User Manual
Eclipse Series Gas Cooktops
EC64GS
60cm 4 burner gas cooktop - stainless steel
EC64GB
60cm 4 burner gas cooktop - black glass
EC74GTB
75cm 4 burner gas cooktop, twin wok - black glass
EC95GLS
90cm 5 burner gas cooktop - stainless steel
EC95GLB
90cm 5 burner gas cooktop - black glass
For your safety
Installation.........................................3
During use.........................................4
Safety of children and the infirm . . . . . . . . . . . . . . . . . . . . . . . . 6
Service and repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Environmental protection advice . . . . . . . . . . . . . . . . . . . . . . . . 6
Use and Care
Description of the hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Instructions for use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
To Light the Burners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
For correct use of the hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Abnormal Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Service and spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Warranty .........................................14
Installation
Technical data.....................................15
Instructions for Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Building into kitchen benches . . . . . . . . . . . . . . . . . . . . . . . . . 16
Combustible surfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Installation cutout drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Connection to the gas supply . . . . . . . . . . . . . . . . . . . . . . . . . 20
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Replacing the power supply lead. . . . . . . . . . . . . . .
. . . . . . . .
21
Before leaving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Gas Conversion (NG to ULPG) . . . . . . . . . . . . . . . . . . . . . . . . 24
Gas Conversion (ULPG to NG) . . . . . . . . . . . . . . . . . . . . . . . . 25
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2
Contents
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3
These instructions have been drawn up for your safety and that of
others. You are therefore requested to read them carefully before
installing and using the appliance. Keep this instruction manual for
future reference as necessary. If the appliance is sold or moved,
make sure that the manual is handed over to the new user.
INSTALLATION
·Installation of the appliance and its connection to the
electrical mains must only be carried out by Authorised
Personnel. Before any service procedure, it is important to
check that the appliance is DISCONNECTED from the
electrical mains.
·WARNING: This appliance is a domestic kitchen appliance
suitable for indoor installation. It is not suitable for outdoor
installations such as alfresco kitchens or garages unless a
qualified, competent installer has deemed the location and
installation to be suitable & compliant.
·DO NOT MODIFY THIS APPLIANCE.
·After removing the appliance from the packaging, make
sure that it is undamaged and that the electrical lead is in
perfect condition. Otherwise, contact your dealer before
operating the appliance.
·Make sure that air is able to circulate freely around the
appliance. Poor ventilation produces a shortage of oxygen.
·Make sure that the available gas supply matches the type
of gas indicated on the data label and the gas type label
next to the gas connection point.
·Use of a gas cooking appliance produces heat and
moisture in the room in which it is installed. Ensure that
the room is well ventilated by keeping the air intakes open
and in good working order or by installing an extractor
hood with discharge pipe.
·If the appliance is used intensively for a long time the
effectiveness of the ventilation will have to be increased,
for example by opening a window or increasing the power
of any electric extractor fan.
For Your Safety
DURING USE
·
homes and for non-commercial purposes. It should not be
used for any other purpose.
·After using the appliance, make sure that all controls are in
'CLOSED' or 'OFF' position.
·If you use an electrical socket close to this appliance, take
care that the cables of the appliances you are using do not
touch it and are far enough away from the hot parts of this
appliance.
·DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS
APPLIANCE WHILE IT IS IN OPERATION.
·DO NOT STORE OR USE FLAMMABLE LIQUIDS OR ITEMS
IN THE VICINITY OF THIS APPLIANCE.
·NOT FOR USE IN MARINE CRAFT, CARAVANS OR MOBILE
HOMES UNLESS EACH BURNER IS FITTED WITH FLAME
SAFEGUARD.
·WHERE THIS APPLIANCE IS INSTALLED IN MARINE
CRAFT OR IN CARAVANS, IT SHALL NOT BE USED AS A
SPACE HEATER.
·WARNING - Accessible parts will become hot when in use.
To avoid burns and scalds children should be kept away.
·This appliance is not intended for use by young children or
infirm persons without supervision
·Young children should be supervised to ensure they do not
play with the appliance.
This product is designed to cook foods inside private
4
For Your Safety
For Your Safety
5
Do not place anything, eg. flame tamer,
asbestos mat, between pan and pan support
as serious damage to the appliance my result.
Do not remove the pan support and enclose
the burner with a wok stand as this will
concentrate and deflect heat onto the hotplate.
Do not use large pots or heavy weights which
can bend the pan support or deflect flame
onto the hotplate.
During use (continued)
·Explanation of symbols on the glass top.
(For Gas on glass models only)
Safety of children and the infirm
This appliance must only be used by adults. Make sure that
children do not touch the controls or play with the appliance.
The exposed parts of this appliance heat up during cooking and
remain hot for some time even after it is switched off. Keep
children well away until the appliance has cooled down.
Cleaning and maintenance
Keep the appliance thoroughly cleaned. Food residues may cause
fire risks.
