EVERVIEW Diamon Series Manual de usuario

Network Video Recorder

User Manual

User Manual of Network Video Recorder

Regulatory information

FCC information

FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant

to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct the interference at his own expense.

FCC conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the

applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC, the EMC

Directive 2004/108/EC, the RoHS Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal

waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of

equivalent new equipment, or dispose of it at designated collection points. For more information see:

www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal

waste in the European Union. See the product documentation for specific battery information. The battery is

marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For

proper recycling, return the battery to your supplier or to a designated collection point. For more information see:

www.recyclethis.info.

User Manual of Network Video Recorder

Preventive and Cautionary Tips

Before connecting and operating your device, please be advised of the following tips:

•Ensure unit is installed in a well-ventilated, dust-free environment.

•Unit is designed for indoor use only.

•Keep all liquids away from the device.

•Ensure environmental conditions meet factory specifications.

•Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of dropping it

may cause damage to the sensitive electronics within the unit.

•Use the device in conjunction with an UPS if possible.

•Power down the unit before connecting and disconnecting accessories and peripherals.

•A factory recommended HDD should be used for this device.

•Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or

equivalent type only. Dispose of used batteries according to the instructions provided by the battery

manufacturer.

User Manual of Network Video Recorder

Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer.

The figures in the manual are for reference only.

This manual is applicable to the models listed in the following table.

Series

Model

Type

NRA00

NRA00-16

NRA00-32

NRA00-64

Network Video Recorder

NRA0R

NRA0R-16

NRA0R-32

NRA0R-64

Network Video Recorder

NR500

NR500-16

NR500-32

Network Video Recorder

NR50P

NR50P6-16

NR50P6-32

Network Video Recorder

User Manual of Network Video Recorder

Product Key Features

General

Connectable to network cameras, network dome and encoders.

Connectable to the third-party network cameras like ACTI, Arecont, AXIS, Bosch, Brickcom, Canon,

PANASONIC, Pelco, SAMSUNG, SANYO, SONY, Vivotek and ZAVIO, and cameras that adopt

ONVIF or PSIA protocol.

Connectable to the smart IP cameras.

PAL/NTSC adaptive video inputs.

Each channel supports dual-stream.

Up to 64 network cameras can be connected for NRA00&NRA0R and NR500 series NVR, and 32

network cameras for NR50P series.

Independent configuration for each channel, including resolution, frame rate, bit rate, image quality, etc.

The quality of the input and output record is configurable.

Local Monitoring

Simultaneous HDMI, VGA and CVBS outputs.

HDMI output and VGAoutput at up to 1920×1080 resolution.

Multiple screen display in live view is supported, and the display sequence of channels is adjustable.

Live view screen can be switched in group, and manual switch and automatic cycle live view are also

provided, and the interval of automatic cycle can be adjusted.

Quick setting menu is provided for live view.

Motion detection, video tampering, video exception alert and video loss alert functions.

Privacy mask.

Multiple PTZ protocols supported; PTZ preset, patrol and pattern.

Zooming in by clicking the mouse and PTZ tracing by dragging mouse.

HDD Management

For NR50P&NR500 series, up to 4 SATA hard disks and 1 eSATA disk can be connected. For

NRA00&NRA0R series, up to 8 SATA hard disks and 1 eSATAdisk can be connected. (Each disk with a

maximum of 4TB storage capacity.)

8 network disks (8 NAS disks, or 7 NAS disks+1 IP SAN disk) can be connected.

Support eSATAdisks for recording or backup.

Support S.M.A.R.T. and bad sector detection. (Not supported with NRA0R series NVR.)

HDD group management.

Support HDD standby function.

HDD property: redundancy, read-only, read/write (R/W).

HDD quota management; different capacity can be assigned to different channel.

Hot-swappable HDD supporting RAID0, RAID1, RAID5 and RAID10 storage scheme. And 8 virtual

disks can be configured. (Only for the NRA0R series NVR.)

