ETC Source 4WRD Manual de usuario

Source 4WRD

HPL to LED Retrofit

Installation and User Manual

Version 1.1.2

Part Number: 7067M1200-1.1.2 Rev C

Released: 2019-06

To view a list of ETCtrademarks and patents, go to

etcconnect.com/ip. All other trademarks, both marked and not

marked, are the property of their respective owners.

ETC intends this document, whether printed or electronic, to be

provided in its entirety.

Table of Contents

Source 4WRD Installation and User Manual i

Introduction 1

Help from ETC Technical Services 2

Safety 3

Retrofit the fixture 6

Wire the power connector(if needed) 6

Remove incandescent lamp housing 7

Install the Source 4WRD retrofit 7

Install the fixture 9

Attach C-clamp and safety cable 9

Connect cables 10

Configure the fixture 13

RDMvalues 13

Focus the fixture 14

Set the Z-adjustment 14

Adjust the yoke position 14

Shape the beam 15

Troubleshoot the Source 4WRD 16

Clean and maintain the fixture 17

Clean the fixture 17

Store the retrofit 17

Clean the lenses 18

Clean the reflector 19

Clean 5° and 10° polymer lenses 20

ii Source 4WRD Installation and User Manual

Source 4WRD Installation and User Manual 1

Introduction

The Source 4WRDLED is a replacement for a standard Source Four

burner assembly. It converts the HPL source to a white-light LED and

provides a significant reduction in power consumption.

Source 4WRD

LED retrofit kit,

shown installed

on a Source Four

fixture body

The following Source 4WRD options are available in 80 CRI, 90 CRI

(Gallery), and 90 CRI Daylight (Gallery) variants:

•

Source 4WRDLED retrofit kit: Used to modify an existing Source

Four HPL incandescent fixture to a white LED fixture. The Source

4WRDLED can also be used with the Source 4WRD PAR or

PARNel Fixture Body to create a Source 4WRD PAR or PARNel

fixture. For more information, visit etcconnect.com.

•

Source 4WRD Light Engine: Combines the Source Four

incandescent fixture body with the Source 4WRDLED. Available

only with 80 CRI and 90 CRI (Gallery) variants.

Note: The Source 4WRDLED retrofit kit is not compatible with

Source Four LED, Fresnel, PAR, or jr fixtures.

2 Source 4WRD Installation and User Manual

Help from ETC Technical Services

If you are having difficulties, and your problem is not addressed by

this document, try the ETC support website at support.etcconnect.com

or the main ETC website at etcconnect.com. If none of these resources

are sufficient, contact ETC Technical Services directly at one of the

offices identified below. Emergency service is available from all ETC

offices outside of normal business hours.

When calling for help, take these steps first:

•

Prepare a detailed description of the problem

•

Go near the equipment for troubleshooting

•

Find your notification number if you have called in previously

Americas United Kingdom

Electronic Theatre Controls Inc. Electronic Theatre Controls Ltd.

Technical Services Department Technical Services Department

3031 Pleasant View Road 26-28 Victoria Industrial Estate

Middleton, WI 53562 Victoria Road,

800-775-4382 (USA, toll-free) London W3 6UU England

+1-608 831-4116 +44 (0)20 8896 1000

service@etcconnect.com techservltd@etcconnect.com

Asia Germany

Electronic Theatre Controls Asia, Ltd. Electronic Theatre Controls GmbH

Technical Services Department Technical Services Department

Room 1801, 18/F Ohmstrasse 3

Tower 1, Phase 1 Enterprise Square 83607 Holzkirchen, Germany

9 Sheung Yuet Road +49 (80 24) 47 00-0

Kowloon Bay, Kowloon, Hong Kong techserv-hoki@etcconnect.com

+852 2799 1220

techservasia@etcasia.com

France

ETC France

62-64 rue Danielle

Casanova

Saint-Denis Cedex,

F93200

+33 1 4243 3535

techservltd@etcconnect.com

Source 4WRD Installation and User Manual 3

Safety

The Source 4WRD fixture is intended for professional use only. Read

the entire manual before using this equipment.

WARNING: Note the following safety warnings before use:

•

Do not mount the fixture on or near a flammable surface.

•

Do not use this fixture with a damaged power lead. If the

power lead (cord set) is damaged, it must be replaced.

•

Mount and support the fixture only by the primary

suspension holes in the yoke.

•

Suspend the fixture from a suitable structure using only

hardware rated for the weight of the fixture.

•

In addition to primary suspension, attach a safety cable (ETC

Model 400SC or other approved safety cable or device) to

the fixture housing. An appropriate attachment point (hole)

is provided in the protruding tab on the fixture housing.

