Exit 12FTX30IN Manual de usuario
MSP-30103-V02
User manual
Gebrauchsanweisung
Gebruikshandleiding
Mode d’emploi
FRAME POOL
3m X 76cM
10FTX30IN
12FTX30IN
3.6m x 76cM
Important safety rules: Before installing and using this product read, understand,
follow all instructions carefully and keep it for future reference!
Wichtige sicherheitsregeln: Bevor Sie dieses Produkt installieren und verwenden
lesen, verstehen und beachten Sie sorgfältig alle anweisungen, und für künftige
bezugnahme aufbewahren!
Belangrijke veiligheidsvoorschriften: Voor installatie en gebruik, zorg dat u alle
instructies aandachtig leest, begrijpt, naleeft en bewaar dit document voor latere inzage.
Règles importantes de sécurité: Lisez, comprenez et suivez attentivement toutes
les instructions avant d’installer et dútiliser ce produit! Conserver pour consultation
ultérieure!
2.44 X 76cM
8FTX30IN
3MSP-30103-V02
MSP-30103-V02 4
English
4
Deutsch
6
Nederlands
17
28
39
Français
NOTE: Drawing for illustration purpose only. Actual product may
vary. Not to scale. Before assembling your pool, layout and review
the contents to become familiar with all the parts you will be using
during the assembly:
HINWEIS: Die Zeichnungen dienen nur der Illustration. Das
tatsächliche Produkt könnte etwas anders aussehen. Nicht
maßstabsgetreu.Bevor Sie Ihren Pool zusammenbauen, breiten Sie
den angelieferten Inhalt aus und überprüfen Sie ihn, um sich mit
allen Teilen, die Sie während der Montage benötigen, vertraut zu
machen:
OPMERKING: de tekening is uitsluitend bedoeld voor
illustratiedoeleinden. Het werkelijke product kan verschillen. Niet
volgens schaal. Voordat u het zwembad monteert, moet u de
inhoud openleggen en controleren zodat u de onderdelen die u bij
de montage zult gebruiken, leert kennen:
REMARQUE : Dessin à but d’illustration uniquement. Le produit
réel peut varier. N’est pas à l’échelle. Avant de monter votre
piscine, disposez et passez en revue le contenu pour vous
familiariser avec toutes les pièces que vous utiliserez pendant le
montage.
5MSP-30103-V02
1.0 Part reference
3
1
5
4
9
6
12
8
11
10
7
2
6
MSP-30103-V02
2.0 Introduction
Congratulations on choosing a EXIT Frame Pool!
Have fun, be active and play outdoors......
That’s what keeps driving us to develop innovative, quality toys for cool kids and
parents.
We do everything possible to develop safe products for children. As our products are
classed as toys, we comply with the toughest consumer safety regulations. Before
launching our products onto the market, we have independent tests carried out for
certication. We also continuously test our production runs and periodically have
independent tests performed again as a further check. Only products which live up to
the highest EXIT Toys standard are marked with and recognized by the EXIT-brand.
“We want to thank you for your custom and your condence in this product. We’re
sure your kids will have as much fun as we did during development. Being open-
minded, we really appreciate all comments and ideas which will help us improve
our products or develop new ones. You are invited to send your ideas to us at info@
exittoys.com”
Please visit www.exittoys.com and discover more cool new products.
The EXIT Toys team
7MSP-30103-V02
3.0 Guidelines for safe use
Using your Frame Pool as instructed in this manual will eliminate virtually all hazards.
However, please bear in mind that children have a natural urge to play and that this
may lead to unforeseen dangerous situations for which the manufacturer cannot be
held responsible. Teach your children how to use the product and point out possible
dangers to them.
Before assembling and using the product, please read and observe these
main warnings:
WARNING: To enhance the enjoyment of your pool
and protect the safety of those in and around the pool,
ALWAYS STRICTLY OBSERVE the following safety and
maintenance instructions:
1). It is the responsibility of the pool owner to identify and obey all local and state
laws pertaining to above ground swimming pool safety PRIOR to set-up or use of the
pool. These include, but are not limited to, laws on: decks, fences, barriers, covers,
pool ladders, lighting, and required safety equipment. Please consult your local
authorities to ensure compliance.
2). Do not allow unattended Children in the pool. Always make sure that at least one
responsible adult is supervising all Children and those who do not know how to swim
AT ALL TIMES. Never swim / bathe in the pool alone.
3). NEVER permit diving or jumping into the pool. Never enter the pool from any
decks or other raised surfaces. The water level in your pool is extremely shallow and
is not suitable for these activities. Failure to heed these in-structions can result in
serious injury or even death.
4). Do not permit Children or adults to engage in any “rough-housing” or other
aggressive sports or activity in or around the pool. Failure to observe this guideline
can result in serious injury for those in and around the pool area.
5). Always maintain the proper pool safety equipment in an easily accessible area
adjacent to your pool. Clearly post emergency phone numbers as well as safety
advisories and rules (such as “No Jumping or Diving” and “Do Not Swim Alone").Do
not allow bathers in the pool unless the area is sufciently bright or lighted.
6)All ltrations are in agreement with the installation standard NF C 15-100 that all
electric appliances located within 3.50 m for the pond and with a free access should
have a low voltage supply of 12V. All electrical appliance supplied with 220V must be
located at least at 3.50 meter from the edge of the pond. Consult the manufacturer
for any change of one or several elements to the ltration system.(For France Market)
8
MSP-30103-V02
7). The safety of your children is up to you! The risk is greatest when children are
younger than 5 years old. The accidents do not only happen to others! Be ready to
face it!
