Installation
This unit may be installed and used only in permanently ventilated rooms:
Unpacking
a)
b)
c)
Installation
b)
c)
d)
e)
f)
g)
h)
The following instructions should be read by a qualified technician to ensure that the appliance
is installed, regulated and technically serviced correctly in compliance with current regulations.
Important: remember to disconnect the appliance from electricity by turn off the mains before
regulating the appliance or carrying out any maintenance work.
Positioning
Important: The hob should never be installed in proximity of a door access. People opening
and closing the door could come into contact with pots or pans cooking on the hob.
Be careful
when
unpacking
and
installing
the
appliance.Sharp
edges might
cause accidents.
The oven is heavy and care must be taken when moving it. Ensure that all packing,
both inside and outside the cooker, has been removed before the oven is used.
Unpack the oven from the carton, check and make sure it has not been damaged in any
way.If you have any doubts, do not use it, contact the service center or where you buy the
oven.
The cooker is desig ned to fit between kitchen cabinets. The space either side need only be
sufficient to allow withdrawal of the cooker for servicing. It can be used with cabinet one side or
both as well as in a corner setting. It can also be used free-standing.
The appliances can be installed next to furniture units which are no taller than the top of the
cooker hobs. If the cooker is placed touching walls or sides of neighboring cabinets, these must
be capable of withstanding a temperature rise of 50 °C above room temperature.For a correct
installation of the cooker the following precautions must be followed:
a)
The cooker may be located in a kitchen, a diner or bed sitting room, but not in a bathroom or
shower room.
Kitchen cabinets installed next to the cooker that are taller than the top of the cooker
hobs must be situated at least 20cm from the edge of the hobs.
Hoods must be installed according to the requirements in the installation manual for
the hoods themselves and in any case at a minimum distance of 65cm.
Place the wall cabinets adjacent to the hood at a minimum height of 42cm from the hobs
as indicated in figure 1.
The hoods must be installed according to the requirements in the hood handbook.
Should the
cooker be installed beneath a wall cabinet, the latter should be situated at least 70cm away
from the hobs as indicated in figure 1.
The cut-out for the cooker cabinet should have the dimensions indicated in the figure1.
The wall in contact with the back of the cooker must be of flameproof material.
It is necessary to allow disconnection of the appliance fromthe supply after installation.