Support disk clone to the eSATAdisk.

Recording, Capture and Playback

Holiday recording schedule configuration.

Continuous and event video recording parameters.

Multiple recording types: manual, continuous, alarm, motion, motion | alarm, motion & alarm.

8 recording time periods with separated recording types.

Pre-record and post-record for alarm, motion detection for recording, and pre-record time for schedule

and manual recording.

Searching record files and captured pictures by events (alarm input/motion detection).

User Manual of Network Video Recorder

Tag adding for record files, searching and playing back by tags.

Locking and unlocking record files.

Local redundant recording and capture.

Provide new playback interface with easy and flexible operation.

Searching and playing back record files by channel number, recording type, start time, end time, etc.

Smart search for the selected area in the video.

Zooming in when playback.

Reverse playback of multi-channel.

Supports pause, play reverse, speed up, speed down, skip forward, and skip backward when playback,

and locating by dragging the mouse.

Up to 16-ch synchronous playback at 4CIF real time.

Manual capture, continuous capture of video images and playback of captured pictures.

Backup

Export video data by USB, SATA or eSATA device.

Export video clips when playback.

Management and maintenance of backup devices.

Either Normal or Hot Spare working mode is configurable to constitute an N+1 hot spare system.

Alarm and Exception

Configurable arming time of alarm input/output.

Alarm for video loss, motion detection, tampering, abnormal signal, video input/output standard

mismatch, illegal login, network disconnected, IP confliction, abnormal record/capture, HDD error, and

HDD full, etc.

Alarm triggers full screen monitoring, audio alarm, notifying surveillance center, sending email and

alarm output.

Automatic restore when system is abnormal.

Other Local Functions

Operable by front panel, mouse, remote control, and control keyboard.

Three-level user management; admin user is allowed to create many operating accounts and define their

operating permission, which includes the limit to access any channel.

Operation, alarm, exceptions and log recording and searching.

Manually triggering and clearing alarms.

Import and export of device configuration information.

Network Functions

2 self-adaptive 10M/100M/1000M network interfaces, and various working modes are configurable:

multi-address, load balance, network fault tolerance, etc. (Two NIC are only for the NRA00 and NRA0R

series NVR.)

Up to 16 independent PoE network interfaces are provided for NR50P series.

IPv6 is supported.

TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, and iSCSI are

supported.

TCP, UDP and RTP for unicast.

Auto/Manual port mapping by UPnPTM.

Remote web browser access by HTTPS ensures high security.

Remote reverse playback via RTSP.

Support accessing by the platform via ONVIF.

User Manual of Network Video Recorder

Remote search, playback, download, locking and unlocking of the record files, and support downloading

files broken transfer resume.

Remote parameters setup; remote import/export of device parameters.

Remote viewing of the device status, system logs and alarm status.

Remote keyboard operation.

Remote locking and unlocking of control panel and mouse.

Remote HDD formatting and program upgrading.

Remote system restart and shutdown.

RS-232, RS-485 transparent channel transmission.

Alarm and exception information can be sent to the remote host

Remotely start/stop recording.

Remotely start/stop alarm output.

Remote PTZ control.

Remote JPEG capture.

Virtual host function is provided to get access and manage the IP camera directly.

Two-way audio and voice broadcasting.

Embedded WEB server.

