Euro Video EVD-16/400A16MN Guía
User’s Manual
EVD-16/400A16MN -1- www.eurovideo-cctv.com
INSTALLATION/OPERATION
REALTIME
DIGITALVIDEO RECORDER
(MPEG4 –16 CHANNEL)
User’s Manual
EVD-16/400A16MN -2- www.eurovideo-cctv.com
WARNING: To prevent a risk of fire of electric shock, do not expose this product to rain or moisture.
• This installation should be made by a qualified service person and should conform to all local codes.
• This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
Copyright This manual is the intellectual property of Manufacturer and is
protected by copyright. All rights are reserved. No part of this
document may be reproduced or transmitted for any purpose,
by whatever means, be they electronic or mechanical, without
the express written permission of Manufacturer.
Edition : Dec.2007
Copyright 2007 Manufacturer
Note This Manual was compiled with the greatest of care and all information
double checked. At the time of printing the description was complete and
correct. Because of the further development of products, the content of the
manual might change without prior notice. Manufacturer will not be liable
for damage which is directly or indirectly due to errors, incompleteness, or
discrepancies the manual and the product described.
Trade marks All names used in this manual for hardware and software are very probably
registered trade marks and must be treated as such.
User’s Manual
EVD-16/400A16MN -3- www.eurovideo-cctv.com
Contents
FOR THE SAFETY OF CUSTOMERS…………………...………………………….…………………………4
DESCRIPTION OF PARTS AND FUNCTION…………...…………………………………………………....7
COMPOSITION OF UNIT…………………………………...……………………………………………………7
FEATURES …………………………………………………..……………………………….……………….....8
DESCRIPTION OF PARTS AND FUNCTION ………………..…………….…………..……..……………….. 9
Front Panel……………………………………………………..………………………………..…………........9
Rear Panel………………………………………………………..………………………………………… …11
Connection diagram………………………………………………………………………………………….13
OSD Description.................................................................................................................................................15
MENU………………………………………………………………...………………………………………......16
MENU TREE…………………………………………………………..…………………………………………16
Main Menu.…………………………………………………………..………………………………………..18
Display………………………………………………………………..………………………………………..18
Recording……………..………..……………………………………..………………………………………..22
System ….……………………………………………………………..……………………………………….26
Network …………………………………………………………………..…………….……………………..32
Event ….……………………………….…………………………..…………………………….….34
Search………………………………………….……………………………………………………….………35
Search……………………………….…………………………………………………….………35
BackUp……….……………………………………………………………………………….………39
Log……….……….……………………….……………………………………………………….………41
Client Program…………………………………………………………………………………........................42
Q & A……………….………………………………………………………………………………….…………68
Appendix 1…...……………………………………………………………………….........…………………….70
Appendix 2...………………………………………………………………………….........…………………….73
Appendix 3…...........………………………………………………………………….........…………………….77
Appendix 4…...........………………………………………………………………….........…………………….80
Appendix 5…...........………………………………………………………………….........…………………….82
Appendix 6 (Specification) ………….…………………………………………….........…………………….89
Product Warranty……………………………………………………………………………………………….91
User’s Manual
EVD-16/400A16MN -4- www.eurovideo-cctv.com
1. FOR THE SAFETY OF CUSTOMERS
Caution before use
Please read this manual for proper use.
The caution described in this manual contains very important information for the safe use, so, please
follow the instruction.
Please keep it whether you could reach after read.
For the safety and proper use, it marked various symbol. So, please read it to prevent your physical or
financial loss.
Tips for installation
Please avoid water which could be the reason of firing or electric shock.
Clean the plug and socket.
Please keep the socket and plug clean so that you could avoid the fire. The plug should be tightly
connected to the wall socket.
Do not put the unit on an unstable place.
Do not put the unit on an unstable place like rugged table or slope place.
Be careful for the installation position.
Don’t put the device in humid, direct sunlight, dusty, hot, greasy condition.
User’s Manual
EVD-16/400A16MN -5- www.eurovideo-cctv.com
Caution for proper usage
During use
In following cases, please turn off the power and remove the plug then, please contact technical
support.
If you use it continually, it could be a reason for a fire or electric shock.
If smoke comes out of the device or when you smell something burning.
If a alien substance is split into the device.
If the device is dropped or the case is damaged.
If the power cable has been damaged ( ex. slipped etc.)
No picture being displayed.
Don’t open the case or modify.
There is the high voltage sector inside the unit so, if you open the case
or modify it, it could cause the fire or electric shock.
Don’t put a cup containing water or juice and small material on the device
If you spilt water or alien substance into the device, it could cause the fire or electric shock.
Don’t put any alien substance
.
..
.
Don’t put alien substance through the fan.
Don’t touch when lightning
.
..
.
When the lightning starts, don’t touch the plug or cable. It could cause the electric shock.
Don’t touch the power plug with wet hand
.
..
.