Service and repairs
If the appliance fails to operate correctly, never attempt to repair
the appliance yourself. Repairs by unskilled persons may cause
damage and accidents. First refer to the contents of this manual. If
you do not find the necessary information, contact your nearest
Service Center. Servicing work on this appliance must be carried
out by Authorised Personnel. Always request the use of original
spare parts.
For Service & Spare Parts please contact:
1300 556 816 (AU) or 09 274 8265 (NZ)
Environmental protection advice
All the materials used are environmentally friendly and recyclable.
Please make your contribution to conserving the environment by
using the separate waste collection channels available when
disposing of this product. Through environment-friendly disposal,
a number of materials used in the production of your appliance
can be recycled. Find out about the current disposal options from
your local authority.
6
For Your Safety
Use and Care
Description of the hob
1. Hob
2. Auxiliary burner
3. Semi-rapid burner
4. Rapid burner
5. Wok burner
6. Pan supports
7. Control knobs
1
2
5
4
6
7
3
A
B
C
D
E
A - Burner cap
B - Burner head
C - Burner bowl
D - Thermocouple
E - Ignition Candle
7
3
Note: Model shown may not be identical to the hotplate you have purchased.
C
D
E
B
A
A
Use and Care
8
Instructions for use
The symbols on the control knobs mean the following:
Regular burners (Auxiliary, Semi Rapid, Rapid, Wok)
1. No gas flow or 'Off' position.
2. Maximum gas flow or 'High' flame and lighting position.
3. Minimum gas flow or 'Low' flame position.
Dual Valve Wok burner (Not all models)
1. No gas flow or 'Off' position.
2. Maximum gas flow for inner and outer flame or 'High' flame
and lighting position.
3. Minimum gas flow for outer flame only or 'Low' flame
position. NOTE: Inner flame remains in ‘High’ position at
this point.
4. Minimum gas flow for inner flame or ‘Low’ flame position.
No outer flame.
All burners
5. Position of the burner each control knob operates.
All operating positions must be set between the maximum and
minimum flow settings, and never between the maximum setting
and the closed position.
Dual WokRegular Burners
1.
2.
4.
3.
5.
1.
2.
3.
5.
To light the burners
To light the burner, press the control knob down completely and
hold down before rotating anti-clockwise to the ‘High’ Flame
position. The ignition device is integrated into the control knob and
is automatically activated by pushing down on the control knob.
After lighting the flame, keep the knob pressed for about 5
seconds: this time is necessary to heat up the thermocouple (D on
page 7) and activate the safety valve, which would otherwise cut
off the gas flow.
In the instance of a power failure, place a lit match near the burner
and proceed as described above. If the flame does not light after
the first attempt, wait 5 minutes for the gas to dissipate before
attempting to re-light the burner.
Once lit, check that the flame is even and turn the control knob to
adjust the flame as required. If the flame is uneven, check that the
'burner head/skirt' and 'burner cap' are correctly positioned. To
turn off the flame, turn the control knob clockwise to the ‘Off’
position ( ). Before removing pots or pans from the
burners, always turn off the flame.
symbol
9
Use and Care
When turning the flame down from the 'High' position (2) to
the 'Low' position (3) only the outer flame turns down.
After this point, the outer flame turns off and the inner flame
begins to turn down until it reaches the 'Low' flame position (4).
When turning the flame up again, the outer flame automatically
relights starting in the 'Low' position (3).
Using the Dual Valve Wok burner (not all models)
The Dual Valve Wok burner has the advantage of providing both
very high or very low heat when needed.
The powerful Dual Flame provides high heat when frying, boiling
or searing is required. It can also be turned to the lowest point
where only the small inner flame remains alight to provide a low
heat for simmering or keeping the dish warm.
Follow the instructions below to light the burner.
Use and Care
Inner & Outer Flame
operating on High
Inner Flame on High
and
Outer Flame on Low
Inner Flame on Low
10
Este manual sirve para los siguientes modelos
4
Tabla de contenidos
Otros manuales de Placa de cocina de Euromaid
Euromaid
Euromaid 0 Manual de usuario
Euromaid
Euromaid I3B60 Manual de usuario
Euromaid
Euromaid CST70 Manual de usuario
Euromaid
Euromaid IMZ64 Manual de usuario
Euromaid
Euromaid Range Manual de usuario
Euromaid
Euromaid IHT3B60 Manual del propietario
Euromaid
Euromaid KCS4 Manual de usuario
Euromaid
Euromaid CT70 Manual de usuario
Euromaid
Euromaid IHT3B60 Manual del propietario
Euromaid
Euromaid I4B60 Manual de usuario
Euromaid
Euromaid ECCT Series Manual de usuario
Euromaid
Euromaid EGS60 Manual de usuario
Euromaid
Euromaid GG90S Manual de usuario
Euromaid
Euromaid EC64 Manual de usuario
Euromaid
Euromaid CC9GE1 Manual de usuario
Euromaid
Euromaid CF7GS Manual de usuario
Euromaid
Euromaid IMZ96 Manual de usuario
Euromaid
Euromaid G7FS1 Manual de usuario
Euromaid
Euromaid ECCK64 Manual de usuario
Euromaid
Euromaid Hot Plates Guía