•

Disconnect the unit from power and DMX and allow the

fixture to cool before removing or installing accessories, and

before all cleaning and maintenance.

AVERTISSEMENT : Prendre connaissance des avertissements de

sécurité suivants avant toute utilisation :

•

Ne pas installer le projecteur sur ou à côté d’une surface

inflammable.

•

Ne pas utiliser ce projecteur avec un cordon d’alimentation

endommagé. Si le cordon d’alimentation (câble) est abîmé, il

doit être remplacé.

•

Installer et accrocher le projecteur uniquement par les trous

de fixation principaux de la lyre.

•

Accrocher le projecteur à une structure convenable en

utilisant seulement du matériel adapté au poids du

projecteur.

•

En plus de l'accroche principale, fixer une élingue de

sécurité (modèle ETC400SC ou autre câble/dispositif de

sécurité certifié) au corps du projecteur. Un point d’accroche

(trou) approprié est prévu dans la patte qui ressort du

boîtier du projecteur.

•

Déconnecter l’alimentation et le DMX et laisser le projecteur

refroidir avant d’enlever ou installer l'optique découpe ou

les autres adaptateurs, et avant tout nettoyage et entretien.

4 Source 4WRD Installation and User Manual

WARNING: Note the following safety warnings before use:

•

The Source 4WRD LED is not user serviceable. Field

modification of the Source 4WRD LED will void your ETC

warranty.

•

Do not use the Source 4WRD fixture below 5°C (41°F).

•

Minimum storage temperature is 5°C (41°F). When the

fixture has been stored or transported in cold temperatures,

allow it to warm to room temperature for a minimum of

1hour before applying power. Applying power to a cold

fixture will cause damage to the fixture and void the ETC

warranty.

•

Do not use this fixture if a glass lens is deeply scratched or

cracked. Damaged lenses must be replaced.

•

To prevent wiring damage, or abrasion, do not expose

wiring to edges of sheet metal or other sharp objects.

•

Use the Source 4WRD fixture in dry locations only, where

humidity does not exceed 90 percent (non-condensing).

These fixtures are not intended for outdoor use.

Source 4WRD Installation and User Manual 5

Specifications

For full product specifications, see the Source 4WRDLED datasheet at

etcconnect.com.

Electrical

•

114–125 VAC 60 Hz power input

•

155 W draw at full (182 W theoretical max. draw)

•

Recommended two (2) fixtures per dimmed circuit (D20 module)

•

Max of 14 fixtures per non-dimmed circuit (R20 module)

•

If using in DMX mode: Connect fixture to relay, constant power,

or dimmer with regulation off and parked at full

Typical Power Consumption

Mode Power Current

Idle:DMXMode 1.2W .046A

Idle: ACMode 0W 0 A

Full Intensity 155.7W 1.35A

Environment

•

Ambient operating temperature: 5°C–50°C (41°F–122°F)

•

Minimum storage temperature: 5°C (41°F)

•

Maximum recommended ambient operating

temperature:Ta=50°C (122°F)

•

Maximum anticipated external surface temperature: Tmax=63°C

(145°F) at Ta=50°C (122°F)

•

External Temperature (steady state achieved) at 25°C (77°F)

ambient: 38°C (100°F)

Weight

•

Source 4WRDLED retrofit kit only: 3.65lb (1.66kg)

•

Source 4WRDLED installed on 26° fixture with yoke and

C-clamp:14lb (6.35kg)

Optical

Compatible with all ETCSource Four lens tubes.

6 Source 4WRD Installation and User Manual

Retrofit the fixture

WARNING: RISK OF FIRE OR ELECTRIC SHOCK! Installing the

Source 4WRDLED retrofit kit requires knowledge of luminaire

electrical systems. If you are not qualified, do not attempt

installation. Contact a qualified electrician.

AVERTISSEMENT : RISQUE D'INCENDIE OU DE DÉCHARGE

ÉLECTRIQUE! Installer le nécessaire de conversion Source 4WRDLED

nécessite une connaissance des systèmes électriques de projecteurs.

Si vous n’êtes pas qualifié, ne tentez pas l’installation. Faire appel à

un électricien qualifié.

Note: THE RETROFIT KIT IS ACCEPTABLE AS A COMPONENT OF A

LUMINAIRE WHERE THE SUITABILITY OF THE COMBINATION SHALL

BE DETERMINED BY AUTHORITIES HAVING JURISDICTION.

Source 4WRD

LED Retrofit Kit

LEDs

RJ45 data in

and data thru

User interface and

navigation buttons

Wire the power connector(if needed)

If you ordered a Source 4WRD retrofit without a power connector,

wire the connector in accordance with all national and local electrical

codes:

•

Brown = Line

•

Blue = Neutral

•

Green/Yellow = Ground