Don’t unplug with wet hands. It could cause a electric shock.
Don’t pull out the power cable.
Use the designated HDD
User’s Manual
EVD-16/400A16MN -6- www.eurovideo-cctv.com
Please use the designated HDD. Otherwise, recording may be operated improperly.
Maker HDD Capacity
Western Digital
Seagate
80,160.250.500,750GB each. And Total 3TB is supported.
Up to 4pcs of HDD are available.
*
**
*
Manufacturer guarantee the combination of same HDD capacity only.
(Ex. It is fine with 320GBx2pcs but it isn’t guaranteed with 250GB+80GB.)
Don’t pull out the cable when plug out from the wall socket.
It could damage the cable and cause the fire.
Please pull out holding the plug.
When you move, please remove plug
.
..
.
If you move the device while the plug is in the socket, it could cause a fire by damaging the cable.
Don’t block the ventilation window.
When the ventilation window is blocked, it could cause the fire by the generation of Internal heat.
Don’t put a heavy item on the device
.
..
.
When it looses the balance and falls down, the customer could be hurt.
Keep the plug and socket clean.
Regarding the cleaning, please contact your Installer.
If there is too much dust inside the device, it could cause the fire or internal short.
Clean the plug and socket.
Please keep the socket and plug clean to avoid fire. The plug should be tightly connected to the wall
socket.
Caution when you don’t use the device for a long time.
If you don’t use the device for a while, please switch off and unplug.
User’s Manual
EVD-16/400A16MN -7- www.eurovideo-cctv.com
2
2.
.
D
DE
ES
SC
CR
RI
IP
PT
TI
IO
ON
N
O
OF
F
P
PA
AR
RT
TS
S
A
AN
ND
D
F
FU
UN
NC
CT
TI
IO
ON
N
2-1 COMPOSITION OF UNIT
Standard
When you have received a product “without HDD” , the accessories
1) stand for HDD installing 2) fixing screws will be supplied.
2-2 FEATURES
※Accessories are subject to change without notice.
Power Cable
Digital Video Recorder System
Please read this manual before using
User Manual
Remote Controller
Battery
User’s Manual
EVD-16/400A16MN -8- www.eurovideo-cctv.com
●
Convenience
- User-friendly GUI( Graphic User Interface)
- Easy-to-use menu composition
- Easy-to-use recorded data search (Time, Date, Motion,Alarm)
- Easy-to use menu with USB Mouse.
●Stability
- Auto restart after power interruption
-DB structure offers data stabilization and best storage utilization
●Expandability
-Various remote multi DVR’s can be controlled by Web browser (PC Client System)
●Technology
-Embedded LINUX OS
-Totally maximum recording rate 400fps
-High-resolution & high-quality MPEG-4 algorithm
-Using Water marking & scrambling technologies,
-Strong protection recorded data
-MPEG-4 : 1 ~ 2 Kbytes per image with resolution 360x240
●Functionality
- Variable recording function (normal, alarm, motion, schedule, audio, Time Lapse,)
- Full channel real-time monitoring
- Live monitoring, recording, playback, backup, remote access at the same time
- Multi channel playback
- Variable events notification to e-mail, buzzer or PC Client system
2-3 DESCRIPTION OF PARTS AND FUNCTIONS
2-3-1 Front Panel
User’s Manual
EVD-16/400A16MN -9- www.eurovideo-cctv.com
(1) MENU
- Display on the menu on the screen
(2) P/T/Z/ SELECTION
- P/T/Z selection of the channel that a user wants to control
(3) CHANNEL DIVISION
- Screen split that a user wants to set
(4) LED (POWER/REC/NET/HDD)
- PWR : System Power On/Off (When power is on, the green light is lit up)
- REC : Recording status (When recording is on, the red light is blinking)
(5) PAN/TILT/ZOOM/FOCUS
-
Control on PAN/TILT/ZOOM/FOCUS of the channel that a user selects
(6) SELECTION BUTTON
- Menu selection
(7)ARROW KEY
- Course shifting on the menu
(8) SEARCH
- Entering search mode directly
(9) STOP& EJECT ( )
- To stop playback and go back to live mode
- To eject CD-RW
User’s Manual
EVD-16/400A16MN -10- www.eurovideo-cctv.com
(10) PAUSE ( )
- To freeze picture on playback mode and live mode
(11) REWIND (◀
◀◀
◀)⊳
⊳⊳
⊳
- Playback on the reverse
(12) PLAY ▶(▶)
▶(▶)▶(▶)
▶(▶)
- Playback on the recorded data
- One more button on play mode, fast-forward will be executed
(13) REC (●
●●
●)
))
)
- It manually starts & stops recording of relevant camera in a full screen live mode
(14) POWER BUTTON
- System Power On/Off
(15) USB 2.0 PORT
- USB 2.0 connector
(16) NUMERIC & CHARACTER
- Input for numeric & character
