eWON Installation Guide
IG 019 / Rev 1.1
This installation guide explains how to install the eWON Flexy G
GSM Extension Card FLB 202.
Contents
This installation guide explains how to install the eWON Flexy
G GSM Extension Card FLB 202.
Subject to change without notice.
Check http://wiki.ewon.biz for the last document release.
eWON Flexy
G GSM Extension Card
FLB 202
Installation Guide
Table of Contents
1. Product Summary.............................................................................................................................3
2. Safety, Environmental & Regulatory Information...........................................................................4
2.1 Scope.......................................................................................................................................... 4
2.2 ESD Damage Prevention............................................................................................................4
2.3 Applicable Directives, Stan ar s an Compliance......................................................................4
2.3.1 Applicable European Directives.......................................................................................4
2.3.2 Applicable Safety Stan ar s............................................................................................4
2.3.3 FCC Compliance..............................................................................................................5
2.3.4 Certifications.................................................................................................................... 5
3. ardware Description.......................................................................................................................6
3.1 Mechanical Layout an Interfaces...............................................................................................6
3.2 Extension Car Label..................................................................................................................7
3.2.1 Label Location an Information Inclu e ..........................................................................7
3.2.2 Part Number Structure for Extension Car s ....................................................................8
3.3 Front Panel LEDs........................................................................................................................8
3.4 Specifications of the 3G GSM Extension Car ............................................................................9
3.5 eWON Flexy Extension Car s Environmental Con itions...........................................................9
3.6 Plugging the Extension Car into the Base Unit........................................................................10
3.6.1 Base Unit Slot Compatibility...........................................................................................10
3.6.2 SIM-Car Insertion.........................................................................................................11
3.6.3 Extension Car Insertion................................................................................................12
3.6.4 Multiple 3G GSM Extension Car s.................................................................................13
3.6.5 Power Requirements......................................................................................................13
4. Powering On the Base Unit with its Extension Cards..................................................................14
5. Check Card Detection on the Embedded Web Page....................................................................15
5.1 Connecting to the Embe e Web Server................................................................................15
5.2 Detecte Car s Displaye in the System Page.........................................................................15
5.3 Mo em Information Displaye in the Info Page.........................................................................16
Revision history.....................................................................................................................................17
i
eWON Flexy - 3G GSM Extension Car - FLB 3202 (Installation Gui e) Page 2/17
Pro uct Summary Chapter 1.
1. Product Summary
The present Installation Gui e escribes the har ware of the 3G GSM Extension Card FLB
3202 of the eWON Flexy family.
The eWON Flexy family is a range of mo ular in ustrial gateway/router.
As the name eWON Flexy suggests, it has been esigne to enable numerous ifferent
combinations of Extension Cards and Base Units. The present Installation Gui e is focusing on
an extension car which, as such, nee s to be inserte in one of the Base Units in or er to work.
The Base Units have their in ivi ual Installation Gui e IG-014-0-EN “eWON Flexy - Base Units”.
The present gui e a resses shortly how the Extension Car s integrate the Base Units an we
give some recommen ations to mount them (see § 3.6 Plugging the Extension Car into the Base
Unit).
eWON Flexy - 3G GSM Extension Car - FLB 3202 (Installation Gui e) Page 3/17
Pro uct Summary Chapter 1.
2. Safety, Environmental & Regulatory Information
2.1 Scope
The present hea ing a resses Safety, Environmental & Regulatory Information for the 3G GSM
Extension Car FLB 3202. This Extension Car is basically belonging to the same compliance
frame than the Base Units. In the present case of a telecommunication Extension Car , a itional
irectives, stan ar s an instructions apply.
2.2 ESD Damage Prevention
Caution!
Contains parts an assemblies susceptible to amage by electrostatic ischarge (ESD). Always
use ESD precautions when han ling Extension Car s an the opene Base Unit.
The Extension Car escribe in the present Installation Gui e is a mo ule exposing both si es
of an electronic printe circuit boar . Therefore, it is packe in antistatic ESD bags. In or er to
avoi ESD amage, the pro uct must be han le with the necessary precaution inclu ing:
●Groun e ESD protective work surface
●Personnel groun ing
2.3 Applicable Directives, Standards and Compliance
The Extension Car escribe in the present Installation Gui e complies with the R&TTE
irective 1999/5/EC an the FCC regulations relate to the wireless mo ems.
The Extension Car escribe in the present Installation Gui e belongs to class A Information
Technology Equipment (ITE). In a omestic environment this pro uct may cause ra io
interference in which case the user may be require to take appropriate measures.
2.3.1 Applicable European Directives
The Extension Car escribe in the present Installation Gui e is in conformity with the following
EC irectives:
●RoHS Directive 2011/65/EU
●EMC Directive 2004/108/EC
●R&TTE Directive 1999/5/EC*
The pro uct conforms to the correspon ing R&TTE articles:
RF spectrum efficiency (Art 3.2); EMC (Art. 3.1b); Safety (Art. 3.11)
2.3.2 Applicable Safety Stan ar s
The Extension Car escribe in the present Installation Gui e is in conformity with the following
safety stan ar s:
●IEC/EN 60950-1
●UL 60950-1
●CSA-C22.2 No 60950-1-07
eWON Flexy - 3G GSM Extension Car - FLB 3202 (Installation Gui e) Page 4/17
Safety, Environmental & Regulatory Information Chapter 2.
