EVGA NForce 750i SLI Manual de usuario

1-1

Getting Started

Chapter1

Thankyouforchoosingthe750i(V1.X) ATXmainboard.

ThemainboardisbasedonNVIDIA nForce750i SLI

(C72P)&430i(MCP51)chipsetsforoptimal system

efficiency.DesignedtofittheadvancedIntel CoreTM2

Extreme,CoreTM2Quad,CoreTM2Duo, Pentium Dual-

Coreand Celeron processors,themainboarddelivers

ahigh performanceand professionaldesktopplatform

solution.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

750iMainboard

1-2

MainboardSpecifications

Processor

-Intel CoreTM2Extreme,CoreTM2Quad,CoreTM2Duo,Pentium

Dual-Coreand Celeron processorsin theLGA775 package

-SupportsIntel SpeedStepTechnology(EIST)

-SupportsIntel Hyper-Threading Technology(HT)

FSB

-400/533/800/ 1066/ 1333/1800 (OC)MHz

Chipset

-NorthBridge:NVIDIA nForce750iSLIchipset(C72P)

-SouthBridge:NVIDIA nForce430ichipset(MCP51)

Memory

-DDR2533/667/ 800/1200(OC)SDRAM

-4DDR2DIMMslots(8GBMax)(240-Pin/ 1.8V)

LAN

-Supports10/100/1000 FastEthernetbyRealtek RTL8211BL

-CompliantwithPCI2.2

-SupportsACPIPowerManagement

IEEE1394

-Chip integrated byVIA VT6308P

-Transferrateisup to400 Mb/s

Audio

-ChipintegratedbyRealtek ALC888S

-Flexible8-channelaudiowithjacksensing

-CompliantwithAzalia1.0spec

-MeetMicrosoft Windows VistaTM Premiumspec

IDE

-2IDEportsbyNVIDIA nForce430i

-SupportsfourIDEdevices

-SupportsUltraDMA33/ 66/100/ 133mode

-SupportsPIO, BusMasteroperationmode

SATA

-4SATAportsbyNVIDIA nForce430i

-SupportsfourSATAdevices

-Supportsstorageand datatransfersup to3Gb/s

-1eSATAportbyJMicron JMB363

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1-3

Getting Started

RAID

-4SATAII portssupport RAID0/1/ 0+1/5orJBODmodebyNVIDIA

nForce430i

-1eSATAportsupportRAID0/1mode byJMicron JMB363

Floppy

-1floppyportsupports1FDDwith360KB,720KB, 1.2MB,1.44MB

and2.88MB

BackPanel

-1PS/2mouse/keyboardport

-1opticalS/PDIF-out port

-1coaxialS/PDIF-outport

-1debugLED

-1clearCMOSbutton

-1IEEE1394port

-6USB ports

-1eSATAport

-1LANjack

-6audiojacks

Connector

-1CD-in connector

-1frontpanelaudioconnector

-1serialportconnector

-1IEEE1394connector

-1USB connector

-1S/PDIF-outconnector

Slots

-2PCIexpress x16 slots

-1PCI express x1slot

-2PCIslotssupport 3.3V/ 5VPCIbusinterface

FormFactor

-ATX(30.5cmX24.5cm)

Mounting

-9mounting holes

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

750iMainboard

1-4

750i (V1.X) ATXMainboard

MainboardLayout

PCI1

PCI_E1

PCI_E2

PCI_E3

PCI2

IDE1

IDE2

FDD1

J1394_1

JAUD1

BATT

JUSB1

SYSFAN3

JCOM1

T: LINE-IN

M:LINE-OUT

B:MIC

T:RS-OUT

M:CS-OUT

B:SS-OUT

SATA3_4SYSFAN2

JPWR2

JCD1

JPWR1

CPUFAN1

SATA1_2

JFP1JFP2

T:MOUSE/

B: USBPORTS

KEYBOARD

T:LANJACK

B:USB PORTS

T:1394PORT

B: USBPORTS/ESATAPORT

JOC1

DIMM1

DIMM2

DIMM3

DIMM4

NVIDIA

C55

NVIDIA

MCP51

VIA

VT6308P

NVIDIA

NF200

FINTEK

F71882FG

REALTEK

ALC888S

JMICRON

JMB363

REALTEK

RTL8211BL SYSFAN1

CLEARCMOSBUTTON

T:OPTICALS/PDIF-OUT

B: COAXIALS/PDIF-OUT

DEBUGLED

JSPDIF

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1-5

Getting Started

*The picturesareforreferenceonly.Yourpackingcontentsmayvarydependingon

the modelyou purchased.

