EXFO FIP-400B Manual de usuario
User Guide
Fiber Inspection Probe and ConnectorMax2
FIP-400B
ii FIP-400B
Copyright © 2013–2014 EXFO Inc. All rights reserved. No part of this
publication may be reproduced, stored in a retrieval system or transmitted
in any form, be it electronically, mechanically, or by any other means such
as photocopying, recording or otherwise, without the prior written
permission of EXFO Inc. (EXFO).
Information provided by EXFO is believed to be accurate and reliable.
However, no responsibility is assumed by EXFO for its use nor for any
infringements of patents or other rights of third parties that may result from
its use. No license is granted by implication or otherwise under any patent
rights of EXFO.
EXFO’s Commerce And Government Entities (CAGE) code under the North
Atlantic Treaty Organization (NATO) is 0L8C3.
The information contained in this publication is subject to change without
notice.
Trademarks
EXFO’s trademarks have been identified as such. However, the presence
or absence of such identification does not affect the legal status of any
trademark.
Units of Measurement
Units of measurement in this publication conform to SI standards and
practices.
Patents
The design patent is pending for this product.
Version number: 5.0.2
Fiber Inspection Probe iii
Contents
Certification Information ........................................................................................................v
1 Introducing the FIP-400B Fiber Inspection Probe and ConnectorMax2 .... 1
Probe ......................................................................................................................................1
Available Models ....................................................................................................................2
Probe Tips ...............................................................................................................................3
LED Indicator ..........................................................................................................................4
ConnectorMax2 Software .......................................................................................................5
Conventions ............................................................................................................................6
2 Safety Information ....................................................................................... 7
3 Setting up Your Fiber Inspection Probe and ConnectorMax2 ................... 9
Changing the Fiber Inspection Probe Tip ................................................................................9
Adjusting Brightness .............................................................................................................10
Setting up Autonaming ........................................................................................................12
Managing and Selecting Test Configurations ........................................................................20
Editing the Power Meter Test Configurations ........................................................................40
Reverting to Factory Settings ................................................................................................42
Changing Fiber Information of Existing Captures .................................................................43
4 Inspecting Fiber Ends ................................................................................. 45
Inspecting Fiber Ends (Single Fiber and Transceiver - Fiber Receptacles) ...............................45
Setting Up Multifiber Inspection ...........................................................................................49
Displaying Multifiber Connector Overlay ..............................................................................50
Inspecting Fiber Ends (Multifiber) .........................................................................................51
Retesting a Fiber (Multifiber) ................................................................................................58
Saving Files ...........................................................................................................................60
Opening and Closing Files ....................................................................................................63
Analyzing Captures ...............................................................................................................64
Displaying or Hiding the Power Meter and VFL Controls .......................................................69
Clearing Power Meter Measurements Automatically .............................................................70
Measuring Power or Insertion Loss .......................................................................................71
Viewing Power Meter Results ...............................................................................................72
Identifying Fiber Faults Visually with the VFL ........................................................................73
Creating Reports ...................................................................................................................74
Updating the Firmware and Software ...................................................................................77
iv FIP-400B
5 Maintenance ................................................................................................81
General Maintenance ............................................................................................................81
Recycling and Disposal (Applies to European Union Only) ....................................................81
6 Troubleshooting ..........................................................................................83
Solving Common Problems ...................................................................................................83
Contacting the Technical Support Group ..............................................................................86
Viewing Information about ConnectorMax2 ........................................................................87
Viewing Online Help .............................................................................................................87
Transportation ......................................................................................................................87
7 Warranty ......................................................................................................89
General Information .............................................................................................................89
Liability .................................................................................................................................90
Exclusions .............................................................................................................................90
Certification ..........................................................................................................................90
Service and Repairs ...............................................................................................................91
EXFO Service Centers Worldwide ..........................................................................................92
A Technical Specifications ..............................................................................93
B Fiber Inspection Probe Tip Compatibility Chart .......................................95
Index .................................................................................................................99
Certification Information
Fiber Inspection Probe v
Certification Information
North America Regulatory Statement
This unit was certified by an agency approved in both Canada and the
United States of America. It has been evaluated according to applicable
North American approved standards for product safety for use in Canada
and the United States.
Electronic test and measurement equipment is exempt from FCC part 15,
subpart B compliance in the United States of America and from ICES-003
compliance in Canada. However, EXFO Inc. makes reasonable efforts to
ensure compliance to the applicable standards.
The limits set by these standards are designed to provide reasonable
protection against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance
with the user guide, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
Modifications not expressly approved by the manufacturer could void the
user's authority to operate the equipment.
European Community Declaration of Conformity
An electronic version of the declaration of conformity for your product is
available on our website at www.exfo.com. Refer to the product’s page on
the Web site for details.
Fiber Inspection Probe 1
1 Introducing the FIP-400B Fiber
Inspection Probe and
ConnectorMax2
The FIP-400B Fiber Inspection Probe is a portable video microscope used
to inspect fiber ends. Unlike traditional microscopes, the FIP-400B
facilitates the examination of patchcord connectors and also hard-to-reach
connectors on the back of patch panels and bulkhead adapters.
Probe
The FIP-400B is designed to be an intuitive, easy-to-use piece of
equipment. This video microscope is used for inspecting fiber ends.
The focus knob can be turned in either direction to focus the image.
The magnification control button allows you to shift between three
levels of magnification. When pressed for one second, it activates the
auto focus.
The capture control button allows you to capture an image, perform an
analysis, or return to the Live video mode.
Status LED
Retaining nut
Focus
Magnification control
Capture control
Interchangeable
adapter tips
Introducing the FIP-400B Fiber Inspection Probe and ConnectorMax2
2FIP-400B
Available Models
The retaining nut holds tips securely in place, ensuring they are always
fastened in the correct position.
The status LED gives you information about the probe or the analysis
results.
The interchangeable adapter tips give you the possibility to use various
tips depending on the type of connector you are inspecting.
The probe comes equipped with a protective cap that fits over basic tips;
therefore, you do not need to remove the tip before putting the cap on.
Available Models
The features available for your probe are automatically detected when you
connect it to your unit. The table below shows which feature is available
for each model.
Note: The auto capture is not available in multifiber mode.
Note: When the internal temperature of the FIP-430B is too low, the probe
performs a warm-up that can last up to a minute.
Models Inspection Auto analysis Auto centering Auto focus Auto capture
FIP-410B X - - - -
FIP-420B X X X - -
FIP-430B X X X X X
Introducing the FIP-400B Fiber Inspection Probe and ConnectorMax2
Fiber Inspection Probe 3
Probe Tips
Probe Tips
The FIP-400B comes with two interchangeable tips included in two
different packages (UPC or APC). Additional models are also available.
UPC package:
FIPT-400-FC-SC: FC-SC Bulkhead tip
FIPT-400-U25M: Universal patchcord tip (2.5 mm ferrule)
APC package:
FIPT-400-SC-APC: SC APC tip for bulkhead adapter
FIPT-400-U25MA: Universal patchcord tip for 2.5 mm ferrules
Other tip models are available for various bulkhead adapters and
patchcord connectors. For more information about tips and their use, see
the Fiber Inspection Probe Tip Compatibility Chart on page 95, or visit the
EXFO Web site.
Introducing the FIP-400B Fiber Inspection Probe and ConnectorMax2
4FIP-400B
LED Indicator
LED Indicator
The LED located on the probe gives you information about the probe or the
analysis results.
LED Status
Flashing blue Detection of the probe in progress
Analysis in progress
Waiting mode. The auto focus
process starts automatically when
you insert an optical fiber
connector (FIP-430B only)
Auto focus in progress (FIP-430B
only)
Probe is initializing
Flashing red There is a major problem preventing
the probe from functioning properly
Blue Probe detected and ready
On a computer, the USB port is in
suspend mode
Red In Capture mode, current FIP result
status is Fail (FIP-420B and FIP-430B)
Green In Capture mode, current FIP result
status is Pass (FIP-420B and FIP-430B)