2.3.3 FCC Compliance
The Extension Car escribe in the present Installation Gui e complies with Part 15, 22A, 24E
an 27 of the FCC Rules. Operating is subject to the following two con itions:
●This evice may not cause harmful interference, an
●This evice must accept any interference receive , inclu ing interference that may cause
un esire operation.
2.3.4 Certifications
The Extension Car escribe in the present Installation Gui e has been certifie by authorize
bo ies:
●Certificate Of Compliance (COC) # E350576
●CB certificate # DK-29479-M1-UL
These certificates can be ownloa e as PDF files on the eWON Support web site:
http://wiki.ewon.biz/Support/07_Documentations/Official_ ocuments
eWON Flexy - 3G GSM Extension Car - FLB 3202 (Installation Gui e) Page 5/17
Har ware Description Chapter 3.
3. ardware Description
3.1 Mechanical Layout and Interfaces
SMA-F Female antenna connector
SIM-Car rawer
Backplane connector
eWON Flexy - 3G GSM Extension Car - FLB 3202 (Installation Gui e) Page 6/17
Har ware Description Chapter 3.
3.2 Extension Card Label
3.2.1 Label Location an Information Inclu e
The i entification label of the extension car s is place on the sol er si e of the PCB.
The ifferent parts of the label are escribe below:
PN
Part Number:
i entifies the type of the car .
Description see 3.2.2 Part
Number Structure for Extension
Car s
SN
Serial Number
Structure of the Serial Number
1111-2233-0001-44
1111 = MTID (pro uct relate )
2233 = Year Week
0001 = sequential mfg or er
44 = pro uct type
Marks CE, UL,... certificate number an
logos if applicable.
eWON Flexy - 3G GSM Extension Car - FLB 3202 (Installation Gui e) Page 7/17
Har ware Description Chapter 3.
3.2.2 Part Number Structure for Extension Car s
FLB 3202_00
FL FL is the prefix for the extensions of
the eWON Flexy family
Only FL (constant)
B
1 alphabetic sign (CAP)
Defines the slots of the base mo ule
in which the extension can be
inserte . See also § 3.6.1 Base Unit
Slot Compatibility
A 2 first slots only ●●○○
B 2 last slots only ○○●●
X In any slot ●●●●
3202_00 3G GSM Extension Car . The suffix _00 is use for software options.
3.3 Front Panel LEDs
Item Mark Function Picture
GSM Green ON =
Mo em is online
▄
Reception Signal level
Green ON = level >1
Poor signal
█
Reception Signal level
Green ON = level >10
Signal is OK
▄
█
Reception Signal level
Green ON = level >16
Good signal
Note : if all signal level LED's are off, either there is no signal at all (level 0) or there is a reception
error (level 99).
eWON Flexy - 3G GSM Extension Car - FLB 3202 (Installation Gui e) Page 8/17
Har ware Description Chapter 3.
3.4 Specifications of the 3G GSM Extension Card
Item Value(s)
Protocols and Frequencies GSM/GPRS/EDGE - 850, 900, 1800, 1900 MHz
UMTS/HSUPA - 800/850, 900 MHz
Class 5 ban GPRS/EDGE Class 33
Antenna Connector Type SMA-F Female
Antenna
(not inclu e in the elivery)
Charact. Value(s)
Range
Depen ing on frequency ban (s) provi e by the
network operator, the customer shall use the most
suitable antenna for that/those ban (s).
Impe ance 50 Ohms
VSWR <= 5:1 Absolute max. to avoi permanent amage
<= 2:1 Limit to fulfill all regulatory requirements
Gain
1.4 Bi @900 an 3 Bi @1800
1.4 Bi @850 an 3 Bi @1900
1.43 Bi (WCDMA)
Input Power > 33 Bm (2W) peak power in GSM
> 24 Bm average power in WCDMA
Tightening
Torque
0.5 Nm. In the absence of a torque wrench, a soft
manual tightening is sufficient.
Warning!
This evice is to be use only in fixe applications. The antenna use for this transmitter has to be
installe to provi e a istance of at least 20 cm from any person an may not be co-locate or operating
in conjunction with any other antenna or transmitter.
3.5 eWON Flexy Extension Cards Environmental Conditions
Characteristic Value
Operating temperature -25 to +70 °C
Storage temperature -40 to +70 °C
Relative humi ity 10 to 95% non-con ensing
Operating altitu e Up to maximum 2000m
Storage altitu e Up to maximum 3000m
eWON Flexy - 3G GSM Extension Car - FLB 3202 (Installation Gui e) Page 9/17
Har ware Description Chapter 3.
3.6 Plugging the Extension Card into the Base Unit
3.6.1 Base Unit Slot Compatibility
The 3G GSM Extension Card (FLB 3202) must be inserte in one of the “B” slots of the Base
Unit.
Explanation:
The Flexy Base Units feature two type of slots. The A slots are the two first slots starting from the
left. The B slots are the two last slots. Some car s fit in A an B slots. Some not. Car s that fit
only one type of slot have a mechanical mistake-proof security.
The reference co e of the Extension Car s inclu es a letter that efines their compatibility either
with “A” slots, “B” slots or both:
FLA xxxx - esignates car s that fit into “A” slots
FLB xxxx - esignates car s that fit into “B” slots
FLX xxxx - esignates car s that fit into both “A” an “B” slots
In a ition to the car reference, each type of extension car bears a visual compatibility symbol
on its front panel. The visual symbols are shown in the table below:
●●○○ 2 first slots only (A)
●●●● In any slot (X)
○○●● 2 last slots only (B)
