.4volts/4

amps

3Hours

11.7orless0%14.4volts/2

amps

6Hoursor

CAUTION

Iftheignitionisinthe“ON”positionthere

ispotentialforsparksandengagementof

components.Sparkscouldcauseanexplosion

ormovingpartscouldaccidentallyengage

causingpersonalinjury

Besureignitionswitchisinthe“OFF”position

beforechargingthebattery.

2.Connectthenegativebatterycables.

Note:Ifthepositivecableisalsodisconnected,

connectthepositive(red)cabletothepositive

batteryterminalrst,thenthenegative(black)cable

tothenegativebatteryterminal.Slipinsulatorboot

overthepositiveterminal.

Note:Iftimedoesnotpermitchargingthebattery,

orifchargingequipmentisnotavailable,connect

thenegativebatterycablesandrunthevehicle

continuouslyfor20to30minutestosufciently

chargethebattery.

PositioningtheDischargeChute

Loosenthetwo3/8inchnylocnutsattachingthe

dischargechute.Lowerthedischargechuteinto

position.Retightenthenylocnutsuntilthechuteissnug

butcanpivotfreely.

ServicingtheEngine

Checktheengineoillevel.

ReferEngineOwner’sManual.

ServicingtheEngineCoolant

Themachineisshippedlledwithenginecoolant.

WARNING

Dischargeofhotpressurizedcoolantor

touchinghotradiatorandsurroundingparts

cancausesevereburns.

•DoNotremovetheradiatorcapwhenthe

engineishot.Alwaysallowtheengineto

coolatleast15minutesoruntiltheradiator

capiscoolenoughtotouchwithoutburning

yourhandbeforeremovingtheradiatorcap.

•DoNottouchradiatorandsurrounding

partsthatarehot.

CAUTION

Enginecoolantistoxic.Swallowingengine

coolantcancausepoisoning.

•DoNotswallowenginecoolant.

•Keepoutofreachfromchildrenandpets.

Withcoolengine,checkthatcoolantlevelisuptothe

indicatorlineontheoverowbottle.Ifnot,add50/50

coolantmixtooverowbottletobringthelevelupto

theindicatorline.Alsocheckcoolantlevelinradiator.

Fillitashighaspossiblewith50/50coolantmix.

Note:UnitsshouldonlybelledwithDexCool©

extendedlifecoolant,whichcanbeidentiedbyits

orangecolor.

ServicingtheHydraulicOil

Themachineisshippedlledwithhydraulicoilinthe

reservoir.

1.Checkhydraulicreservoirandifnecessarylltothe

appropriatelevelwithExmarkPremiumHydroOil.

2.Adjusttheseattothemostforwardpositionto

accessthecapsontheLHandRHhydrodrives.

3.Removethecap,wipethedipstickclean,andre-insert

thecapbackintothehydro.Looselytightenthecap.

4.Removethecapagainandchecktheleveloftheoil

onthedipstick.SeeFigure2foroillevels.

Figure2

1.Full2.Add

Note:Theoillevelonthedipstickwillbeincorrect

iftheoilischeckedwhentheunitishot.

5.Ifthedipstickoillevelisatthe“add”markadd

ExmarkPremiumHydrooil.

6.Replacehydraulicreservoircapandtightenuntil

snug.DoNotovertighten.

FillingOuttheProduct

Registration

Fillouttheproductregistrationonlineandplacekeys

intoliteraturepack.