8). Watch and act:
- Supervision of children must be close and constant;
- Designate one responsible for security;
- Strengthen monitoring when there are multiple users in the pool;
- Teach your children to swim as soon as possible;
- Wet neck, arms and legs before entering the water;
- Learn lifesaving,especially those specic to children;
- Forbid diving or jumping in front of young children;
- Forbid running and violent games around the pool;
- Do not allow access to the pool without a safety vest for a child not knowing
how to swim and not accompanied in the water;
- Do not leave toys near unmonitored pool;
- Keep water clear and healthy;
- Store water treatment products out of reach of children;
9). Plan:
- Phone near the pool, do not leave your children unattended when you call;
- Buy and pole near the pool;
10). Moreover, some devices may contribute to security:
- Barrier whose portal will be constantly kept closed (e g a hedge cannot be regarded
as a protective barrier);
- Manual or automatic cover properly positioned and secured protection;
- Electronic sensor to detect or drop in service and operational, but not a substitute
for close supervision;
11). Accident:
- Remove the child from the water as quickly as possible;
- Call for help immediately and follow the advice that given to you;
- Replace wet clothes with warm blankets;
12)Store and view pool number of rst aid:
- Fire: (18 for France); (112 Europe)
- EMS: (15 for France); (112 Europe)
- Poison Center; (112 Europe)
13). Prohibit access to the pool for the deterioration or the system(s) lter;
14). Do not submerge;
15). Do not walk on the edge;
16). Warning: Never put the empty swimming pool in the open air.
9MSP-30103-V02
4.0 Site selection
WARNING: Pools installed on inadequately level surfaces are subject to leaking,
forming irregularities, or collapse, which can result in property damage or serious in-
jury for those in or around the pool area!
WARNING: Do not use sand during setup process. If it appears that there is a need
for use of a “leveling agent”, then your set-up site is likely unsuitable. FAILURE TO
OBEY THIS WARNING MAY RESULT IN SERIOUS PERSONAL INJURY.
CAUTION: Please choose your set-up area carefully, as lawn and other desirable
vegetation underneath the ground cloth (If applicable) will die. Furthermore, try to
avoid setting the ground cloth (If applicable)in areas prone to aggressive plant and
weed species, as they may grow through the ground cloth (If applicable).
CAUTION: The pool must be accessible to a 110 or 230-volt AC outlet protected
by a Ground Fault Circuit Interrupter (GFCI). The pool should be set no closer than
10 ft. to the power source, but no further than the length of the lter pump cord.
Under no circumstances should an extension cord be used to extend the range of the
connection.
It is absolutely essential to select a suitable site for your pool
BEFORE attempting to ll it with any water. Please select a set-up
site which strictly conorms to the following guidelines:
Guide 1. Ensure that the area is rm,at(no bumps or mounds of earth) and
extremely level, with a grade not exceeding 3° of slope at any point in the set-up
area.
Guide 2. Make sure that the area you have selected to set-up the pool is completely
free of sticks, stones, sharp objects or other foreign debris.
Guide 3. Select an area that is not directly underneath overhead power lines or
trees. Additionally, make sure that the pool set-up area does not contain underground
utility pipes, lines, or cables or any kind.
Stay away from drains
& suction fittings
Your hair,body & jewelry can get sucked into drain.
You could be held under water & drown!
10
MSP-30103-V02
Guide 4. A ground cloth will help protect the pool liner from damage due to weed
growth, sharp objects, and debris.
Guide 5. If at all possible, choose an open location on your property that is exposed
to direct sunlight. This will help to warm your pool.
5.0 Set up the pool
IMPORTANT:Do not start assembly if any pieces are missing. For replacement
pieces call the Consumer Service telephone number in your area.
The number of persons required for installation: 2 adult at least.
Total installation time except the time for site preparation and water lling:
30 up to 45 minutes.
Step 1. Account for all parts.
Remove all the parts from the carton(s) and place them on the ground in the location
where they are to be assembled
Check each part according to “PART REFERENCE” 1.0. Make sure all the pieces to be
assembled are accounted for.
Step 2. Install drain valves cover and stopper.
Make sure that outer drain plug is inserted into the outer drain cap and drain valve
cover is screwed on tightly.Plug the connection holes with the stoppers. (The out
drain plug changes according to different size of pool.)
STOPPER Out Drain Plug A Out Drain Plug BDrain Vavle Cover
+3°
Bumpy,Sloping Ground-INCORRECT
Flat,Level Ground-CORRECT
11MSP-30103-V02
Step 3. Install the horizontal beams
Step 4. Install T-joints and frame
4.1. Use the connection
end of the T-Joint to
connect the adjacent
horizontal tubes.
4.2. Insert the Pin into the
hole of connected tubes
4.3. Install the vertical leg
cap onto the vertical leg.
4.4. Insert the vertical leg
into the T-Joint through the
belt.
Step5. Fill the pool
WARNING: Do not leave pool unattended while lling with water.
WARNING: If more than 1~2 inches of water collects on any one side before you
start lling in the center.The pool is not level enough, and must be corrected! You
shall pull out the drain plug, release the water completely, disassemble the pool
completely,locate the pool on a plane surface, repeat set up instructiion.
WARNING: DO NOT OVERFILL as this could cause the pool to collapse.In times of
heavy rainfall you may need to empty some of the water to ensure the level is
correct.
A
A-A.
A
Slide combined beams into sleeve,the hole on the beams should face outwards.
4
3
4
1
2
!