User Manual of Network Video Recorder

TABLE OF CONTENTS

Chapter 1 Introduction.............................................................................................................................. 11

1.1 Front Panel ....................................................................................................................................12

1.2 Rear Panel .....................................................................................................................................21

Chapter 2 Getting Started .........................................................................................................................23

2.1 Starting Up and Shutting Down the NVR......................................................................................24

2.2 Using the Wizard for Basic Configuration.....................................................................................26

2.3 Adding and Connecting the IP Cameras........................................................................................31

2.3.1 Adding the Online IP Cameras.............................................................................................31

2.3.2 Editing the Connected IP Cameras and Configuring Customized Protocols........................34

2.3.3 Editing IP Cameras Connected to the PoE Interfaces ..........................................................37

Chapter 3 Live View ..................................................................................................................................40

3.1 Introduction of Live View .............................................................................................................41

3.2 Operations in Live View Mode......................................................................................................42

3.2.1 Front Panel Operation on Live View....................................................................................42

3.2.2 Using the Mouse in Live View.............................................................................................43

3.2.3 Using an Auxiliary Monitor.................................................................................................44

3.2.4 Quick Setting Toolbar in Live View Mode ..........................................................................44

3.3 Adjusting Live View Settings........................................................................................................47

3.4 Channel-zero Encoding .................................................................................................................49

3.5 User Logout...................................................................................................................................50

Chapter 4 PTZ Controls............................................................................................................................51

4.1 Configuring PTZ Settings..............................................................................................................52

4.2 Setting PTZ Presets, Patrols & Patterns.........................................................................................53

4.2.1 Customizing Presets.............................................................................................................53

4.2.2 Calling Presets .....................................................................................................................54

4.2.3 Customizing Patrols.............................................................................................................54

4.2.4 Calling Patrols .....................................................................................................................56

4.2.5 Customizing Patterns...........................................................................................................57

4.2.6 Calling Patterns....................................................................................................................58

4.3 PTZ Control Panel.........................................................................................................................59

Chapter 5 Recording and Capture Settings.............................................................................................60

5.1 Configuring Parameters.................................................................................................................61

5.2 Configuring Recording/Capture Schedule.....................................................................................64

5.3 Configuring Motion Detection Recording and Capture.................................................................68

5.4 Configuring Alarm Triggered Recording and Capture...................................................................70

5.5 Manual Recording and Continuous Capture..................................................................................72

5.6 Configuring Holiday Recording and Capture................................................................................74

5.7 Configuring Redundant Recording and Capture............................................................................76

5.8 Configuring HDD Group for Recording and Capture....................................................................78

5.9 Files Protection..............................................................................................................................79

5.9.1 Locking the Recording Files................................................................................................79

5.9.2 Setting HDD Property to Read-only ....................................................................................81

User Manual of Network Video Recorder

Chapter 6 Playback....................................................................................................................................83

6.1 Playing Back Record Files ............................................................................................................84

6.1.1 Playing Back by Channel.....................................................................................................84

6.1.2 Playing Back by Time..........................................................................................................86

6.1.3 Playing Back by Event Search.............................................................................................88

6.1.4 Playing Back by Tag ............................................................................................................90

6.1.5 Smart Playback....................................................................................................................93

6.1.6 Playing Back by System Logs .............................................................................................94

6.1.7 Playing Back External File ..................................................................................................96

6.2 Auxiliary Functions of Playback ...................................................................................................97

6.2.1 Playing Back Frame by Frame.............................................................................................97

6.2.2 Smart Search........................................................................................................................97

6.2.3 Digital Zoom........................................................................................................................99

6.2.4 Reverse Playback of Multi-channel .....................................................................................99

6.3 Picture Playback..........................................................................................................................101

Chapter 7 Backup ....................................................................................................................................103

7.1 Backing up Record Files .............................................................................................................104

7.1.1 Quick Export......................................................................................................................104

7.1.2 Backing up by Normal Video Search.................................................................................105

7.1.3 Backing up by Event Search.............................................................................................. 112

7.1.4 Backing up Video Clips ..................................................................................................... 114

7.2 Backing up Pictures..................................................................................................................... 117

7.3 Managing Backup Devices.......................................................................................................... 119

7.4 Hot Spare Device Backup............................................................................................................122

7.4.1 Setting Hot Spare Device...................................................................................................122

7.4.2 Setting Working Device.....................................................................................................123

7.4.3 Managing Hot Spare System..............................................................................................123

