Introduction

Welcome to the eurosec control panel. Your installation company will

have programmed your system to protect your premises to the highest

possible standards. Several user programmable options are available

that will be covered later in this manual. Throughout this manual,

reference will be made to the Master User Code, the factory set

default is 5678. This code is programmable along with eight other User

Codes.

The Control Panel will have been supplied with either an icon

style keypad or text style keypad. Please follow the instruction

relevant to your keypad style.Text commands will be shown in

brackets.

If an Engineer is on site, it may be necessary to authorise them to

access your system. Do this by entering your User Code when

asked to do so by the engineer.

Icon style keypad Text style keypad

Full

Part

Quick

Yes

PPaa

aagg

ggee

PR5202 Rev 14 CP8L LCD User EN.qxd 11/07/2006 14:54 Page 1

PPaa

aagg

ggee

Display Status Blanking

Depending on Control Panel installed, it may be a requirement that

the Status (Set or Unset display) of the security system is not

displayed. Set or Unset Status will only be displayed for ten seconds

when the system is Set or Unset. The bottom line of the display will

then be blanked off.

If the Control Panel is non EN then all displays will be shown and

“CHECK” will not be displayed.

All information displays will remain until cleared by the User.

IMPORTANT USER INFORMATION

PR5202 Rev 14 CP8L LCD User EN.qxd 11/07/2006 14:54 Page 2

PPaa

aagg

ggee

Full Setting the System.

Two methods are available for Full Set.

After checking the premises are secure:

1) Enter a valid User Code followed by . (Full).

Press *.(Quick)*.

* If enabled by the installation engineer.

2) The exit tone will now sound.

3) Exit the premises via an authorised exit route.

4) Once the premises are secure, listen (from outside the

protected area) for the exit tone to finish.

Note: Pressing the (Quick) key during exit will shorten the exit

time to 3 seconds.

Note: To abort the exit, enter a valid User Code.

Setting & Unsetting the System via a Keyswitch (if fitted).

Biased Keyswitch

To set the system with a biased keyswitch, insert the key and turn it,

then return the key to the original position and remove. Follow the

instructions from step 3 (above).To unset, repeat this operation.

PR5202 Rev 14 CP8L LCD User EN.qxd 11/07/2006 14:54 Page 3

PPaa

aagg

ggee

Pre Exit Check.

At the start of the setting procedure, a fault

tone will sound if any non exit routes are

open. The display will show, for example:-

If the fault clears within 20 seconds then the exit tone will begin, if not,

the fault tone will continue until a valid User code is entered.

Part Setting the System (using Part 1).

Up to three Part Sets may be available for your system. Please refer to

the customer details at the rear of this manual for information about

Part Set zones. Part Set zones will be omitted from the system when

that particular Part Set is used. To set the system using Part 1.

1) Enter a valid User Code followed by . (Part).

Press * (Quick)* followed by . (Part).

2) Retire to an unprotected area.

Note: Pressing the Quick key during exit will shorten the exit time

to 3 seconds.

Note: To abort the exit, enter a valid User Code.

Exit Now ! . . .

Zone 3

* If enabled by installation engineer

PR5202 Rev 14 CP8L LCD User EN.qxd 11/07/2006 14:54 Page 4

PPaa

aagg

ggee

Part Setting the System (using Part 2 or 3).

Two other Part Sets may be available for your system. Part 2 is a

second set of zones that may be omitted and Part 3 will combine Part

1 and Part 2. To use Part 2 or 3.

1) Enter a valid User Code followed by 2 or 3.

Press * (Quick)* followed by 2 or 3.

2) Retire to an unprotected area.

Note: Pressing the Quick key during exit will shorten the exit time

to 3 seconds.

Note: To abort the exit, enter a valid User Code.

3) The exit tone may or may not be heard depending on the

system settings programmed by the installation company.

4) Exit the premises or retire to an unprotected part of the

system. At the end of the exit time, either the exit sounder

will stop (if the exit tone has been audible) or a single beep

will be emitted (if the exit tone has been silent).

5) The system is now Part Set.You are free to move around the

zones that have been removed by the Part Set but other

zones on the system are active.

* If enabled by installation engineer

PR5202 Rev 14 CP8L LCD User EN.qxd 11/07/2006 14:54 Page 5

PPaa

aagg

ggee

Unsetting the System.

1) Enter the premises via an authorised Entry Point.

2) The entry tone will sound.

3) Proceed to the keypad and enter a valid User Code.

Display After an Alarm.

If an alarm occurs when the system is set, the cause of the alarm will

be displayed for 10 seconds after you unset the system.

1) The display will show, for

example:-

2) Then, after 10 seconds the display

will show:-

3) To view the cause of the alarm again, enter your User code.

Then press 0.

! ! ! ALARM ! ! !

Zone 4

!!!! CHECK ! ! ! ! !

PR5202 Rev 14 CP8L LCD User EN.qxd 11/07/2006 14:54 Page 6

PPaa

aagg

ggee

Resetting After an Alarm

After an alarm the system needs to be reset.

Your installation company will have programmed the reset modes for

your system so that it complies with your insurance company and

legislation requirements.

Your installation company will have informed you as to the type of

reset that your system is set for.

Before attempting to reset your system, ensure that the system

is Un-set and the fault has been rectified.

1) If the system has been

programmed for Anycode reset;

2) With the display showing:-

Enter your User code

3) Then press Reset.

The system is now reset.

!!!! CHECK ! ! ! ! !

PR5202 Rev 14 CP8L LCD User EN.qxd 11/07/2006 14:54 Page 7

PPaa

aagg

ggee

If a Master Code Reset has been programmed by the engineer, a

higher level of code will be required.

If Alarm Reset has been programmed for Master, then the display will

show, for example, each time the User attempts to set

the system.

Use a Master code to reset the system.

1) With the display showing:-

Enter a valid Master code.

2) Press Reset.

The system is now reset.

If an Engineer Code Reset has been programmed, please call the

Installation Company.

If Alarm Reset has been programmed for Engineer, then the display

will show, for example, each time the User attempts to

reset the system.

! ! ! ALARM ! ! !

Zone 4

!!!! CHECK ! ! ! ! !

! ! ! ALARM ! ! !

Zone 4

PR5202 Rev 14 CP8L LCD User EN.qxd 11/07/2006 14:54 Page 8
