Ewbank FP160 Guía

Care and Use Guide

Customer Services, Ewbank Products Ltd, Billington Road, Burnley

Lancashire, BB11 5ED.

Tel: 01282 835841

www.ewbank.co.uk

Floor Polisher

Model FP 60

Pack Contents:

1 - Scrubbing, polisher and waxing head

2 - Handle assembly

3 - Polishing pads blue) EB0129

4 - Scouring pads white) EB0130

5 - Scrubbing brush plates EB0131

6 - Velcro backed plates EB0132

7 - Care and use guide

Read the care and use guide before using

the Ewbank®Floor Polisher and make sure

that…

• The cable is in perfect condition.

• All packaging materials are removed from the

product.

Thank you for purchasing your Floor Polisher,

we hope you enjoy using it.

Please read the manual carefully to get the most

out of your product.

Floor Polisher

3456

Safety Instructions - CAUTION

• Do not allow machine to run unattended at

any time.

• Close supervision is necessary when this

machine is used near children. Do not allow it

to be used as a toy.

• The machine is designed for household use

only, do not expose to rain.

• Whilst in use never turn the machine over.

Keep machine level during use.

• To provide continued protection against the

risk of electric shock, connect properly to an

earthed socket.

• Use only genuine manufacturerʼs parts.

• It is recommended that a RCD (residual

current device) rated at 30mA is fitted into the

mains supply socket for added protection

against electric shock.

• Do not immerse power cable, plug or

machine in water or any other liquid.

• Take extra care if operating machine in bare

feet or when wearing open toe shoes or

sandals.

• Do not operate with a damaged power cable,

keep feet and all parts of body away from the

rotating pads.

Use power cable clip on handle to keep

power cable clear of rotating pads.

• Do not pull or carry by power cable, or use

power cable as a handle, close door on power

cable or pull power cable around sharp edges

or corners. Keep power cable away from

heated surfaces.

• Unplug the polisher when not in use. Turn all

controls off before unplugging from electrical

outlet.

• Do not unplug by pulling on power cable.

Always grasp the plug, not the power cable.

ever handle plug or appliance with wet

hands.

• Store in a dry place. Do not expose machine

to freezing temperatures.

• This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or

lack of experience and knowledge, unless

they have been given supervision or

instruction concerning use of the appliance by

a person responsible for their safety.

• Unplug after use and before cleaning.

• The Ewbank Floor Polisher is intended for

Domestic use and not Commercial use.

• Check pads for embedded grit or hard

material before using on floors or scratching

may occur.

Floor Polisher

Assembling the Appliance

• Insert the handle into the aperture at the top

of the body aligning the notch on the tube with

the rear of the unit, and straighten the security

collar (Fig.1).

Chang ng the pads and plates on your

product

• Make sure appliance is not plugged in before

fitting pads.

• ote the orientation of the drive hubs (Fig.2).

• Place the required velcro plate or brush plate

over the hub and rotate until the shape lines

up (Fig.3).

• Press the plate down to clip into place (Fig.4).

• Always use two plates of the same type, i.e.

not 1 brush and 1 pad (Fig.5).

• Simply pull the plates off to remove and

change.

Adjust the he ght of the handle to su t your

he ght (F g.6).

Floor Polisher

(Fig.2)

(Fig.3)

(Fig.4)

(Fig.5)

(Fig.1)

(Fig.6)

Floor Polisher

Us ng your floor pol sher on var ous floor

types

DO NOT USE ON CARPET

Take care not to slip over when polishing floors,

they can become very slippery in the process.

Only use dedicated floor products, other

inappropriate polishes and waxes may leave

the floor dangerously slippery.

Do not leave the product operating in one area

for a prolonged period of time as this may

damage your floor.

You may need a mop and bucket to clean and

prepare your hard floor, prior to polishing with

your floor polisher.

Clean ng hard floors w th heavy so l ng

• Use the brush heads to loosen dried on dirt.

• Take care not to scratch the floor if hard dirt

gets stuck to the brush heads.

Apply ng floor treatments

• Always read and follow manufacturerʼs

instructions for floor treatment products.

• Apply the treatment directly to the floor unless

instructions indicate otherwise.

T ps for pol sh ng wax on hard floors

• Once the wax polish has dried on the floor

use the blue buffing pads to polish.

• Keep the polishing head moving. Donʼt stop in

one place for a long time or it will spoil the

finish.

• Move at a speed of about 1 minute every 1m2

and follow the diagram for an even finish

(Fig.1).

• A glossy finish is not always possible; this

depends on the wax or polish used and the

type of floor. Sometimes several coats of wax

polish will help to get a glossy finish.

T ps for remov ng old pol sh

• Read and follow carefully the instructions for

your chosen floor polish remover.

• Use the white pads to scrub old polish from

the floor.

(approx. 1minute per metre square)

(Fig.1) 1m

Floor Polisher

• Ensure that the scrubbing brushes are

attached to the product (see page 4).

• Turn the product on at the power outlet.

• With your foot securing the head of the

polisher on the floor, pull the handle towards

you and the product will start (Fig.1).

• Move the product slowly across the surface of

the floor to loosen and collect any debris.

• Collect large debris towards the centre of the

base unit to prevent it from being spread

across the floor.

• Once this is complete, please turn the

product off, before returning it to its upright

position.

Scrubbing /Cleaning the floor

(Fig.1)

Pull back

to start

Place foot

on base

Polishing the floor

• Clean floor thoroughly first before adding your

chosen floor wax polish.

• Allow to dry before buffing using blue

polishing pads.

• With your foot securing the head of the

polisher on the floor, pull the handle towards

you and the product will start (see Fig.1).

• If you are using a floor polishing wax or oil,

refer to the manufacturersʼ instructions when

using with the Ewbank Floor Polisher.

• Move the product slowly (approx. 1minute per

1m2) across the surface of the floor in the

pattern illustrated in (Fig.2).

• Do not leave the product operating in one

area for a prolonged period of time as this

may damage your floor.

(approx. 1minute per metre square)

(Fig.2)

Power Cable Storage

• The electrical power cable can be stored on

the rear of the product using the convenient

power cable storage hooks.

Floor Polisher

Clean ng the floor pads

• All pads and floor attachments are washable.

• The brushes, polishing pads and scouring

pads can be washed under the tap with warm

soapy water.

• The polishing unit is not suitable for washing

in water, it must be wiped with a damp cloth.

•Smeary marks are made on floor when

pol sh ng.

- Has the polish/wax been allowed to dry.

- Does old polish/wax need to be removed?

•No gloss sheen s be ng produced.

- Floor wax level may need to be increased, try

another coat. Allow to dry and re-polish.

- However some types of floor do not produce

gloss finish.

•Scratches are made on the floor.

- Check for grit or dirt stuck to the pads or

wheels.

- Clean/replace pads or clean wheels.

•Floor s too sl ppery.

- Check the polish/wax is designed to be used

on floors. Floor wax should produce a glossy

but gripping finish.

Floor Polisher

EB0235 4/02/11

Your Guarantee

This product is covered by a 12 month guarantee.

This does not cover normal wear and tear or abuse.

For guarantee purposes, please retain your original receipt as proof of purchase.

For spares, service and further information please contact;

Customer Services, Ewbank Products Ltd, Billington Road, Burnley, Lancashire, BB11 5ED

www.ewbank.co.uk

Made in China

Your attention is brought to new directives applicable to the disposal of this electrical

equipment,where in accordance with the legislation this product must not be disposed of

in your normal household waste. Instead it is your responsibility to dispose of this type of

waste by handing it over to special designated collection points for recovery and recycling.

This product is marked with a ‘Wheelie bin’ symbol with a cross on it to remind you of this

action. The objective of this directive is to help conserve resources and ensure that it is

recycled in a manner that protects human health and the environment. For more information

about where you can drop off your waste please contact your local authority, take back

facilities are free of charge.

INFORMATION ON THE DISPOSAL OF WASTE ELECTRICAL AND

ELECTRONIC EQUIPMENT KNOWN AS WEEE

This guarantee does not affect your statutory rights.

Please phone our helpline Tel: 01282 835841 between 9am - 5.30pm Monday to Friday.

Techn cal Data

220-240V~50Hz

Rotational speed Approx. 2500 rpm.