PackingChecklist

Mainboard Driver/UtilityCD Back I/OShield

PowerCable SATACable StandardCablefor

IDEDevices

2-WaySLIbridgecable

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

2-1

HardwareSetup

Chapter2

Thischapterprovidesyou withtheinformation about

hardwaresetupprocedures.Whiledoingthe installation,

becarefulinholdingthecomponentsandfollowthe

installationprocedures.Forsomecomponents,ifyou

install inthewrong orientation,thecomponentswillnot

workproperly.

Useagroundedwrist strapbeforehandlingcomputer

components.Staticelectricitymaydamagethe

components.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

750iMainboard

2-2

Quick ComponentsGuide

Memory,

p.2-7

JPWR1,

p.2-9

CPUFAN1,

p.2-16

CPU,

p.2-3

IDE1/2,

p.2-14

FDD1,

p.2-15

SATA1/2/3/4,

p.2-15

SYSFAN1,

p.2-16

J1394_1,

p.2-16

Slots,

p.2-28

JAUD1,

p.2-18

JCD1,

p.2-17

JFP1/2,

p.2-17

JUSB1,

p.2-19

JCOM1,

p.2-19

BackPanel,

p.2-11

JPWR2,

p.2-10

SYSFAN3,

p.2-16

JOC1,

p.2-20

SYSFAN2,

p.2-16

JSPDIF,

p.2-18

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

2-3

HardwareSetup

CPU(CentralProcessingUnit)

ThismainboardsupportsIntel processorsin theLGA775 package.Whenyouare

installingtheCPU, makesuretoinstallthecoolertoprevent overheating.Ifyou do not

havetheCPUcooler,consultyourdealerbeforeturning onthecomputer.

1.Overheatingwill seriouslydamagethe CPUand system.Alwaysmakesure

thecoolingfancanworkproperlytoprotecttheCPUfromoverheating.

Makesurethatyou applyaneven layerofthermalpaste(orthermaltape)

between theCPUand the heatsinktoenhanceheatdissipation.

2.Whilereplacing the CPU,always turnoff theATXpowersupplyorunplug

the powersupply spowercordfromthe grounded outlet firsttoensurethe

safetyofCPU.

3.Thismainboardisdesigned tosupportoverclocking.However,please

makesureyourcomponentsareable totoleratesuchabnormal setting,

whiledoing overclocking.Anyattempttooperatebeyondproductspecifi-

cationsisnotrecommended.Wedonotguarantee the damagesorrisks

caused byinadequateoperation orbeyondproductspecifications.

Important

Introduction toLGA775 CPU

YellowtriangleisthePin1indicator

Alignment Key

The pin-pad sideofLGA775CPU.

YellowtriangleisthePin1indicator

Alignment Key

ThesurfaceofLGA775CPU.Re-

membertoapplysomethermalpaste

onitforbetterheat dispersion.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

750iMainboard

2-4

CPU&Cooler Installation

When you areinstallingtheCPU,makesuretheCPUhasacoolerattachedon thetop

toprevent overheating.Meanwhile, do notforget toapplysomethermalpasteonCPU

beforeinstallingtheheatsink/coolerfanforbetterheat dispersion.Followthesteps

belowtoinstalltheCPU&coolercorrectly. Wrong installation will causethedamage

ofyourCPU&mainboard.

2.Removethe capfromleverhinge

side(asthe arrowshows).

1.TheCPUsockethasaplasticcap

onittoprotectthe contactfrom

damage.Beforeyouinstall the

CPU,alwayscoverittoprotect

thesocketpin.

4.Opentheloadlever.3.Thepinsof socketreveal.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com
