EtroVISION EV6552A Manual de usuario
EV6552A Series
Fixed Dome IP Camera
User’s Manual Ver. 6.1
About This Guide
Model
EV6552A
EV6552AP
Before Using the EV6552A & EV6552AP Fixed Dome IP Camera
Check PC requirement
Check OS platform requirement
Install EtroStation™ 3.0 software before you start using the video
server.
Read special and important precautionary information.
Basic knowledge of network setup and configuration will be helpful.
Icon Descriptions
Notes: This icon represents a tip for operation.
Caution: This icon stands for an action that probably impairs the
operation.
Warning: This icon stands for an action that can cause damage to the
operation.
Disclaimer
© 2007 Etrovision Technology. All rights reserved.
Etrolink™ & AnyUSB™ are trademarks of Etrovision Technology; other
product or service names mentioned herein are the trademarks of their
respective owners. Information contained in this document may be
superseded by updates. No representation or warranty is given and no
liability is assumed by Etrovision Technology with respect to the accuracy or
use of the information, or infringement of patents or other intellectual
property rights. No licenses are conveyed, implicitly or otherwise, under any
intellectual property rights.
TABLE OF CONTENTS
Enter the port number, user name, password, and server name information of the
SMTP server. If you’d like to receive the attached snapshots, please enable the
appropriate check box. Authentication is not a mandatory requirement by SMTP
servers. In some situations, the required information includes the SMTP server
name and e-mail address only.................................................................... 36
Please fill in the address of remote FTP server, port number, user name, and
password................................................................................................ 37
1.PRODUCT OVERVIEW
EV6552A & EV6552AP support dual streams simultaneously.
Combination options include:
Stream 1 Stream 2
H.264 M-JPEG
H.264 MPEG-4
H.264 H.264
M-JPEG MPEG-4
M-JPEG H.264
M-JPEG M-JPEG
MPEG-4 H.264
MPEG-4 M-JPEG
MPEG-4 MPEG-4
Stream 1 Stream 2
Note: If users assign MPEG-4 for both Stream1 and 2, the image will be unable
to reach real-time performance. M-JPEG for both Stream 1 and 2 leads to the same
result. This is system limitation.
Difference between EV6552A and EV6552AP:
Features EV6552A EV6552AP
Sensor type 1/4” Low-light sensitive CMOS
Compression Format M-JPEG, MPEG-4 dual codec
Audio Line Out x 1
Scanning System progressive scan
PoE N/A YES
Package Checklist
EV6552A IP Camera x 1
Power Adapter x 1
USB Cable x 1
Product CD x 1
Screws
Front
Connectors
DIP SW Pin#1: AES On/Off
DIP SW Pin#2: AGC On/Off
DIP SW Pin#3: AWB On/Off
DIP SW Pin#4: Mirror On/Of
f
RJ-45 Ethernet Connect
Green: Audio Out Cable
Black: Power In Cable
2.SETTING AND INSTALLATION
Note:
Connect EV6552A / EV6552AP to your network by using a standard Cat-5
cable.
Connect the video output of your camera with video in of video server, using
standard 75Ωcoaxial cable with BNC type connector.
Connect speaker and active microphone to Audio In / Out.
Product CD
Product CD in the package contains:
EtroStation™3.0 NVR management software
o16CH Live View / Recording / 4CH Playback
User’s Manual
Power on IP Camera
Use the power adapter, provided in the package, to power on the IP
camera. The adapter should be connected to 110v~22Ov AC socket.
Connect to Network
Connect EV6552A / EV6552AP and network hub/switch via a standard
CAT5 Ethernet cable and RJ-45 socket. Please pay attention that the PC
must be on the same network domain with the IP camera.
Connect I/O
Users have to make pin-to-pin correctly to enable this function.
Enable Audio Function
The video flicker may occur when enabling or disenabling audio
in and audio out. The situation normally lasts for a second.
Easy Installation
Step 1: Lock the screws by the main to fix the IP camera into the ceiling or
wall.
Step 2: Lens can be adjusted to the specific angle as required
Step 3: Lock the screw to fix the front holder (this action is required)
Step 4: Use the white lid to cover the inner part of IP camera
3.USING EV6552A / EV6552AP
FOR THE FIRST TIME
Before You Install Software
Please check PC OS platform. Microsoft Windows 2000 or
Windows XP is capable of running EtroStation™3.0 software.
PLEASE read EtroStation™3.0 user’s manual before installation.
Language Support
English
Install EtroStation™ 3.0
User can easily find the specific IP camera on the network via this
software.
Browser for Live Viewing and Video Settings
Microsoft IE browser version 6 or higher is recommended. Currently
Mozilla Firefox and others are not compatible.
Factory Setting – Initial IP Address
Default IP Address: 192.168.1.2
Gateway: 192.168.1.1
Subnet Mask: 255.255.255.0
