eSSL TS2000 Manual de usuario
Security at Fingertips
www.esslsecurity.com
1110 500 260
980
980
1110
260
500
740
260
500
260
500
<80 <80
＞100
980
Assistant
framework
1. When installing the tripod turnstile against the wall, please reserve at least 100 mm space in order to open the cover for adjustment
and maintenance.
2. The space at the end of the arm shall not be greater than 80 mm (see figure 3-1).
3. Setting a warning line for card swiping (see figure 3-2). A warning line is suggested to prompt users to swipe cards in a distance,
which would greatly reduce the probability of equipment failure caused by improper operations.
Warning line for card swiping
Warning line for card swiping
Warning line for card swiping
Warning line for card swiping
S
Turnstile-opening
Electromagnet
Turnstile-opening
Electromagnet
