ewheels EW-1200 Manual
ewheelsdealers.com - 888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
Assembly and Setup Instructions
EW-1200
ewheelsdealers.com - 888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
Please observe and follow these instructions closely as it will ensure safe and reliable operation.
1. Remove the EW-1200 from it’s carton. Lift the bike out of the carton, assistance will be needed. If no
assistance available start by opening the top to allow access to the inside of the carton. Use a knife to cut
each corner from the inside out (Figure A). Once all four corners are cut it will allow a 360 degree access to
your new bike eliminating the heavy lifting.
2. Place the EW-1200 as shown (Figure B).
Tools you will need to assemble the EW-1200
1. Philips Screwdriver
2. 15mm wrench
3. Knife
4. 6mm Allen Wrench
ewheelsdealers.com - 888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
1. After you have placed the bike make sure you have all the components in the bike as shown in Figure C.
Components included on the EW-1100
A. Fender
B. Pedals
C. Charger
D. Front Wheel
ewheelsdealers.com - 888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
Handlebar Installation
1. Insert handlebar and align steering correspondingly (Figure A).
2. Use the 6mm Allen Wrench to tighten the steering wheel until it is fully tightened (Figure A).
Tools you will need to attach the Handlebar
- 6mm Allen Wrench
ewheelsdealers.com - 888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
Front Wheel Installation
-Prior Front Wheel installation made sure disc brake is on the correct side as shown in Figure A.
-Insert Wheel by lifting from steering wheel and secure (Figure B).
ewheelsdealers.com - 888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
Fender Installation
-Remove Screw located in the middle of steering wheel fork (Figure A).
-Insert the fender and secure it with screw (Figure B).
ewheelsdealers.com - 888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
Pedals Installation
1. Check each pedal for their corresponding side (L) Left and (R) Right (Figure A).
2. Insert pedal into place and tighten it using the 15mm Wrench (Figure B).
Tools you will need to attach the Pedals
-15mm Wrench
ewheelsdealers.com - 888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
How to properly remove the Battery Pack
1. Unlock the Battery lock located on Battery Pack.
2. Press on the lever underneath the seat to unlock the sea (Figure A).
3. Use Battery pack handle to remove Battery Pack (Figure B).
ewheelsdealers.com - 888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
Charging the Battery
1.
Plug Charger into Battery Pack (Figure A).
2. Leave Battery pack charge Until green light on charger appears
Warning!
(1) Charge in dry and airiness place, forbidden to charge in room.
(2) Charging far away clothing,, gasoline, alcohol, gas and so on the flammable things.
(3) When charging, the charger must not be touched by children.
(4) When charging, do not cover the battery charger with anything.
(5) Don’t directly touch the output plug with conductive object
ewheelsdealers.com - 888-305-0881 (Toll Free) -5000 Birch St West Tower- Suite 3000, Newport Beach, CA 92660
How to accelerate
-Turn the throttle down to accelerate