Chapter 8 Alarm Settings........................................................................................................................126

8.1 Setting Motion Detection Alarm..................................................................................................127

8.2 Setting Sensor Alarms .................................................................................................................129

8.3 Detecting Video Loss Alarm........................................................................................................132

8.4 Detecting Video Tampering Alarm..............................................................................................134

8.5 Detecting VCAAlarm .................................................................................................................136

8.6 Handling Exceptions Alarm.........................................................................................................138

8.7 Setting Alarm Response Actions .................................................................................................139

8.8 Triggering or Clearing Alarm Output Manually..........................................................................142

Chapter 9 Network Settings ....................................................................................................................143

9.1 Configuring General Settings......................................................................................................144

9.2 Configuring Advanced Settings...................................................................................................146

9.2.1 Configuring PPPoE Settings..............................................................................................146

9.2.2 Configuring DDNS............................................................................................................146

9.2.3 Configuring NTP Server....................................................................................................150

9.2.4 Configuring SNMP............................................................................................................150

9.2.5 Configuring Remote Alarm Host .......................................................................................151

User Manual of Network Video Recorder

9.2.6 Configuring Multicast........................................................................................................152

9.2.7 Configuring RTSP..............................................................................................................152

9.2.8 Configuring Server and HTTP Ports..................................................................................152

9.2.9 Configuring HTTPS Port...................................................................................................153

9.2.10 Configuring Email .............................................................................................................155

9.2.11 Configuring NAT...............................................................................................................156

9.2.12 Configuring High-speed Download...................................................................................159

9.2.13 Virtual Host Settings..........................................................................................................160

9.2.14 Telnet Settings....................................................................................................................161

9.3 Checking Network Traffic...........................................................................................................162

9.4 Configuring Network Detection ..................................................................................................163

9.4.1 Testing Network Delay and Packet Loss............................................................................163

9.4.2 Exporting Network Packet.................................................................................................163

9.4.3 Checking the Network Status.............................................................................................164

9.4.4 Checking Network Statistics..............................................................................................165

Chapter 10 RAID (Only for NRA0R series NVR)...................................................................................167

10.1 Configuring Array and Virtual Disk ............................................................................................168

10.1.1 One-touch Configuration ...................................................................................................169

10.1.2 Manually Creating Array and Virtual Disk ........................................................................170

10.2 Rebuilding Array.........................................................................................................................175

10.2.1 Automatically Rebuilding Array........................................................................................175

10.2.2 Manually Rebuilding Array ...............................................................................................176

10.3 Repairing Virtual Disk.................................................................................................................178

10.4 Deleting Array / Virtual Disk.......................................................................................................179

10.4.1 Deleting the Virtual Disk ...................................................................................................179

10.4.2 Deleting the Array..............................................................................................................179

10.5 Upgrading Firmware ...................................................................................................................181

Chapter 11 HDD Management .................................................................................................................183

11.1 Initializing HDDs ........................................................................................................................184

11.2 Managing Network HDD ............................................................................................................186

11.3 Managing eSATA ........................................................................................................................188

11.4 Managing HDD Group................................................................................................................189

11.4.1 Setting HDD Groups..........................................................................................................189

11.4.2 Setting HDD Property........................................................................................................190

11.5 Configuring Quota Mode.............................................................................................................192

11.6 Configuring Disk Clone ..............................................................................................................194

11.7 Checking HDD Status .................................................................................................................196

11.8 HDD Detection............................................................................................................................198

11.9 Configuring HDD Error Alarms..................................................................................................200

Chapter 12 Camera Settings .....................................................................................................................201

12.1 Configuring OSD Settings...........................................................................................................202

12.2 Configuring Privacy Mask...........................................................................................................203

12.3 Configuring Video Parameters ....................................................................................................204

Chapter 13 NVR Management and Maintenance ...................................................................................205

Tabla de contenidos

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario
