SERVICE ------------------------------------------------------------------------ 2
IMPORTANT LABELS -------------------------------------------------------- 3
PRODUCT SAFETY ---------------------------------------------------------- 4
PART DRAWING -------------------------------------------------------------- 5
PART LIST ---------------------------------------------------------------------- 6
HARDWARE PACKING LIST & TOOLS --------------------------------- 8
ASSEMBLY --------------------------------------------------------------------- 9
COMPUTER ---------------------------------------------------------------------16
STORAGE ----------------------------------------------------------------------- 17
ADJUSTMENTS --------------------------------------------------------------- 18
LUBRICATION ----------------------------------------------------------------- 19
TROUBLE SHOOTING & MAINTENANCE ---------------------------- 20
WARM UP ---------------------------------------------------------------------- 21
WARRANTY -------------------------------------------------------------------- 22
FAX FORM ---------------------------------------------------------------------- 23
Item
#1005
OWNER’S
MANUAL
TABLE OF
CONTENTS
1
IMPORTANT: FOR NORTH AMERICA ONLY
To request product service and order
replacement parts, please call our
customer service department at:
1-866-924-1688
Monday through Friday, 8:00 AM-5:00 PM Pacific Standard Time,
Please visit our website at www.paradigmhw.com.
Please have the following information ready when requesting for service:
Your name
Phone number
Model number
Serial number
Part number
Proof of Purchase
*Before returning this product to the store please contact
customer service at the contact number.
Paradigm Health & Wellness, Inc.
1189 Jellick Ave, City of Industry, CA 91748, USA
SE VICE
2
IMPO TANT
LABELS
Basic precautions should always be followed, including the following
safety instructions when using this manual treadmill: Read all
instructions before using this manual treadmill.
1. Check every part of the equipment before exercise. If there is any
defective component, replace it immediately; keep the equipment out of
use until repair.
2. Make sure all parts, bolts and nuts are well assembled and locked before
exercise.
3. Never insert any object into any opening.
4. Never operate this manual treadmill if it is not working properly. If it has
been dropped or damaged, or been exposed to water, return the
appliance
to a service center for examination and repair.
5. Do not attempt any maintenance or adjustments other than those
described in this manual. Should any problems arise, discontinue use and
3
P ODUCT SAFETY
consult an Authorized Service Representative.
6. Wear comfortable and suitable clothing when using the treadmill. Do not
use the treadmill barefoot, in only socks or in sandals, always wear
athletic shoes. Never wear loose clothing because it could run the risk of
getting caught in the treadmill.
7. Keep children and pets away from the equipment while in use.
8. Do not use the treadmill outdoors. This manual treadmill is for household
use only.
9. Only one person should be on the treadmill while in use.
10. Keep the manual treadmill on a solid, level surface with the minimum
safety area clearance of 78.7” x 118” of the manual treadmill. Be sure the
area around the treadmill remains clear during use and has adequate
clearance.
11. Hold the handlebar with your hands when starting or stopping exercise
and increasing or decreasing the speed.
12.If feeling chest pains, nausea, dizziness, or short of breath, you should
stop exercising immediately and consult your physician before continuing.
13. The maximum weight capacity for this product is 260 lbs.
WARNING:Before beginning any exercise program consult your
physician. This is especially important for the persons who are over 35
years old or who have pre-existing health problems. Read all instructions
before using any fitness equipment.
CAUTION:Read all instructions carefully before operating this
product. Retain this Owner’s Manual for future reference.
4
PA T D AWING
5
PA T LIST
No. Description Qty No. Description Qty
001 Rear Roller Ø60x395 1 026 Safety Tube B (□25x460) 1
002 Running Deck 1020x407x12 1 027 Spring Knob Ø8 1
003 Front Roller Ø60x395 1 028 Transport Wheel Ø50 2
004 Running Belt 2400x335x1.2 1 029 Square End Cap (□38) 2
005 Main Frame 1 030 Rubber Pad 4
006 Protective Cover 1 031 Extension Sensor Wire III
(180mm) 1
007 Base Frame 1 032 Sensor with Wire 1
008 Left Handlebar 1 033 Extension Sensor Wire I
(1250mm) 1
009 Right Handlebar 1 034 Extension Sensor Wire II
(250mm) 1
010 Left Handlebar Support Tube 1 035 Extension Hand Pulse Sensor Wire
(250mm) 2
011 Right Handlebar Support Tube 1 036 Wire Plug (Ø6xØ21x10) 1
012 Hand Pulse Sensor with Wire 2 037R Right Side Rail (950mm) 1
013 Handlebar Adorner 2 037L Left Side Rail (1020mm) 1
014 Computer Bracket Ø28 1 038 Magnet with Magnet Bracket 1
015 Computer (HR-1566SP) 1 039 Screw ST3x6 2
016 Rear Roller Adjustment Bolt
Plate 2 040 Rear Roller Adjustment Bolt
M6x50mm 2
017R Right Incline Adjuster 1 041 Hexagon Head Bolt M6x25 6
017L Left Incline Adjuster 1 042 Screw ST4x16 8
018 Incline Adjuster End Cap Ø50 2 043 Bolt M8x40mm 5
019 Incline Adjuster End Cap Ø38 2 044 Bolt M8x35mm 1
020 Locking Pin Ø8x60 2 045 Bolt M8x45mm 4
021 Main Frame End Cap T65x25 3 046 Bolt M8x55mm 4
022 Square End Cap (□25.4) 3 047 Bolt M8x16mm 4
023 Square End Cap (□20) 2 048 Washer Ø12.5xØ22 3
024 Safety Tube A (□20x500) 1 049 Sleeve Ø16xØ12.5x9mm 1
025 Safety Tube B Bushing
(F23xF20.3x42) 1 050 Bolt M10x55mm 2
No. Description Qty No. Description Qty
051 Handlebar Support Tube End
Cap Ø28
2 058 Screw ST3x12 2
052 Bolt M5x10mm 2 059 Washer M8 6
053 C Clip Ø12 3 060 Washer M10 2
054 Nylon Washer Ø8.2xØ16x2T 2 061 Computer Bracket Foam Grip
Ø23x3Tx390
2
055 Washer M6 8 062 Handlebar Foam Grip Ø23x3Tx580 2
056 Spring Washer M6 6 063 Screw ST4x12 2
057 Nylon Nut M8 10
6
PA T LIST
7
HA DWA E PACKING LIST &
TOOLS
Allen Wrench 6M
1 PC
Allen Wrench with Phillips Screwdriver 5M
1 PC
Wrench
1 PC
(63) Screw ST4x12
2 PCS
(46) Bolt M8x55mm
4 PCS (47) Bolt M8x16mm
2 PCS
(50) Bolt M10x55mm
2 PCS
(57) Nylon Nut M8
4 PCS
(59) Washer M8
4 PCS
(60) Washer M10
2 PCS
(45) Bolt M8x45mm
4 PCS
